- Page 18 Digital Weight Indicator Setup / Operation Manual Revision 1.0 July 8, 2009...
-
Page 19: Table Of Contents
©Totalcomp, Inc. 2009. All rights reserved. The information contained herein is the property of Totalcomp and is supplied without liability for errors or omissions. No part may be reproduced or used except as authorized by contract or other written permission. The copyright and the foregoing restriction on reproduction and use extend to all media in which the information may be embodied. -
Page 20: Introduction
INTRODUCTION The T500ESS Digital Indicator is a general purpose, industrial grade weight indicator. One model is currently available, distinguishable by display type, enclosure type and power supply. Table 1 shows the T500ESS product matrix. This model can readout up to 50,000 display divisions and can supply enough current for up to 4-350 load cells. -
Page 21: Connections
Environment Avoid installing the indicator in areas of direct sunlight or high humidity Avoid sudden temperature change – if this is unavoidable allow equipment to ‘soak’ at a constant temperature for at least three hours before use Ensure that steady, clean AC power is available to the unit Remember that the installer is ultimately responsible to assure that a particular installation will be and remain safe and operable under the specific conditions encountered. -
Page 22: Connecting The Power Supply
CONNECTING THE POWER SUPPLY The TI-500E-SS indicator ships with an AC line cord attached to the indicator. Simply plug the unit into a standard wall outlet. CONFIGURATION OVERVIEW The indicator contains two main configuration menus: The Setup (“F”) menu, which configures the indicator to your weigh platform The User (“A”) menu, which configures the serial communication port and enables some user options The Setup and User menus consist of several menu selections, each with its own sub-menu of selections... - Page 23 Use the directional keys to move around in the Menu Structure shown below. Etc. Grads Sampling Numeric Entry To move to a new heading, use the TARE (left) or PRINT (right) key to move right or left in the Menu. To move to the selection or programming level, press the ZERO (down) key once.
-
Page 24: Setup Menu Descriptions
SETUP MENU DESCRIPTIONS This section provides more detailed descriptions of the selections found in the Setup Menu Chart. Factory-set defaults are shown in bold; (NA) for North America and ( ) for Europe. € NOTE: Some selections are subject to local legal metrology regulations CODE/NAME DESCRIPTION SELECTION LIST... - Page 25 CODE/NAME DESCRIPTION SELECTION LIST Allows the lb/kg key to be disabled so that an operator cannot 0 (€) accidentally press the key and change the displayed units. Units 1 (NA) Conversion "0" = Disable the Units key "1" = Enable the Units key Places indicator into the zero calibration routine.
-
Page 26: Setup Menu Procedures
CODE/NAME DESCRIPTION SELECTION LIST Selects the minimum weight at which the auto print function will work Key-in Auto Print Min. if enabled. Selections are in display divisions (d). Scrolling down with 0 - 100 the ZERO key one level begins the procedure. Weight 1 (NA/€) “0”... -
Page 27: User Menu Descriptions
USER MENU DESCRIPTIONS This section provides more detailed descriptions of the selections found in the User Menu Chart. Factory-set defaults are shown in bold; (NA) for North America and ( ) for Europe. € CODE/NAME DESCRIPTION SELECTION LIST Selects the baud rate for data transmission through the serial port. 300, 600, 1200, 2400, 4800, Baud Rate... -
Page 28: User Menu Procedures
USER MENU PROCEDURES This section provides instructions for all of the User Menu procedures. ID Number Entry (A8) 1. While in the User Menu mode, scroll to "A 8", then scroll down once using the ZERO key to enter the ID Number menu. 2. -
Page 29: Calibration
If your indicator was shipped as a complete scale, then calibration is not necessary. Please check with your installer or supplier if you are unsure. Totalcomp recommends having your weighing equipment checked by a qualified scale technician at least once a year depending on its intended use and working environment. -
Page 30: View Calibration Values (F18)
6. At this time it is suggested that the calibration values be recorded for future use (see next section). If the calibration was not successful, one of the error messages below will appear. Take the indicated action to correct the problem, then perform a new calibration. "Err0"... -
Page 31: Key-In Zero Calibration Value (F19)
KEY-IN ZERO CALIBRATION VALUE (F19) Note: This procedure is intended for emergency use only in the case of non-volatile memory loss. A valid zero calibration value, obtained from a successful F16 calibration procedure, must be used. 1. While in the Setup mode, scroll to "F 19", then scroll down once using the ZERO key. The display will momentarily show "ET C 0", followed by a value of zero 2. -
Page 32: Operation
OPERATION DISPLAY This model utilizes a 6-digit LED (Light Emitting Diode) display. Table 4 summarizes the display annunciators. GROSS TARE ZERO STABLE MEANING Annunciator ZERO Better known as the “Center of Zero” annunciator, this light is active whenever the displayed weight is within a pre-programmed band from true zero. -
Page 33: Function Keys
FUNCTION KEYS Units – This key toggles the indicator among the available weight units if enabled in the User (“A”) menu. Available weight units include lb, kg and pieces.. Zero - This key sets the indicator to display zero provided the following conditions are met: 1. -
Page 34: Peak Hold Mode
1. If the items you will be counting require a container, you must first tare the container off by pressing the TARE key. NOTE: The TARE key is inoperative when in sampling mode. 2. Press the UNITS key until “5 0” is indicated on the display. If the screen does not show “5 0”, press the ZERO key once. -
Page 35: Legal For Trade Sealing
LEGAL FOR TRADE SEALING Indicators can be sealed for commercial (Legal for Trade) applications as follows. 1. Power off the indicator. 2. On the back of the indicator, locate the setup/calibration switch cover. 3. Thread a wire security seal through both drilled head screws securing the calibration switch cover as well as the single drilled head screw holding on the rear panel. -
Page 36: Appendix A: Specifications
APPENDIX A: SPECIFICATIONS ANALOG SPECIFICATIONS Full Scale Input Signal ±3.125 mV/V Minimum Sensitivity - Non trade 0.3 V / grad Minimum Sensitivity - H-44/R76 0.6 V / grad Input Impedance 30M , typical Internal Resolution Approximately 260,000 counts @ 2mV/V input Display Resolution 50,000 display division max Measurement Rate... -
Page 37: Appendix B: Serial Port Information
APPENDIX B: SERIAL PORT INFORMATION SERIAL PORT MODES DEMAND DUPLEX MODE The Demand Duplex Mode provides a two way serial transmission mode In this mode, the output information is transmitted on demand; either by pressing the PRINT key on the indicator’s front panel or upon receiving a recognized command from a host device (i.e. -
Page 38: Output Strings
OUTPUT STRINGS TEXT PRINT TICKET The Text Print Ticket is designed specifically for a serial printer. ID. NO. 123456 GROSS 25.00 LB TARE 1.48 LB 23.52 LB NOTES: 1. The TARE and NET fields are not printed unless a tare has been established in the system. -
Page 39: Appendix C: Displayed Error Codes
APPENDIX C: DISPLAYED ERROR CODES CODE MODE MEANING / POSSIBLE SOLUTION Normal Operating Gross Overload. A weight greater than the rated capacity has been Mode applied to the scale. Remove the weight from the platter or try re- calibrating the scale. Otherwise, check for a bad load cell connection or possible load cell damage due to overloading.
