Published 08/23

This Operator's Manual is an integral part of the safe operation of this machine and

must be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW

the Safety and Operation Instructions contained in this manual before operating the

equipment.

BUSH HOG

2501 Griffin Ave.

Selma, AL 36703

334-874-2700

www.bushhog.com

OPERATOR'S MANUAL

C01-Cover str

BSE-1, BSSS-1

BSSS-2, BSSS-3

BALE SPEAR

Models

Part No.50084019

Table of Contents

Need help?

Do you have a question about the BSE-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bush Hog BSE-1

Page 1 Models BSE-1, BSSS-1 BSSS-2, BSSS-3 BALE SPEAR Published 08/23 Part No.50084019 OPERATOR’S MANUAL This Operator's Manual is an integral part of the safe operation of this machine and must be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety and Operation Instructions contained in this manual before operating the equipment.
Page 2 To the Owner/Operator/Dealer All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
Page 3: Table Of Contents
Table of Contents SAFETY SECTION ..................1 - 1 GENERAL SAFETY INSTRUCTIONS AND PRACTICES................1 - 2 OPERATOR SAFETY INSTRUCTIONS AND PRACTICES ................1 - 4 EQUIPMENT OPERATION SAFETY INSTRUCTIONS AND PRACTICES ............ 1 - 5 CONNECTING OR DISCONNECTING IMPLEMENT SAFETY INSTRUCTIONS AND PRACTICES ..1 - 10 MAINTENANCE AND SERVICE SAFETY INSTRUCTIONS AND PRACTICES .........
Page 4 Table of Contents BALE SPEAR PRE-OPERATION INSPECTION ..................4 - 15 OPERATING THE TRACTOR AND IMPLEMENT..................4 - 17 Picking up a Bale............................. 4 - 17 Traveling with a Load ..........................4 - 18 Placing the Bale............................4 - 19 Unhooking the Bale Spear ........................
Page 6: General Safety Instructions And Practices
SAFETY GENERAL SAFETY INSTRUCTIONS AND PRACTICES A careful operator is the best operator. Safety is of primary importance to the manufacturer and should be to the owner/operator. Most accidents can be avoided by being aware of your equipment, your surroundings, and observing certain precautions.
Page 7 SAFETY Never allow children to operate, ride on, or come close to the Tractor or Implement. Usually, 16-17 year-old children who are mature and responsible can operate the implement with adult supervision, if they have read and understand the Operator’s Manuals, been trained in proper operation of the tractor and Implement, and are physically large enough to reach and operate the controls easily.
Page 8: Operator Safety Instructions And Practices
SAFETY OPERATOR SAFETY INSTRUCTIONS AND PRACTICES Never operate the Tractor or Implement until you have read and completely understand this Manual, the Tractor Operator’s Manual, and each of the Safety Messages found in the Manual or on the Tractor and Implement.
Page 9: Equipment Operation Safety Instructions And Practices
SAFETY Use extreme caution when getting onto the Implement to perform repairs, maintenance and when removing accumulated material. Only stand on solid flat surfaces to ensure good footing. Use a ladder or raised stand to access high spots which cannot be reached from ground level.
Page 10 SAFETY BEFORE leaving the tractor seat lower the implement, set the parking brake and/or set the tractor transmission in parking gear, disengage the PTO, stop the engine, remove the key, and wait for all moving parts to stop. Place the tractor shift lever into a low range or parking gear to prevent the tractor from rolling.
Page 11 SAFETY For added safety when lifting loads above the height of the operator, install a certified Falling Object Protective Structure. Shiftable loads, round bales, large loose items, and loader attachments can fall toward the operator resulting in serious injury or death. Falling Object Protective Structure (FOPS) rated Cab may be obtained from the tractor dealer or other sources.
Page 12 SAFETY Carry the loader and attachment low when transporting to reduce the potential of the tractor tipping over. Transport on slopes only at slow speeds and use gradual turning angles. Tractor wheel contact with any wash out, drop off or ground obstruction with a raised loader could result in the tractor tipping over and causing serious injury.
Page 13 SAFETY Know before you DIG. Call 888-258-0808 and request that all buried utilities locations be identified before digging in unfamiliar ground. Do not let the loader or attachment contact buried electrical power lines, utilities, or gas lines. Contact with electrical power lines can result in serious bodily injury or electrocution.
Page 14: Connecting Or Disconnecting Implement Safety Instructions And Practices
