Fluval FX UVC Manual
Fluval FX UVC Manual

Fluval FX UVC Manual

In-line clarifier
Hide thumbs Also See for FX UVC:

Advertisement

Quick Links

FX
IN-LINE
CLARIFIER
INSTALLATION ON
FLUVAL FX2/FX4/FX6 FILTER COVER
INSTALLATION ON CABINET WALL WITH
FLUVAL FX2/FX4/FX6 FILTER
INSTALLATION ON CABINET WALL WITH
CANISTER FILTERS USING 5/8" / 16 mm HOSING
UVC
FREE • GRATUIT • FREI • GRATIS • GRÁTIS
3
+
EXTENDED WARRANTY WITH ONLINE REGISTRATION
GARANTIE PROLONGÉE AVEC INSCRIPTION EN LIGNE
GARANTIEVERLÄNGERUNG MIT ONLINE-REGISTRIERUNG
GARANTÍA EXTENDIDA AL REGISTRARTE ONLINE
GARANTIA ALARGADA COM REGISTO ONLINE
2
YEARS
ANS
JAHRE
AÑOS
ANOS
IN-LIN
CL
PAGE 2
PAGE 3
PAGE 5

Advertisement

loading
Need help?

Need help?

Do you have a question about the FX UVC and is the answer not in the manual?

Questions and answers

Summary of Contents for Fluval FX UVC

  • Page 1 IN-LIN IN-LINE CLARIFIER INSTALLATION ON FLUVAL FX2/FX4/FX6 FILTER COVER PAGE 2 INSTALLATION ON CABINET WALL WITH FLUVAL FX2/FX4/FX6 FILTER PAGE 3 INSTALLATION ON CABINET WALL WITH CANISTER FILTERS USING 5/8" / 16 mm HOSING PAGE 5 FREE • GRATUIT • FREI • GRATIS • GRÁTIS...
  • Page 2 Adapters for lters with Wall mounting bracket and screws 5/8” / 16 mm diameter hosing INSTALLATION ON FLUVAL FX2/FX4/FX6 FILTER COVER PREPARING YOUR FILTER 1. Turn filter IN and OUT valves to the closed (horizontal) position. 2. Unplug filter from electrical power supply. 3. Prior to UVC installation, output hosing must be emptied of water.
  • Page 3 UVC unit and plug into electrical outlet. A light indicator (visible through the semi-transparent lamp cover) will show that the UVC unit is operating. INSTALLATION ON CABINET WALL WITH FLUVAL FX2/FX4/FX6 FILTER IMPORTANT: • This installation option requires one 1" / 25 mm FX hose for cabinet mount (sold separately – # A20233) or equivalent 1" / 25 mm inner diameter vinyl hose (sold separately). • Self-tapping screws supplied with UVC unit are suitable for wooden cabinet walls with a minimum thickness of 0.6" / 15 mm. Installation is not...
  • Page 4 4. Slide metal clamp over end of filter 5. Slide UVC unit into mounting bracket until it clicks into place. output hosing (approx. 0.25" / 1 cm from end) and attach to UVC connector (either side as the UVC works in both directions). 6. Slide metal clamp over one end of 7. Slide metal clamp over other end of 1" / 25 mm FX hose for cabinet mount 1"...
  • Page 5 (A) for horizontal positioning, or holes (B) for vertical positioning. IMPORTANT: If installing horizontally, ensure mounting bracket is placed so that the screw holes appear below the Fluval logo. 2 HORIZONTAL 2 VERTICAL 4. Install hosing adapters on each 3. Slide metal clamps over each of the two 1"...
  • Page 6 7. Slide metal clamp over one end of 8. Attach other end of connection hose to filter output valve. IMPORTANT: 5/8" / 16 mm vinyl hosing (sold separately). Ensure clamp is positioned For optimal performance, ensure all approx. 0.25" / 1 cm from end and hosing follows a straight path with attach to UVC connector.
