DH-ITSE0804-GN5B-D ITC Terminal
Management Device
User's Manual
Version 1.1.1
Dahua Technology CO., LTD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DH-ITSE0804-GN5B-D and is the answer not in the manual?

Questions and answers

Summary of Contents for Dahua Technology DH-ITSE0804-GN5B-D

  • Page 1 DH-ITSE0804-GN5B-D ITC Terminal Management Device User's Manual Version 1.1.1 Dahua Technology CO., LTD...
  • Page 2 Safeguards and Warnings Please read the following safeguards and warnings carefully before using the product in order to avoid damages and losses. Note:  Do not expose the device to lampblack, steam or dust. Otherwise it may cause fire or electric shock.

  • Page 3: Table Of Contents

    Table of Contents Safeguards and Warnings ....................... ii Product Overview ........................1 Overview ........................1 Features ........................1 Product Structure ........................3 Front Panel ......................... 3 Rear Panel ......................... 3 HDD Note ........................4 System Networking ........................6 Local Operation ........................7 View Video .........................

  • Page 4: Product Overview

    1 Product Overview 1.1 Overview This product is a high-performance outdoor intelligent terminal management device, mainly used to receive transmission of front camera video and pictures, set the video management, data management, real-time storage, picture display and network switching functions into one. The products are widely used in various road safety monitoring system and channel monitoring system to a variety of ways of device storage, storage platforms and PC client storage.
  • Page 5 COM Interface RS485 interface, RS232 interface Dual network multi-address, fault-tolerant, load balance config. 8 100M industrial-level switching network interfaces, integrating switching function. 2 1000M network interfaces, one is 1000M SFP interface which can do photoelectric conversion.

  • Page 6: Product Structure

    2 Product Structure 2.1 Front Panel Figure 2- 1 Indicator has three statuses, including NO, NC and flashing. Interface Name Function Indicator NO green, as program is running  Operation normally.  Indicator flash green, as program is upgrading. Indicator flash green, as reading HDD. ...

  • Page 7: Hdd Note

    Interface Name Function Restore default settings. Note RESET Reset button Under device normal working, power indicator is green. Hole this button for 10s, system will restore default settings. +12V Power output interface POWER OUT Input GND A1, B1 A2, B2 RS485 interface Reserved, 4 RS485 interfaces A3, B3...
  • Page 8 Total HDD capacity（M） Record time（hour）= HDD occupation per hour (M/h) * channel number Note: ITC terminal management device adopts H.264 compression technology, which has big dynamic range, and HDD capacity calculation is based on stream estimation of file generated by each channel per hour.

  • Page 9: System Networking

    3 System Networking In the networking system of the product, central server and monitoring spot (location of front-end camera) need to be connected to Ethernet at the same time, while there is no need of video line between center and monitoring spot. Figure 3- 1 ITC management device is used to store HD encoded video and picture send by HD camera, to save all passed vehicle data, and upload to central server for management.

  • Page 10: Local Operation

    4 Local Operation You can view channel video and picture via monitor locally. The device supports connection to monitor via VGA port, connection to mouse via USB port, when successfully connect and boot up the device, the monitor shows local interface, default is video interface.

  • Page 11: View Picture

    Figure 4- 2 4.2 View Picture If you view a single channel picture, you can click Picture, and click a channel. Channel color changes from as you can view channel picture. Details of the picture will be shown below the window. The following is an example of 1-window, see Figure 4- 3.
  • Page 12 Figure 4- 3 Click History Picture, you can view picture history. Local display supports up to 1000 pictures and over 1000 pictures system will auto overwrite old pictures.

  • Page 13: Web Client

    5 WEB Client 5.1 Intro The device supports WEB page access and device management on PC client. WEB client provides preview, search, setup and alarm modules. 5.2 System Login 5.2.1 Network Connection Step 1. Confirm device is correctly connected into the Internet. Step 2.

  • Page 14: Preview

    Figure 5- 2 Note: To logout WEB page, click Logout. 5.3 Preview 5.3.1 Preview Video and Picture Step 1. Click Preview. Step 2. Click one channel. System shows current channel’s video and snapshot. Note: If there is no video or picture in this channel, please confirm front-end camera and the device’s record and snapshot function are ON.

  • Page 15: Preview Video

    Figure 5- 3 In video window, you can press the following buttons. When button color is ON, it means corresponding operation is in effect. Button Icon Button Name Button Function ，button color change to Click Red box select the area to zoom in Zoom In ，...

  • Page 16: Preview Picture

    Figure 5- 4 If you want to switch window mode, you can click , as these functions are: full-screen, 1-window, 4-window, 9-window, 16-window. Step 3. Click , click Open All to switch to 16-window. System opens all monitoring channels, you can preview all these channel info. You can click Close All to close channels.

