SpectronIQ PLTV-4250 Reference Manual

Spectroniq pltv-4250: reference guide

How To:

Remove the base on the PLTV-4250 (42")

Lay your TV facing down on a soft surface (something that will protect the screen from

scratches).

Remove the 8 screws from the back that hold the base in place. (see arrows below)

*Please note, the top 6 screws are about 1.5" in length and have to be removed before the

base rods will slide out. A magnet works great to extract them.

Table of Contents

Need help?

Do you have a question about the PLTV-4250 and is the answer not in the manual?

Page 1 How To: Remove the base on the PLTV-4250 (42”) Step #1 Lay your TV facing down on a soft surface (something that will protect the screen from scratches). Step #2 Remove the 8 screws from the back that hold the base in place. (see arrows below) *Please note, the top 6 screws are about 1.5”...
Page 2 Step # 3 Remove ALL of the Screws from the bottom of the stand and remove the two black plates. (see below) Before After Rods that have to be slid out.
Page 3 TV. *Note: The rods are firmly installed, therefore steady force and pressure is required to slide the rods out from the TV. Ensure that all of the screws mentioned above are completely removed. (See picture below)
Page 4 You are now ready to mount your TV with the base removed. (see picture below) *Note: The bottom part of the TV might seem a little wobbly, tha is okay. With the TV secured firmly to your mount, it will have no effect on the quality of your product or appearance.
