Air King QUIET ZONE AKCVQZ80 Specifications

• Motor

Three stage 120 volt, double ball bearing with tangential bypass
discharge and thermoset fan end bracket. 13.13 amps with Quiet
Motor Technology.

• Power Unit Body

Durable powder coated all steel body.

• Performance

CFM at 2" opening: 96
Water Lift: 136"
Air Watts: 465

• Collection

5 Gallon Bagged or Bagless collection canister with HEPA membrane
filter, made with Dupont™ Teflon® fluropolymer.

• Recommended Home Size

Homes up to 8,000 square feet.

• Mounting

Includes metal mounting bracket, an extra utility inlet, and exhaust
muffler for added sound protection.

• Shipping Information

UPC: 0-83162-
Shipping Weight: lbs.
PROJECT
LOCATION
CONTRACTOR
FAN MODEL
CFM
NUMBER NUMBER
C US
Specifications subject to change without notice.
QUIET ZONE
IN
RPM WATTS AMPS
W.C.
AKCVQZ80
® CENTRAL VACUUM POWER UNIT
ARCHITECT
ENGINEER
SUBMITTED BY
SONES QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (610) 692-7400 • 877-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
CENTRAL VACUUMS
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: (905) 456-2033
Fax: (905) 456-1015
Updated 4-07