SAFETY Your driving vision may be reduced or impaired by the tractor, cab, or implement. Before driving on public roadways identify any limited vision areas, and make adjustments to your operating position, mirrors, and the implement transport position so that you can clearly see the area where you will be traveling, and any traffic that may approach you.
Page 15: Maintenance And Service Safety Instructions And Practices
SAFETY MAINTENANCE AND SERVICE SAFETY INSTRUCTIONS AND PRACTICES READ, UNDERSTAND, and FOLLOW the following Safety Messages. Death or serious injury may occur unless care is taken to follow the warnings and instructions stated in the Safety Messages. Always use good common sense to avoid hazards. (SG-2) str Always maintain the safety signs in good readable condition.
Page 16 SAFETY Avoid contact with hot surfaces including hydraulic oil tanks, pumps, motors, valves and hose connections. Relieve hydraulic pressure before performing maintenance or repairs. Use gloves and eye protection when servicing hot components. Contact with a hot surface or fluid can cause serious injury from burns or scalding.
Page 17: Operator Safety Instructions And Practices
SAFETY OPERATOR SAFETY INSTRUCTIONS AND PRACTICES Never operate the Tractor or Implement until you have read and completely understand this Manual, the Tractor Operator’s Manual, and each of the Safety Messages found in the Manual or on the Tractor and Implement.
Page 18: Equipment Operation Safety Instructions And Practices
SAFETY Use extreme caution when getting onto the Implement to perform repairs, maintenance and when removing accumulated material. Only stand on solid flat surfaces to ensure good footing. Use a ladder or raised stand to access high spots which cannot be reached from ground level.
Page 19 SAFETY Do not mount or dismount the Tractor while the tractor is moving. Mount the Tractor only when the Tractor and all moving parts are completely stopped. Dismounting a moving power unit can result in a crushing hazard that can cause death or serious injury.
Page 20: Connecting Or Disconnecting Implement Safety Instructions And Practices
SAFETY Your driving vision may be reduced or impaired by the tractor, cab, or implement. Before driving on public roadways identify any limited vision areas, and make adjustments to your operating position, mirrors, and the implement transport position so that you can clearly see the area where you will be traveling, and any traffic that may approach you.
Page 21 SAFETY Periodically inspect all moving parts for wear and replace when necessary with authorized service parts. Look for loose fasteners, worn or broken parts, and leaky or loose fittings. Make sure all pins have cotter pins and washers. Serious injury may occur from not maintaining this machine in good working order.
Page 22: Transporting Safety Instructions And Practices
SAFETY TRANSPORTING SAFETY INSTRUCTIONS AND PRACTICES Make certain that the “Slow Moving Vehicle” (SMV) sign is installed in such a way as to be clearly visible and legible. When transporting the Equipment use the Tractor flashing warning lights and follow all local traffic regulations.
Page 23: Parts Information
These parts are made and tested to Bush Hog specifications. Non-genuine "will fit" parts do not consistently meet these specifications. The use of “will fit” parts may reduce equipment performance, void warranties, and present a safety hazard. Use genuine Bush Hog parts for economy and safety.
Page 24: Decal Location
SAFETY DECAL LOCATION NOTE: Bush Hog supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in shipping, use, or reconditioning. Bush Hog cares about the safety of its customers, operators, and bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).
Page 25 MODEL BSSS-1 50084017 MODEL BSSS-2 50084018 MODEL BSSS-3 50083392 LOGO Bush Hog - Model BSE-1, BSSS-1 50083387 LOGO Bush Hog - Model BSSS-2, BSSS-3 SERIAL PLT Serial Plate Number D960 WARNING Prop 65 Warning BSSS/BSE Bale Spear 08/23 Safety Section 1-21...
Page 28 SAFETY FEDERAL LAWS AND REGULATIONS This section is intended to explain in broad terms the concept and effect of federal laws and regulations concerning employer and employee equipment operators. This section is not intended as a legal interpretation of the law and should not be considered as such. Employer-Employee Operator Regulations U.S.
Page 30 INTRODUCTION These bale spears are designed with care and built with quality materials by skilled workers. Proper assembly, maintenance, and operating practices, as described in this manual, will help the owner/operator get years of satisfactory service from the machine. The purpose of this manual is to familiarize and instruct. This manual is intended for all models, but will show specific pictures and diagrams of the BSSS-2 bale spear.
Page 31 INTRODUCTION The Bush Hog BSSS-1, BSSS-2, BSSS-3, and BSE-1 have uses and applications in farming and ranching. They have the capability of quickly and conveniently turning your Skid Steer loader or Tractor loader equipped with a Skid Steer adapter plate. It is designed to move large bales of hay or straw.
