Summary of Contents for Kallipr Captis Pulse Lite 1.0
- Page 1 Captis Termination Guide 12/12/2022...
- Page 2 Contents Scope .................................... 2 Before You Begin ..............................2 What do you need? ............................2 Compatibility ..............................3 Terminating ................................. 3 Prepare the Cable ............................3 Crimp the pins ..............................4 Secure the Pins ..............................5 Fasten the Connector ............................. 5 Testing ..................................
-
Page 3: Before You Begin
1 Scope The purpose of this document is to detail the termination guidelines of the Captis Pulse Lite 1.0, Captis Pulse 1.2, Captis Multi 1.2 and Captis Recharge 1.2. 2 Before You Begin Before you begin, please ensure you have the required tools and have reviewed this document. - Page 4 Strip Insulation Length (A) Strip Jack Length (B) 3.5mm – 4mm 16mm – 18mm Table 3 Please contact support@kallipr.com to ensure the selected sensor is compatible with the selected Captis device. Captis Cloud Configuration Guide Page | 3...
- Page 5 Crimp the pins The following steps outline how to securely crimp the amphenol pin to the cable conductor. Please note, only the crimping tool listed below is recommended for crimping these pins. Failure to use the recommended tool may result in non- compliant installations.
- Page 6 3.3 Secure the pins Please ensure that care is taken to select the correct terminal for each pin as the connector is not suitable for pin removal. As such, there is no recommended practice for pin removal. After all of the cable conductors have been successfully fastened to the crimps, the amphenol pins may be inserted into the pin receptacles.
- Page 7 Ensure that the Captis is correctly configured to receive the data from the connected sensor. If there is no data being transmitted by the sensor to the Captis device, please review the terminations and sensor output. If the issue persists, please contact support@Kallipr.com Captis Cloud Configuration Guide Page | 6...
