- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per TP-Link TL- PA7020P Kit o cerca il tuo prodotto tra le migliori offerte di Wireless e Bluetooth TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter REV1.0.0 1910011148...
- Page 2 Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.
- Page 3 FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 4 Safety Information When product has power button, the power button is one of the way to shut off the product; when there is no power button, the only way to completely shut off power is to disconnect the product or the power adapter from the power source.
- Page 5 TP-LINK TECHNOLOGIES CO., LTD DECLARATION OF CONFORMITY For the following equipment: Product Description: AV1000 2-port Gigabit Passthrough Powerline Adapter Model No.: TL-PA7020P Trademark: TP-LINK We declare under our own responsibility that the above products satisfy all the technical regulations applicable to the product within the scope of Council Directives: Directives 2004/108/EC, Directives 2006/95/EC, Directives 2011/65/EU The above product is in conformity with the following standards or other normative documents：...
-
Page 6: Table Of Contents
CONTENTS Chapter 1 Introduction ..................1 1.1 System Requirement ..................1 1.2 Important Safety Instructions ..............1 1.3 Conventions .......................2 1.4 LED Indicator .....................2 1.5 Physical Interface ....................3 Chapter 2 Connecting Mechanism ............... 5 2.1 Introduction ......................5 ... -
Page 7: Chapter 1 Introduction
To ensure data communication’s security and multimedia applications, this powerline adapter supports built-in 128-bit AES encryption and Quality of Service (QoS) features. The new powerline adapter TL-PA7020P from TP-LINK provides extra convenience and better performance for your home network with its integrated electrical socket and mains filter. The common problem of wasting an electrical outlet is solved and additional terminal devices or multiple sockets can be connected to the adapter just like to a normal wall socket. -
Page 8: Conventions
1.3 Conventions The powerline adapter or AV1000 2-port Gigabit Passthrough Powerline Adapter mentioned in this guide stands for TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter without any explanation. 1.4 LED Indicator The LED indicator displays information about the device’s status. -
Page 9: Physical Interface
TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter Item Status Indication The powerline adapter is connected to a powerline network. Powerline LED The powerline adapter is not connected to any powerline network or is in Power-Saving Mode. At least one Ethernet port is connected. - Page 10 TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter Note: If the pair button is pressed for about 8 seconds, the powerline adapter will leave the network which it has joined and its new network name assumes a random value. The Powerline LED turns off when it disconnects from the powerline network.
-
Page 11: Chapter 2 Connecting Mechanism
TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter Chapter 2 Connecting Mechanism 2.1 Introduction The powerline adapter supports up to 1000Mbps data rate. With this high speed connection rate, this powerline adapter allows you to set up a high speed house network by using your household existing electrical wiring. -
Page 12: Hardware Connection - Computer
TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter 2.3 Hardware Connection – Computer For those computers you wish to be networked by powerline adapters, each of the computers must be properly connected with a powerline adapter through an Ethernet (RJ45) cable. -
Page 13: Hardware Connection - Internet
TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter 2.4 Hardware Connection – Internet This section describes how to connect the powerline adapter into your existing ADSL broadband connection via ADSL Ethernet port. Follow the procedures described below to connect the powerline adapter to your ADSL broadband connection: 1．... -
Page 14: Chapter 3 Installing Management Utility
Setup Wizard will automatically pop up on your computer’s screen. Note: You can also download the utility at http://www.tp-link.com/en/support/download/. Step 2: Select TL-PA7020P and click Management Utility, and then the program installation process will carry out and copy all the necessary files to your system. - Page 15 TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter...
- Page 16 TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter...
- Page 17 TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter Step 3: After the installation, a shortcut to the “PowerLine Utility” application icon is provided on the windows desktop.
-
Page 18: Chapter 4 Using The Management Utility
TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter Chapter 4 Using the Management Utility After you had successfully installed the powerline adapter hardware and Management Utility software, you can set up or configure the devices according to your need. This PowerLine Utility enables you to identify powerline devices on the powerline network, measures data rate performance and ensures privacy by setting user defined secure powerline networks. -
Page 19: Status
TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter 4.1 Status The Status tab shows information of the powerline adapter connected to the current computer where the Management Utility is running. On this page, you can also set its network name. ... -
Page 20: Network
TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter 4.2 Network The Network tab window shows information of all the powerline devices found on the current logical network. Type: Displays the type of the powerline device found in the network. ... - Page 21 TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter Simple Application Mapping: The group allows you to choose what type of traffic with the highes user priority you will use your local HomePlug device for by pitching one of the following radios.
-
Page 22: System
TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter 4.4 System The System tab window is for some basic settings of the adapter. On this tab window, you can upgrade the firmware to the latest version and reset the adapter’s settings to the factory defaults. -
Page 23: Reset Device
The parameter information of GGL will restore to the factory defaults after resetting the powerline adapter. To upgrade the device's firmware, follow these instructions: Download GGL file from the TP-LINK website www.tp-link.com). Enter the path name or click to select the downloaded file on the computer into the corresponding blank. -
Page 24: Chapter 5 Advanced Feature: How To Use The Pair Button
TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter Chapter 5 Advanced Feature: How to Use the Pair Button 5.1 Set Up a Secure Powerline Network The Homeplug AV standard uses 128-bit AES (Advanced Encryption Standard) to safely transmit data between powerline adapters. For the powerline adapters to communicate with each other they all need to use the same Network Membership Key (NMK). -
Page 25: Appendix A: Troubleshooting
TL-PA7020P AV1000 2-port Gigabit Passthrough Powerline Adapter Appendix A: Troubleshooting The Troubleshooting provides answers to common problems regarding the powerline adapter. 1. The Power LED does not light up. Ans. Check the following: 1. Make sure that the powerline adapter is properly plugged into a power outlet.