  • Page 17: Search

    Figure 5- 5 If you want to switch window mode, you can click , as these functions are: full-screen, 1-window, 4-window, 9-window, 16-window. Step 4. Click , click Open All to switch to 16-window. System opens all monitoring channels, you can preview all these channel info. You can click Close All to close channels.

  • Page 18: Search Vehicle Picture

    Figure 5- 6 5.4.1 Search Vehicle Picture You can search snapshot vehicle picture via time, picture type, seed and plate no. Step 1. Click Car. Step 2. Set search filter according to the following parameters. Click Search Parameter Note Start Time Select search start time.

  • Page 19: Search Video

    Figure 5- 7 Step 3. Select download type, according to system prompt download to local.  By File: in search result, check one or more pictures, click download.  By Time: download all pictures within period from searched start time to end time, click download.

  • Page 20: Setup

    Figure 5- 8 Step 3. Double click search result, system will auto play the record. You also can click play bar menu to stop, quick play and play record. Step 4. Check record, select download type, according to system prompt, download record to local.
  • Page 21 Figure 5- 9 5.5.1.1 Snapshot Combination You can set channel snapshot combination method. Step 1. Select>Intelligent Traffic>Snapshot Combination, see Figure 5- 10.
  • Page 22 Figure 5- 10 Step 2. Check Enable, enable snapshot combination function. After this function is enabled, system will save the original snapshot picture by default. Step 3. Check “upload original picture”, device not only can receive snapshot original picture, but also can receive the combined picture.
  • Page 23 Parameter Note Picture According to picture numbers, set combined picture size. Combination Resolution Step 5. Click Copy, in pop-up window, copy the snapshot combination setup to other channel, Click Save. Step 6. Click Save, it takes effect. If you want to restore default setup, please click Default. 5.5.1.2 Combination OSD You can combine speed, plate, time, address and etc.

  • Page 24: Analog Camera

    Figure 5- 12 Step 2. Check Enable, enable transfer offline function. Step 3. Select platform and input platform IP address. Step 4. Click Save, it takes effect. If you want to restore default setup, please click Default. 5.5.1.4 Allowlist/Blocklist  Blocklist refers to alarm settings open blocklist alarm when it detects the presence of a vehicle in the blocklist will be alarm can be set up 10,000 records.
  • Page 25 Figure 5- 13 Step 1. Select Analog Camera>Video. See Figure 5- 15. Figure 5- 14 Step 2. Refer to the following chart. Click Save. Parameter Note Analog Channel Select corresponding analog channel. Stream Type May select general. Encode Mode May select H.264M, H.264B or H.264H Resolution Front-end device encode setup, support D1（704*576）, HD1 （352*576）, CIF（352*288）...

  • Page 26: Network

    Figure 5- 15 Step 4. Click Save, it takes effect. If you want to restore default setup, please click Default. 5.5.3 Network 5.5.3.1 TCP/IP The TCP/IP interface is shown as in Figure 5- 17.TCP/IP module mainly set device IP address, support IPv4, Ipv4 supports static IP and DHCP dynamic to get IP.
  • Page 27 Parameter Function Host name Set current host name. Max supports 15 characters. Ethernet card Set Ethernet card to config. Default is wired. You can select from static and DHCP mode. In DHCP mode, it automatically searches IP while you cannot set IP/subnet mask/gateway. Plus IP/subnet Mode mask/gateway display values from DHCP.
  • Page 28 Step 3. Click Add IP, in the pop-up box, input IP address or IP segment, Click Save. Step 4. Check Enable, Click Save. 5.5.3.4 Auto Register After auto register is enabled, device automatically registers to management server, and you can preview and monitor device on server.

  • Page 29: Event

    Figure 5- 19 Step 2. Select one channel, check Enable. Step 3. According to actual condition, select protocol type. Available protocols are Onvif, Provate, RTSP. Note: customize RTSP main stream URL, default format rtsp://[username]:[password]@[ip]:[port]/cam/realmonitor?channel=1&subtype=0 Step 4. Input camera IP address, port, username, password and device location. You can click System Config to view camera system info.
  • Page 30 Figure 5- 21 Step 2. Refer to the following chart. Parameter Note Enable When checked, the system will detect the alarm signal Relay-in Select the appropriate alarm channel number, support up to four alarm inputs Working Period Set the alarm time period, within the time frame set will start alarm recording.

