Summary of Contents for NSR Marine NRT-1000
- Page 1 USER MANUAL SART NRT-1000 NRT-1000 UM.E 20190712-06...
- Page 3 NOTICE TO USERS Thanks for your purchasing this product NRT-1000 SART. Please read this manual carefully to ensure proper use before installation and use of the NRT-1000 SART. NEW SUNRISE will assume no responsibility for the damage caused by improper use or modification of the product or claims of loss of profit by a third party.
- Page 4 Do not activate the SART unless in case of emergency. If the SART is activated for any reasons, the battery pack in SART should be replaced to maintain enough life of batteries. The red pin should also be replaced because it cannot restore to its right state after being pulled off. NRT-1000 UM.E 20190712-06...
- Page 5 Modify Record Modify by Date Paragraph Version Reason 2014/09/1 Generally modified. 2017/11/24 Wordings modified. 2018/06/12 2, 3 Add black protector. 2018/12/28 Generally modified. 2019/07/12 Generally modified. NRT-1000 UM.E 20190712-06...
-
Page 6: Table Of Contents
CHECK LIST BEFORE DELIVERY ................11 INSPECTION RECORDS （EVERY 6 MONTHS） ..........12 INSPECTION RECORDS （EVERY 6 MONTHS） ..........13 INSPECTION RECORDS （EVERY 5 YEARS） ........... 14 INSPECTION RECORDS （EVERY 5 YEARS） ........... 15 MEMO ..........................16 APPENDIX SIZE DRAWING ................... 18 NRT-1000 UM.E 20190712-06... -
Page 7: Product Outline
NRT-1000 USER MANUAL 1. PRODUCT OUTLINE The Search and Rescue Radar Transponder (SART) is a very simple 9 GHz receiver / transmitter which provides a position. The fundamental function of the SART is to indicate its position by producing range and bearing information on any 9 GHz radar screen of any nearby ship, vessels and aircraft (with no modification). - Page 8 NRT-1000 USER MANUAL In operation, the SART responds automatically using a 9 GHz high-speed frequency sweeping signal with a pulse emission period of 100 ㎲ which is synchronous with any received scanning pulse. The SART response signal scans all frequencies in the 9 GHz radar band.
-
Page 9: How To Activate
NRT-1000 USER MANUAL 2. HOW TO ACTIVATE ① ② ③ ④ 2.1 On vessel When still onboard the vessel, activate SART as below: ⚫ Take off SART from the installation bracket. ⚫ Remove the black protector. ⚫ Pull off the red pin and rotate the operation handle to ON. -
Page 10: In Life Raft
NRT-1000 USER MANUAL 2.2 In life raft Activate SART in life raft as below: ⚫ Keep SART as high as possible by using the telescopic pole supplied or hanging SART in the life raft by using the rope supplied. ⚫... -
Page 11: How To Test
NRT-1000 USER MANUAL 3. HOW TO TEST ⚫ Take off SART from the bracket. ⚫ Hold SART in open space outdoor. ⚫ Remove the black protector. ⚫ Pull off the red pin and rotate the round operation handle to TEST. -
Page 12: How To Mount
NRT-1000 USER MANUAL 4. HOW TO MOUNT SART is mounted with the wall bracket in the bridge. The bracket should be mounted in a vertical position and in a place where SART is easily available in case of an emergency. -
Page 13: Periodic Inspection
NRT-1000 USER MANUAL 5. PERIODIC INSPECTION Periodic inspection is very important to ensure SART in a good condition. Each test should be executed in short time because any test could reduce the life of the batteries. 5.1 Every six months The inspection every six months years should be carried out by operators on board. -
Page 14: How To Replace Battery
Gasket Two cells of batteries All above items are combined into a battery module, NBT100S. NSR guarantees the quality of NRT-1000 SART only when original NBT100S battery module is supplied by NSR. 6.2 Battery Disposal Warning：Lithium batteries should have two terminals insulated prior to disposal because the remained power could cause sever harm to human beings. -
Page 15: Technical Specifications
NRT-1000 USER MANUAL 7. TECHNICAL SPECIFICATIONS ⑴ Work Frequency： 9.2 ~ 9.5GHz ≥400mW ⑵ Carrier Power： ≤-50dBm ⑶ Receiving Sensitivity： ≥5nm ⑷ Communication Coverage： Operating: -20℃ ~ +55℃ ⑸ Temperature range： -30℃ ~ +65℃ Storage: ⑹ Size： 95（d）× 377（h）mm ⑺ Weight：... -
Page 16: Warranty
NRT-1000 USER MANUAL 8. WARRANTY All goods manufactured by NSR are warranted to be free from defect in workmans hip and material for the period of 18 months from the date of delivery (unless stat ed otherwise and confirmed in writings). -
Page 17: Check List Before Delivery
NRT-1000 USER MANUAL CHECK LIST BEFORE DELIVERY Battery： Expiry date： Watertightness verification： Mounting bracket： Transmission test： General operation： USER ID： NEXT INSPECTION DUE ON： Date： Signature and stamp： NRT-1000 UM.E 20190712-06... -
Page 18: Inspection Records （Every 6 Months
NRT-1000 USER MANUAL INSPECTION RECORDS （every 6 months） DATE INSPECTION RESULT INSPECTOR NRT-1000 UM.E 20190712-06... -
Page 19: Inspection Records （Every 6 Months
NRT-1000 USER MANUAL INSPECTION RECORDS （every 6 months） DATE INSPECTION RESULT INSPECTOR NRT-1000 UM.E 20190712-06... -
Page 20: Inspection Records （Every 5 Years
NRT-1000 USER MANUAL INSPECTION RECORDS （every 5 years） Battery replacement： Battery supplier： Model number： New battery expiry date： Old battery disposal： Gasket replacement： Performance test： NEXT INSPECTION DUE ON： Date： Signature and stamp： NRT-1000 UM.E 20190712-06... -
Page 21: Inspection Records （Every 5 Years
NRT-1000 USER MANUAL INSPECTION RECORDS （every 5 years） Battery replacement： Battery supplier： Model number： New battery expiry date： Old battery disposal： Gasket replacement： Performance test： NEXT INSPECTION DUE ON： Date： Signature and stamp： NRT-1000 UM.E 20190712-06... -
Page 22: Memo
NRT-1000 USER MANUAL MEMO NRT-1000 UM.E 20190712-06... - Page 23 NRT-1000 USER MANUAL MEMO NRT-1000 UM.E 20190712-06...
-
Page 24: Appendix Size Drawing
NRT-1000 USER MANUAL APPENDIX SIZE DRAWING NRT-1000 UM.E 20190712-06... - Page 28 Copyright by NEW SUNRISE CO., LTD. (NSR) www.nsrmarine.com info@nsrmarine.com July, 2019...
