sauter SAF 875 B Instruction Manual

Gas - electric cooker

Hide thumbs

Table Of Contents

Quick Links

Download this manual

SAF 875 B

SAF 875 W

SAF 875 IX

INSTRUCTION MANUAL

GAS - ELECTRIC COOKER

IO-CFS-0401_EN / 8069170

(06.2017 / v1)

Table of Contents

Need help?

Do you have a question about the SAF 875 B and is the answer not in the manual?

Questions and answers

Summary of Contents for sauter SAF 875 B

Page 1 SAF 875 B SAF 875 W SAF 875 IX INSTRUCTION MANUAL GAS - ELECTRIC COOKER IO-CFS-0401_EN / 8069170 (06.2017 / v1)
Page 2 DEAR CUSTOMER, The cooker is exceptionally easy to use and extremely efficient. After reading the instruction manual, operating the cooker will be easy. Before being packaged and leaving the manufacturer, the cooker was thoroughly checked with regard to safety and functionality. Before using the appliance, please read the instruction manual carefully.
Page 3: Table Of Contents
TABLE OF CONTENTS Safety instructions ......................4 Description of the appliance ..................... 9 Installation ..........................11 Operation ........................... 16 Baking in the oven – practical hints ................22 Cleaning and maintenance ....................24 Specification ........................30...
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Warning: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning...
Page 5 SAFETY INSTRUCTIONS Warning: Ensure that the appliance is switched off before re- placing the lamp to avoid the possibillity of electric shock. Before opening the cover, cleaning it of any dirt is recom- mended. The cooker hob surface should be cooled down before closing the cover.
Page 6 SAFETY INSTRUCTIONS  Do not place pans with a weight greater than 10 kg onto the grate over one burner, or pans with a total weight of over 40 kg on the whole grate.  Do not hit the knobs and burners. ...
Page 7 SAFETY INSTRUCTIONS  Prolonged intensive use of the appliance may require additional ventilation, for example, opening a window or a more effective ventilation, such as increasing efficiency of mechani- cal ventilation, if applicable.  The appliance has been designed only for cooking. Any other use (for example for heat- ing) does not comply with its operating profile and may cause danger.
Page 8 DISPOSAL OF THE APPLIANCE UNPACKING During transportation, protec- Old appliances should not sim- tive packaging was used to ply be disposed of with normal protect the appliance against household waste, but should any damage. After unpack- be delivered to a collection and ing, please dispose of all recycling centre for electric and elements of packaging in a...
Page 9: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE 3, 4 5, 6 Burner Spark safety ignitor valve 11 Double crown burner 1 Temperature control knob 12 Medium burner 2 Oven function selection knob 13 Medium burner 3, 4, 5, 6 Gas burner control knobs 14 Auxiliary burner 7 Temperatureregulatorsignal light L 15 Cover...
Page 10 SPECIFICATIONS OF THE APPLIANCE Oven fittings: Grill grate Roasting tray (drying rack) Sideracks...
Page 11: Installation
INSTALLATION The following instructions are addressed to the qualified specialist installing the cooker. HOOD These instructions aim at ensuring that installation and maintenance activities are Min. 600 mm performed as professionally as possible. Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure) and the adjustment of the ap- pliance are compatible.
Page 12 INSTALLATION The cooker comes with a G 1/2” threaded Gas connection coupling. Caution! Cooker connector The cooker should be connected to a pipe situated at the gas supply of the particular type of gas corner G1/2” that the appliance is manufactured to function with.
Page 13 INSTALLATION Make sure you do not exceed the torque Electrical connection when making the connection (maximum torque is 20 Nm). Otherwise, the connection  The cooker is manufactured to work with may be faulty or leaks may occur. a one-phase alternating current (230V The gas hose should not touch metal ele- 1N~50 Hz) and is equipped with a 3 x 1,5 ments of the cooker back shield.
Page 14 INSTALLATION Adapting the cooker to another type of gas. This operation may only be carried out by an In order to adapt the cooker to burn a different appropriately authorised fitter. type of gas, you should:  exchange nozzles (see tables below), If the gas the cooker is to be supplied with ...
Page 15 INSTALLATION In cookers with a safety device, a knob with Surface burners applied do not require adjust- a surface burner safety valve is used, fig. ment of primary air. A correct flame has dis- Knobs should be adjusted with the burner tinct internal cones of blue and green colour.