  • Page 31: Storage

    Figure 5- 22 Figure 5- 23 Step 2. Check Enable, and set hard disk lower limit and other parameters. Step 3. Click Save. 5.5.4.3 Alarm I/O Step 1. Select Event>Alarm I/O, see Figure 5- 26. Figure 5- 24 Step 2. Refer to the following chart. Parameter Note Relay-out...
  • Page 32 Figure 5- 25 5.5.5.1 Local Storage Local storage refers to data stored in the device's hard drive, you can query the device hard disk capacity, set drive properties. If the device is installed multiple hard drives, hard disk storage can be individually set for the video and pictures.
  • Page 33 Figure 5- 27 Step 2. Refer to the following chart. Parameter Note Enable After checked, enable FTP server. Encoding Two encoding format, as UTF-8 and GB2812. Test Click “Test”, if FTP server connects successfully or not. System will generate test file according to selected encoding format. Server Address FTP server IP address Port...
  • Page 34 Parameter Note Related Video You can customize event time range, unit is second. Time FTP Naming You can set naming method of picture and record, if you need help, click Help. Step 3. Click Save. Step 4. You can set other FTP server in the same way. Note: The same violation type cannot be uploaded on more than two FTP servers.
  • Page 35 Parameter Note Record Mode Set each channel’s record mode: Main stream：According to period in record setup, under main  stream it auto records.  Second stream：According to period in record setup, under sub stream it auto records. Off：Turn off record function ...

  • Page 36: System

    Step 5. Click Copy, you can copy record schedule of current channel to other channel. Step 6. Click Save. 5.5.5.5 Snapshot Snapshot is to enable each channel’s snapshot function, select related record channel. Step 1. Select Storage> Snapshot, see Figure 5- 33. Figure 5- 31 Step 2.
  • Page 37 Parameter Note Input device no., if there are multiple devices, you need to make Device No. sure the device no. is exclusive. Language Select language to display. Video Standard Video standard, such as PAL. Figure 5- 33 Parameter Note Date Format Select the desired display corresponding date display format Time Format Select the time format to be displayed...
  • Page 38 5.5.6.2 Local Setting You can click Browse, set PC client picture and record storage path. See Figure 5- 36. Figure 5- 34 Default snapshot path is: C:\PictureDownload Default record path is: C:\RecordDownload 5.5.6.3 Account You can add, delete and modify user group and user info, but you cannot set right. ...

  • Page 39: System Info

    Figure 5- 36 5.5.6.5 Import/Export You can export all config to local, or import local config into the system. Figure 5- 37 5.5.6.6 Auto Maintain You can set auto reboot time and period, default is 02:00 every day. See Figure 5- 40. Figure 5- 38 5.5.7 System Info You can view system version, log and online user info.
  • Page 40 Figure 5- 39 5.5.7.1 Version You can view device version, port and SN info. See Figure 5- 42. Figure 5- 40 5.5.7.2 Log You can search system and user log via time and type. Max supports 1024 logs, when quantity of log exceeds 1024, system will overwrite log. See Figure 5- 43.
  • Page 41 Figure 5- 41 Parameter Note Start Time Start time of log you want to search. End Time End time of log you want to search. Type Log info type are system, settings, data, event record and etc. Click "Search", dynamic display search number, click "Stop" to Search suspend log search, displays search several regions and time periods...

  • Page 42: Alarm

    Figure 5- 43 5.5.7.5 Smart Info It displays hard disk auto check result, and when it detects potential error in HDD, it will record in this page. Note: When state is fault, please change hard disk to avoid data loss. See Figure 5- 46.
  • Page 43 Figure 5- 45 Parameter Note Check Disk-Full, so alarm when disk is full.  Check Loop/Detector Malfunction, so alarm when loop/detector  has malfunction. Alarm Type Check Blocklist, so alarm when blocklist occurs.   Check External Alarm, then alarm when corresponding event occurs.

  • Page 44: Quick Configuration Tool

    6 Quick Configuration Tool 6.1 Overview Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it to upgrade the device. Please note the tool only applies to the IP addresses in the same segment. 6.2 Operation Double click the “ConfigTools.exe”icon, you can see an interface is shown as in Figure 6- 1.
  • Page 45 Figure 6- 2 Select the “Open Device Web” item; you can go to the corresponding web login interface. See Figure 6- 3. Figure 6- 3 If you want to modify the device IP address without logging in the device web interface, you can go to the configuration tool main interface to set.
  • Page 46 Figure 6- 4 After you logged in, the configuration tool main interface is shown as below. See Figure 6- 5. Figure 6- 5 For detailed information and operation instruction of the quick configuration tool, please refer to the Quick Configuration Tool User’s Manual included in the resources CD.

  • Page 47: Faq And Maintenance

    7 FAQ and Maintenance 7.1 FAQ Question Possible Cause and Solution 1. The input power is not correct. 2. Switching power line contact is not good. 3. He switching power supply damaged. No response after power up 4. Program upgrade error. 5.

  • Page 48: Maintenance

    1. The network is not good patency. Record file playback has 2. Whether the client resource constraints. mosaic or no image 3. The user is logged no monitoring authority. 1. Network instability. 2. IP address conflicts. Unstable network connection 3. MAC address conflicts. 4.
  • Page 49 voltage device damage. Do not hot plug RS232, RS485 interfaces, or likely to damage the port.  When the device is turned off, do not turn off the power switch, use the off button on the front  panel (pressing more than 5 seconds), the device automatically turn off the power, to avoid damage to the hard disk.
