1250DR/2500DR side display/manual controller PLDC-1

INTRODUCTION

The PowerLights have both light unit and power supply self-contained. They have a plug-in professional
flashtube, a 250-watt adjustable quartz modeling light, and bare bulb capability, both vertically and
horizontally. The PowerLights are fitted with Photogenic's quick-change reflectors and accessories made
by Photogenic.
Before using your new PowerLight for the first time, please read this manual carefully and acquaint
yourself with the controls and features. In this way, you can quickly get the greatest benefit from your new
unit and maintain efficient and safe operation.

SAFETY PRECAUTIONS

Despite the measures that have been taken to make electronic flash equipment safe, it must be recognized
that high voltages and high temperatures do exist within the power supply / lighting unit. Certain
precautions must be observed in handling the unit.
1.
Be sure this appliance is turned off, cooled, and unplugged from AC power before removing or
inserting flashtube or modeling lamp. Always use a rag or wear gloves to protect your hand from glass
breakage and heat.
2.
Do not defeat the purpose to the three-wire line cord by disconnecting the ground. Connect to properly
functioning and grounded 3-pin receptacles only (including extension cords).
3.
Do not insert a screwdriver or other metal objects into the flashtube socket area or vents. Contact with
high voltage may result.
4.
Do not operate this appliance with a frayed or damaged line cord. When replacing or using the unit
with an extension cable, be sure the cable has an equivalent or greater rating and is a properly
connected 3-wire grounded cable.
5.
Do not attempt to use this appliance if it has been dropped or damaged, until a qualified service person
has serviced it.
6.
Do not operate the unit with a damaged or broken flashtube or modeling lamp. Do not use flashtubes
with broken, cracked or missing glass envelopes.
7.
Perform no internal service work on this unit. Refer all such service to a qualified service person or
return to the factory.

PREPARATION AND BASICS

Unpacking and Setup
Unpack all units carefully to remove all parts from the carton(s). Do not discard or destroy the packing
material until the equipment has been inspected, assembled, and all parts accounted for.
After unpacking, all parts should be examined for any damage, which may have been caused by rough
handling during shipment. If any damage is detected, contact the delivering carrier at once. Claim for
damage should be made to the delivering carrier before destroying packing cartons.
OPERATOR MANUAL FOR THE
PowerLight 1250
PowerLight 1250DR
PowerLight 2500DR
1250 side display PLDD-1
1250DR/2500DR side display/IR receiver PLDIR-1
1250DR/2500DR IR remote control PLIRC-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerLight 1250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Photogenic PowerLight 1250

  • Page 1 The PowerLights have both light unit and power supply self-contained. They have a plug-in professional flashtube, a 250-watt adjustable quartz modeling light, and bare bulb capability, both vertically and horizontally. The PowerLights are fitted with Photogenic’s quick-change reflectors and accessories made by Photogenic.
  • Page 2 Illustration from PL1500 p. 3 Power Input: The power required to operate the PowerLight 1250 or 1250DR is 105 to 125 volts AC, 60 Hz, 10 Amp. The power cord has a 125V, 10 Amp. rating. Cords rated for less amperage may overheat.
  • Page 3 To adjust the PowerLight 1250 to an exact flash power setting, use the accessory digital display. Ready Light: The PowerLight 1250 is fully charged when the READY lamp is on. Full power charge (500 ws) time is a maximum of 1.5 seconds. The unit may be flashed before fully charged.
  • Page 4 time, with the FLASH already set to desired watt-seconds. Setting is retained when user returns from another mode. FULL ON/OFF is exactly what it says. Press the FULL ON/OFF button to turn the modeling lamp OFF (LED off) or ON (LED on). All mode settings are retained, even after power has been off.
  • Page 5 or if no light appears through the lens, the shutter is not synchronized. If the shutter appears not to be synchronized, a reputable camera repair shop should check the shutter contacts. OPERATION Flashing Rate: The unit recharges quickly, as indicated by the READY light on the control panel. A quick series of flashes can be obtained within the limits of the recharge time.
  • Page 6 Dimensions ...................4.5” x 4.5” x 6.75” Without tube, lamp, reflector. Flashtubes and Modeling Lamps: Flashtube ....................Plug-in style, use only Photogenic C4-5. Modeling Lamp ..................250-Watt Quartz Halogen, ESS. 150-Watt Quartz Halogen, ESP. 100-Watt Quartz Halogen, ESR. Fuse .......................3AG type, 16 Amp, SLO-BLO.
  • Page 7 SERVICE The photographer should not attempt to make repairs himself. Consult a dealer for an authorized Photogenic Machine Company service agent. For replacing the flashtube or modeling lamp, follow the directions given in this manual.