Page 32: Attention Owner/Operator
NOTE: Warranties are honored only if completed “Owner Registration and Warranty” forms are received by Bush Hog within thirty days of delivery of the implement. 3. Record the Model and Serial Numbers on the Warranty page at the front of the Operator’s Manual. Keep this as part of the permanent maintenance file for the implement.
Page 33 5. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident. 6. If parts not made or supplied by Bush Hog have been used in connection with the unit, if, in the sole judgment of Bush Hog such use affects its performance, stability or reliability.
Page 36: Assembly
ASSEMBLY ASSEMBLY Your Bush Hog Bale Spear is fully assembled at the factory. Upon receipt, the operator must make sure all nuts and or bolts are properly torqued before use of attachment. Refer to “Torque Chart” in the Maintenance Section of this manual.
Page 38 BUSH HOG BALE SPEAR OPERATING INSTRUCTIONS Your Bush Hog Series Skid Steer Bale Spear should now be assembled and inspected for any evidence of defective or damaged parts before use. Any evidence of damage should be reported to your dealer immediately.
Page 39: Standard Equipment And Specifications
OPERATION 1. STANDARD EQUIPMENT AND SPECIFICATIONS BSSS-1 Specifications Overall Width 45” Overall Length 52” Overall Height 19” Overall Approximate Weight 135 lb. Bale Spear Length and Quantity 49” x 1 Bale Spear Socket Conus 2 Bale Spear Rating (Each) 4,046 lbs Front of socket to load point is 19.68”...
Page 40 OPERATION BSSS-2 Specs with Optional Extensions Overall Width 50.75” Overall Length 51” Overall Height 54” Overall Approximate Weight 224 lb. Bale Spear Length and Quantity 49” x 2 Bale Spear Socket Conus 2 Bale Spear Rating (Each) 4,046 lbs Front of socket to load point is 19.68” BSSS/BSE Bale Spear 08/23 Operation Section 4-4 ©...
Page 41 OPERATION BSSS-3 Specs with Optional Extensions Overall Width 50.75” Overall Length 42” Overall Height 54” Overall Approximate Weight 232 lb. Bale Spear Length and Quantity 39” x 3 Bale Spear Socket Conus 2 Bale Spear Rating (Each) 4,046 lbs Front of socket to load point is 19.68” BSSS/BSE Bale Spear 08/23 Operation Section 4-5 ©...
Page 42 Bale Spear Length and Quantity 39” x 3 Bale Spear Socket Conus 2 Bale Spear Rating (Each) 4,046 lbs Front of socket to load point is 19.68” BSE-1 Specifications Overall Width 42” Overall Length 50” Overall Height 21” Overall Approximate Weight 121 lb.
Page 43: Operator Requirements
OPERATION 2.OPERATOR REQUIREMENTS Safe operation of the unit is the responsibility of a qualified operator. A qualified operator has read and understands the implement and tractor Operator’s Manuals and is experienced in implement and tractor operation and all associated safety practices. In addition to the safety messages contained in this manual, safety signs are affixed to the implement and tractor.
Page 44: Tractor Requirements
OPERATION 3. TRACTOR REQUIREMENTS The tractor used to operate the Bale Spear must have the power capacity to lift, pull, and operate. The rated speed while traveling at a ground speed is between 2 and 5 MPH. Operating the Bale Spear with a tractor that does not meet the following requirements may cause tractor or Bale Spear damage and be a potential danger to the operator and passersby.
Page 45: Getting On And Off The Tractor
OPERATION 4. GETTING ON AND OFF THE TRACTOR Before getting onto the tractor, the operator must read and completely understand the implement and tractor operator manuals. If any part of either manual is not completely understood, consult an authorized dealer for a complete explanation.
Page 46: Starting The Tractor
OPERATION 5.STARTING THE TRACTOR The operator must have a complete understanding of the placement, function, and operational use of all tractor controls before starting the tractor. Review the tractor operator’s manual and consult an authorized dealer for tractor operation instructions if needed. Essential Tractor Controls: •...
Page 47: Skid Steer And Tractor Hook-Up
OPERATION 6. SKID STEER AND TRACTOR HOOK-UP A crushing hazard exists when hooking-up attachments. DO NOT allow anyone to stand be- tween the Skid Steer/Tractor and the attachment itself. DO NOT operate hydraulic controls while someone is near the Skid Steer/Tractor or attachment. 6.1 Attaching BSSS to Loader Use caution when connecting the attachment to the machine.
Page 48: Attaching Bse To Loader
OPERATION 6.2 Attaching BSE to Loader Use caution when connecting the attachment to the machine. Keep hands and feet from un- der the attachment and machine. Do not allow anyone to stand between the machine and bale spear during attachment process. 1.
Page 49: Pre-Operation Inspection And Service
