- Page 1 Hexagonal Trampoline Manual MODELS SK HX50 UBG HX50 OR UBG HX50 YL UBG HX50 GR SK HX40 UB03EC 40HXE 2 Mill St. Cornwall, NY 12518 1-845-810-0083 020.3150.0484 www.Machrus.com support@machrus.com support@machrus.co.uk...
-
Page 2: Safety Instructions
Safety Instructions • To ensure the maximum safety of the trampoline, check it regularly for damaged and worn parts. • If you pass on this trampoline to another person or if you allow another person to use it, make sure that the other person is familiar with the product and details outlined in this instructions booklet. -
Page 3: Important Notes
Important Notes • Assemble the trampoline as per the assembly instructions and be sure to only use the structural parts provided with the trampoline. Prior to assembly, make sure the contents are correct by referring to the parts list on the assembly and operating instructions. •... -
Page 4: Parts List
Parts List Part Part PART# ITEM Number 40" Number 50" Frame Tube UBRP-0082 UBRP-0032 Frame Tube With UBRP-0093 UBRP-0033 Handrail Holder UBLEG-10-6 UBLEG-10-6 UBRP-0095 UBRP-0035 Bungee Cord 50” Trampoline UBRP-0104 UBRP-0036 Bungee Cord 40” Trampoline Bottom Handrail UBRP-0137 UBRP-0137 support Upper Handrail UBRP-0138 UBRP-0138... - Page 5 Steps to assemble the trampoline Step 1 - Attach the frame tubes as shown in fig. below. Step 2 - Remove the black caps that cover the leg connectors. Screw all legs onto the frame leg connectors. (They are the small threaded pieces that extend from the frame.) Remove black cap...
- Page 6 Step 3 - Prepare the Mat- Thread all the bungee cords individually (manual item #4) through the bungee holes at the end of the mat, (Manual Item #3). One bungee per bungee hole. Step 4 - Fasten the bungee cords to the frame tube. First fasten the two bungee cords closest to every corner, as shown in the figure below.
- Page 7 Steps to install the bungee cord Note When installing the bungee cords keep the ball on the underside of the frame. Thread the bungee cord through the loop attached to the jumping mat.Thread all the cords in the same direction. Pull both ends of the bungee cord out past the trampoline frame.
- Page 8 Step 5 - Assemble the bottom handrail Step 5 - Assemble the bottom handrail support (Manual Item #5) to the frame support (Manual Item #5) to the frame (Manual Item #1-A) attaching it with the (Manual Item #1-A) attaching it with the bolts, washer and nuts, using the wrench bolts, washer and nuts, using the wrench as shown in the following figure.
- Page 9 Step 6 - Assemble the upper handrail support (Manual item #6) into the bottom handrail support (Manual item #5), and slide it into its position with the adjustment knob (Manual item #8).
- Page 10 Step 7 - Attach the handrail (Manual item #7) to the upper handrail support (Manual Item #6). Attach the handle by using the screws (Manual items 12 and 14), and the reinforced sheet (Manual Item #17) as shown in the picture below, tighten the screws with the wrench.
- Page 11 If you purchased a trampoline that includes a safety pad then follow Step 8 (otherwise skip this step) Step 8 - Attach the pad to the mat of the trampoline with the Velcros, as shown in the figure below. Step 9 - Trampoline Assebly is complete.
- Page 12 If you have difficulty finding the correct replacement part for your trampoline. PLEASE GIVE US A CALL 1-845-810-0083 EMAIL US AT support@machrus.com Our Customer Service Department staff are trained in the details of all trampolines and will help you find the right part to get you bouncing again.