Page 16: Operation
OPERATION Before first use Timer The function of this timer is not only to provide  remove packaging elements, a warning signal about an expiring of time  gently (slowly) remove labels from the given before, but also have a built-in auto- oven door, trying not to break the glue matic switch off-function of an oven.
Page 17 OPERATION Ignition without an ignitor How to use surface burners  light a match, Choice of cookware  press in the knob to the end and turn it left to the “large flame” position Mind that the diameter of a pan base is always ...
Page 18 OPERATION Caution! Operation of the burner protection valve In cooker models equipped with a surface burner safety valve, hold the Some models are equipped with an automatic knob pressed down to the end when system that cuts off gas supply to a burner igniting for 10 seconds at the “large when the flame has disappeared.
Page 19 OPERATION Oven functions and operation. Oven is off Oven with automatic air circulation (including a fan and an ultra-fan heater) Keeping warm In this setting special bottom heater The oven can be heated up using the bottom is on. This function allows to keep and top heaters, the grill or the ultra-fan he- the temperature in the oven between ater.
Page 20 OPERATION Bottom heater on Convection with ring heating ele- When the knob is set to this position ment and bottom heater on the oven is heated using only the With this setting the convection fan bottom heater. Baking of cakes from and bottom heater are on, which in- the bottom until done (moist cakes creases the temperature at the bottom...
Page 21 OPERATION Use of the grill The grilling process operates through infrared rays emitted onto the dish by the incandes- cent grill heater. In order to switch on the grill you need to:  set the oven knob to the position marked with  heat the oven for approximately 5 minutes (with the oven door shut).
Page 22: Baking In The Oven - Practical Hints
BAKING IN THE OVEN – PRACTICAL HINTS Baking  we recommend using the baking trays which were provided with your cooker;  it is also possible to bake in cake tins and trays bought elsewhere which should be put on the drying rack; for baking it is better to use black trays which conduct heat better and shorten the baking time;...
Page 23 BAKING IN THE OVEN – PRACTICAL HINTS Oven with automatic air circulation (including a fan and an ultra-fan heater) Type Oven Temperature Level Time functions in minutes dish 160 - 200 2 - 3 30 - 50 160 - 180 20 - 40* 140 - 160 10 - 40*...
Page 24: Cleaning And Maintenance
CLEANING AND MAINTENANCE Important: By ensuring proper cleaning and mainte- nance of your cooker you can have a sig- The burner caps and leads must be reposi- nificant influence on the continuing fault-free tioned correctly so that they sit squarely onto operation of your appliance.
Page 25 CLEANING AND MAINTENANCE Oven Important! Do not use any abrasive agents,  The oven should be cleaned after every harsh detergents or abrasive ob- use. When cleaning the oven the lighting jects for cleaning. should be switched on to enable you to see the surfaces better.
Page 26 CLEANING AND MAINTENANCE  Ovens marked with the letters Dp have Replacement of the oven light bulb stainless steel sliding telescopic runners attached to the wire shelf supports. The In order to avoid the possibility of an telescopic runners should be removed electric shock ensure that the appliance is switched off before replacing the bulb.
Page 27 CLEANING AND MAINTENANCE Door removal Removing the inner panel In order to obtain easier access to the oven 1. Using a flat screwdriver unhook the up- chamber for cleaning, it is possible to remove per door slat, prying it gently on the sides the door.
Page 28 CLEANING AND MAINTENANCE 3. Pull the inner glass panel from its seat Regular inspections (in the lower section of the door). Fig. D. Besides keeping the cooker clean, you 4. Clean the panel with warm water with should: some cleaning agent added. ...
Page 29 OPERATION IN CASE OF EMERGENCY In the event of an emergency, you should:  switch off all working units of the cooker  disconnect the mains plug  call the service centre  some minor faults can be fixed by referring to the instructions given in the table below.
Page 30: Specification
SPECIFICATION Manufacturer Sauter Type code SAF 875 B SAF 875 W SAF 875 IX Cooker dimensions (H/W/D) 850 x 600 x 600 mm Weight 45 kg Rated voltage 230V ~50 Hz Rated power 3100 W top heater + bottom heater...

This manual is also suitable for:

Saf 875 w Saf 875 ix
