- Page 1 Technical manual...
- Page 3 READ THIS DOCUMENT BEFORE INSTALLING THE HEATER Warning Incorrect installation, adjustment, alteration, repair or maintenance work may lead to material damage or injury. All work must be carried out by certified, qualified professionals. If the appliance is not positioned in accordance with the instructions, the warranty shall be rendered void.
-
Page 4: Technical Specifications
Technical specifications Technical specifications Type MDX 33 MDX 56 Specifications indoor unit Weight Air flow 6600 11200 Sound pressure level (5 mtr.) at max air flow dB(A) Throw Pipe diameter Liquid Ø mm (inch) 12,7 (1/2”) 15,8 (5/8”) Ø mm Power supply Ph/V/(Hz)kW 1/230/(50)0,24... - Page 5 Assembly suggestions Unit Placement and Installation Positioning the appliance After unpacking, check the appliance for damage. Check that the information relating to the type/model and the electrical voltage is correct. Place the appliance and any accessories to a sufficiently solid structure, taking into account the minimum free space required.
- Page 6 3.2.2 Spacing For indoor units to function properly, a sufficient air flow through the heat exchanger must take place. The spacing of the indoor units must take into account that sufficient air may flow through each unit. Figures 3.1 to 3.3 show spacing requirements in three different scenarios.
- Page 7 3.3 Condensate drain (optional) If the Mistral MDX is used for heating only, a condensate drain is not necessary. Type MDX 33 MDX 56 Condensate kg/h Indoor air temperature 27°C and 50% humidity 3.3.1 Condensate drain with natural progression The condensate drain must meet the criteria as described in the manual of the outdoor unit.
-
Page 8: Maintenance
The air diverter plate becomes dirty over time, which affects the functioning. The plate should be cleaned annually or more often if necessary. The Mistral MDX 33 has one diverter plate, the Mistral MDX 56 has two diverter plates. These two diverter plates are connected to each other shown in Figure 4.1. - Page 9 Figure 4.1 Cleaning air diverter plate Replacing a broken condensate pump When the condensate drain pump breaks down, it must be replaced. The location of the pump is shown in the figure. Figure 4.4 Replacing a broken condensate pump...
- Page 10 Positioning sensors Incoming air temperature Average battery temperature Incoming refrigerant temperature Outgoing air temperature Outgoing refrigerant temperature There are five sensors in the Mistral MDX. These are mounted in the places as shown in the Figures 4.5-4.8. If one or more sensors fail, they must be replaced. Sensor T1 can be replaced via the control box.
- Page 11 Figure 4.7 Position sensors When mounting the sensors, it is important that moisture cannot enter the sensors. Figure 4.8 Position sensors...
-
Page 12: Refrigerant Piping
Refrigerant Piping For information about the refrigerant piping, please see the technical manual of the specific Mistral MDX outdoor unit. Control board settings 0-10V Output control The DIP switch numbers of ENC2, ENC3 and ENC4 correspond to different voltage outputs. Depending on the DIP switch numbers of SW1-2, there are two control modes available, which are gear 1 and gear 3 fan speeds, respectively. -
Page 13: Electrical Wiring
Setting the Master/Slave AHU Control Box 1. If multiple AHU control boxes are connected in parallel, the master/slave AHU control box needs to be set through SW2-3 and SW2-4 Figure 6.3 SW2-3 and SW2-4 are 00: master AHU control box 1 234 (factory default) Selection of Controllers... - Page 14 Power Supply Wiring Power supply wiring design and installation should adhere to the following requirements: Separate power supplies should be provided for the indoor unit and outdoor unit. » Installation must comply with the relevant local and/or national regulations. » Communication Wiring Communication wiring design and installation should adhere to the following requirements:...
- Page 15 Wiring example...
- Page 16 Electrical diagram...
- Page 20 FAX +31 (0)598 624584 TELEFAX +49 (0)2822 97728-10 info@mark.nl info@mark.de www.mark.nl www.mark.de MARK EIRE BV MARK POLSKA Sp. z o.o COOLEA, MACROOM UL. JASNOGÓRSKA 27 CO. CORK 42-202 CZĘSTOCHOWA (POLSKA) P12 W660 (IRELAND) PHONE +48 34 3683443 PHONE +353 (0)26 45334...
