- Page 1 T410 Dual Channel Smart Soldering Station User Manual Please read this manual carefully before use...
-
Page 2: Product Features
Smart identification system, monitor the working statuses in real time Modular handle holder, separable and combinable IPS HD LCD interface, personalized settings, easier to operate Parameters Host parameters Model: T410 Input voltage: 110/230V Peak power: 100W Temp range: 90~450°C Host size: 178.4*112*125mm Input fuse: 3A. -
Page 3: List Of Packing
List of packing The package of T410 includes the following components Cable hanger ------ ×1 Grounding wire ------ ×1 Host ------ ×1 Handle holder----- ×1 T210 handle------ ×1 K tip------ ×1 Power cable------ ×1 Manual card------ ×1 Certificate------ ×1... -
Page 4: Product Structure
Product structure Handle cable clamp Function/OK buttons Tip holder Temp Tip pull socket shortcut buttons Handle holder 2.4inch HD display screen Tip cleaner Power switch Type-C interface Handle interface Heat emission hole Power input interface Grounding interface Expanded holder interface Handle holder connect interface... - Page 5 Adjustable holder Handle cable clamp Adjust angles of handle holder, Place the cable on the clamp to avoid twine meeting needs for working position Support expanding to two holders, operate with one handle Two channels are heated one by one rather than simultaneously Splash shield Prevent solder from splashing when cleaning with brass wire...
- Page 6 Main interface and buttons introduction Main interface introduction Case temp Set temp display Software version Handle model Working state Real time temp display Power Shortcut temp switch Fast temp switching The “CH1, CH2, CH3” buttons corresponds to a temperature channel. Users can adjust the set temperature according to their own needs, press the button to switch the...
- Page 7 Function buttons operation Temperature setting Temperature System curve setting Standby setting The power on interface of the station default to be the main interface. Click the middle function button to enter the function setting interface. The functions displayed on the interface correspond to the function buttons one by one, a nd the user can operate according to the prompts.
- Page 8 Soldering station operation Working mode Standby mode When the soldering handle is picked up When the soldering handle is placed in from the holder, the iron tip will the handle holder, the host will automatically heat to the selected automatically enter the standby mode temperature.
- Page 9 Precautions Precautions for soldering station To avoid damage to the soldering station and consider safety of the working environment, the following matters shall be observed: This product uses a three wire grounding plug, which must be inserted into a three hole grounding socket.
- Page 10 Use and maintenance of soldering iron tip Note: do not use a file to remove the oxide on the iron tip 1. Set the temperature at 250 degrees Celsius (482 degrees Fahrenheit). 2. After the temperature is stable, clean the iron tip with a cleaning sponge and check the state of the soldering iron.
-
Page 11: After Sales
AiXun company has the final right to interpret the above regulations. - Page 12 Phone：(+86) 400-175-8688 Website：www.aixuntech.com Address：503, Building C4, Zhonghao Industrial Park, Xiangjiaotang Community, Bantian Street, Longgang District, Shenzhen...