OPERATION 7. PRE-OPERATION INSPECTION AND SERVICE Before each use, a pre-operation inspection and service of the implement and power unit must be performed. This includes routine maintenance and scheduled lubrication, inspecting that all safety devices are equipped and functional, and performing needed repairs. Do not operate the implement and power unit it the pre- operation inspection reveals any condition affecting safe operation.
Page 50: Implement Pre-Operation Inspection/Service
OPERATION 7.2 Implement Pre-Operation Inspection/Service Before each implement use, a complete inspection and service is required to ensure the implement is in a good and safe working condition. Damaged and/or broken parts should be repaired and/or replaced immediately. To ensure the implement is ready for operation, conduct the following. OPS-T-0002 str The operator’s manual and safety signs affixed on the unit contain important instructions on the safe and proper use of the equipment.
Page 51: Bale Spear Pre-Operation Inspection
OPERATION BALE SPEAR PRE-OPERATION INSPECTION Bale Spear ID# ______________________ Date:______________________________ Make: _____________________________ Shift:______________________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the bale spear is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 52 OPERATION TRACTOR PRE-OPERATION INSPECTION Tractor ID# ____________________ Make:_______________________ Date:________________________ Shaft: _______________________ Before conducting the inspection, make sure the tractor engine is off, all rotation has stopped and the tractor is in park with the parking brake engaged. Make sure the mower is resting on the ground or securely blocked up and all hydraulic pressure has been relieved.
Page 53: Operating The Tractor And Implement
2. Stop completely before raising or lowering the spear(s) to the correct height. Insert spear(s) into the bale as follows: BSSS-1 and BSE-1 3. Locate spear point at center of bale or a small distance vertically above center.
Page 54: Traveling With A Load
OPERATION BSSS-2 6. While driving up to the bale, center the Bale Spear horizontally on the bale and spear points about 1/3 of the way below center of bale while driving up to the bale. 7. Push the spear(s) into the bale until the bale is against the frame of the attachment 8.
Page 55: Placing The Bale
OPERATION 4. When transporting with a bale, transport with bale fully against the spear frame and with spear points(s) up 5-10 degrees from horizontal. Never transport with bale halfway or more out on the spear(s). 5. When stopped, always lower spear point to the ground so that no person or livestock could walk/run into the spear and become impaled.
Page 56: Implement Storage
OPERATION Detach BSE 1. Move the machine onto a flat, level, solid surface. Lower the attachment slightly above the surface with the hitch angled, front of the attachment slightly higher than the rear. 2. If your machine is equipped with hydraulically operated locking pins, retract the coupler lock at this time.In this case;...
Page 57: Transporting On Public Roadways
OPERATION When transporting, only raise the blade enough to clear ground obstacles to prevent tipping, especially when traveling through rough terrain. Before transporting the tractor on a public roadway or boarding a trailer for transport, the tractor brake pedals should be locked together. Locking the pedals ensures...
Page 58 OPERATION The SMV (Slow-Moving Vehicle) emblem is universal symbol used to alert drivers of the presence of equipment traveling on roadways at a slow speed. SMV signs are a triangular bright orange with reflective red trim for both easy day and night visibility.
Page 59: Hauling The Tractor And Implement
OPERATION Reduce speed before turning or applying the brakes. Ensure that both brake pedals are locked together when operating on public roads. OPS-U- 0023 str 11.1 Hauling the Tractor and Implement Before transporting loaded tractor implement, measure height width dimensions and gross weight of the complete loaded unit.
Page 62: Proper Torque For Fasteners
MAINTENANCE PROPER TORQUE FOR FASTENERS The chart lists the correct tightening torque for fasteners. When bolts are to be tightened or replaced, refer to this chart to determine the grade of bolts and the proper torque except when specific torque values are assigned in manual text.
Page 63 TO THE OWNER/OPERATOR/DEALER To keep your implement running efficiently and safely, read your manual thoroughly and follow these directions and the Safety Messages in this Manual. The Table of Contents clearly identifies each section where you can easily find the information you need. The OCCUPATIONAL SAFETY AND HEALTH ACT (1928.51 Subpart C) makes these minimum safety requirements of tractor operators: REQUIRED OF THE OWNER:...
Page 64 BSE-1/BSSS-1/BSSS-2/BSSS-3 BALE SPEAR BSE-1/BSSS-1/BSSS-2/BSSS-3 SOM 08-23 P/N 50084019 Printed U.S.A...
