Irelcome to the world of the Fatar Studio Series Keyboard Controllers.
Congradulations on purchasing the ST-610 Plus, one of the finest master keyboard
controllers in the world today. The Studio-610 Plus is the perfect choice for a
musician looking for a simple yet versatile keyboard controller to produce quality
results for the live or studio environment.
TECHNICAL CHARACTERISTICS:
* 6l weighted keys
* One zone
* Velocity Sensitive and aftertouch
* Pitch Bend Wheel and Programmable Wheel
* Two Parallel MIDI Outputs
* Sustain Input Jack
"'Volume Input Jack
* Program change, MIDI Channel, Transpose, Programmable wheel (Volume, Pan,
Aftertouch, Pitch, Modulation) etc.
* External Adapter 9V DC 500mA included
CONNECTIONS:
1) Connect the DC adapter cable to the power input jack, in the back of the
controller, located next to the power switch. See Figure #1.
Figure #1.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fatar ST-610 Plus
Summary of Contents for Fatar ST-610 Plus
- Page 1 Irelcome to the world of the Fatar Studio Series Keyboard Controllers. Congradulations on purchasing the ST-610 Plus, one of the finest master keyboard controllers in the world today. The Studio-610 Plus is the perfect choice for a musician looking for a simple yet versatile keyboard controller to produce quality results for the live or studio environment.
- Page 2 Plus. Each channel would normally be assigned to a different sound or effect. Since the ST-610 Plus has only one zone, you can only program one of thel6 channels at a time. Make sure that your sound source is properly assigned to the channel you are sending on.
- Page 3 Many expensive keyboard controllers offer aftertouch, which allows expressive control of sound sources. The ST-610 Plus allows the same expression via [WHEEL A]. Aftertouch, pitch, (1 through 16). Refer to the sound source s owners manual for this procedure.
- Page 4 Sometimes you might get undesirable results. At this point it might be best to reset your sound source (see sound sources owners manual) and shut off the ST-610 Plus, then turn it back on again. This will reset the ST-610 Plus to base channel #1, the control wheel to modulation and no transposition.
- Page 5 CONTROLLER NUMBER 12-15 20-31 33-63 70-7 84-91 98-121 Refer to a MIDI technical handbook for further information on these controller functions. CONTROLLER FUNCTION Bank Modulation Breath controller Undefined Foot controller Portamento rate Data Entry MSB Volume Balance Undefined Expression Undefined Gen'l Purpose #1 Gen'l Purpose #2 Gen'l Purpose #3...
- Page 6 Transposition: Sometimes a player may not be able to play in a certain key. At these times the [TRANSPOSE] switch will be invaluable. For example, if you need to change from the key of C major to the key of Eb major, you can still play the C major keys, but what you hear would be Eb major.
