- Page 1 ALL-IN-ONE UTILITY CABINET WITH STAINLESS-STEEL SINK AND FAUCET TOUT-EN-UN ARMOIRE DE RANGEMENT AVEC ÉVIER EN ACIER INOXYDABLE ET ROBINET OWNER’S MANUAL ITM. / ART. 2233579 MANUEL DE L’UTILISATEUR QL014...
-
Page 2: Table Of Contents
. If you have any questions, contact the manufacturer . 3 . Installation work and plumbing must be done by qualified person(s) in accordance with all applicable codes and standards . 4 . Protect the entire surface during installation . QL014... -
Page 3: Warranty
Warranty ONE YEAR LIMITED WARRANTY A thorough inspection must be made before installation and any damage must be promptly reported . We will not be liable for failures or damage that could have been discovered or avoided by proper inspection and testing prior to installation . Conglom Kitchen &... -
Page 4: Pre-Installation
Needle nose Phillips wrench pliers screwdriver Utility knife Pipe wrench Sealant Hacksaw Carpenter’s level Hex key Safety gloves Safety goggles PARTS REQUIRED (NOT SUPPLIED) NOTE: Parts not shown to actual size. Supply Wall Fastening Tailpipe P-Trap Shims lines Hardware QL014... -
Page 5: Package Contents
Pre-Installation (continued) PACKAGE CONTENTS Carefully check the utility cabinet for damage and/or missing parts prior to installation . If there is any damage or if you are missing parts, do not proceed with the installation . Report damage and/or missing parts immediately to our customer service team at cs@conglomkb . com or 1-877-333-0098 (Service available in English and French, Monday - Friday from 8:30 am - 5:00 pm EST) . -
Page 6: Installation
CAUTION: Do not rest or bump the leveling legs on the side using four of the provided screws (H) . as this may cause them to detach or break. - Gently rotate the cabinet (A) right side up . QL014... -
Page 7: Installing The Handles
Installation (continued) INSTALLING THE HANDLES - Attach door handles (C) to the cabinet doors using supplied door handle screws (G) and a screw driver . Do not overtighten . ADJUSTING THE DOOR POSITION If the doors need to be repositioned, the hinges can be adjusted to ensure a precise fit with the cabinet. -
Page 8: Installing The Faucet
. Quick Connector Hose NOTE: It is helpful to have a second person hold the faucet in place while Sprayer Hose tightening the mounting nuts. Please ensure that none of the supply lines are kinked during installation. QL014... -
Page 9: Installing The Strainer
Installation (continued) INSTALLING THE STRAINER Strainer Basket - Apply plumbing putty or silicone sealant to the top side of the drain opening . - Insert the strainer body into the drain opening and press it down until it is evenly seated . Strainer Body - Assemble the rubber gasket, friction washer and strainer locknut onto the strainer body from underneath the sink . -
Page 10: Placement
. Secure the handle in Setscrew Cap place using the setscrew and cover it with the setscrew cap . Turn the water supply to the faucet back on . Operate the faucet to make sure everything works correctly . QL014... -
Page 11: Care And Cleaning
Care and Cleaning Your sink is manufactured with the highest grade stainless steel and will provide you many years of enjoyment with the proper care . SINK CABINET After use, always rinse your sink with tap water to dilute and Remove dust and dry dirt with a soft, damp cloth . -
Page 12: Service Parts
(Service available in English and French, Monday - Friday from 8:30 am - 5:00 pm EST) . Identify the required part(s) and have the part number(s) ready . Part Description Code Quantity Door Handles QHL182 Door Handle Screws QHL104 Leveling Leg Screws QHL106 Leveling Legs QHL179 Cabinet Hinges QHL102 Ceramic Cartridge QHL166 Sprayer Head QHL181 Strainer Assembly QHL176 Strainer Basket QHL177 QL014... -
Page 13: Manuel De L'utilisateur
Imported by / Importé par : St-Laurent, Québec, H4S 2C3 1-877-333-0098 | cs@conglomkb.com (service available in English and French, Monday - Friday from 8:30 am - 5 pm EST) (service disponible en anglais et français, du lundi au vendredi, 8h30 à 17h, H.N.E.) Made in China / Fabriqué...
