Common Mode Noise Filters Array
EXC28CG type
Features
● Small and thin type, two built-in filter circuit (L 2.0 mm×W 1.0 mm×H 0.5 mm)
● Prevention of weakening of transmission signals by controlling singal pass band as 3 GHz or above
● Prevention of reflection of transmission signals and noise radiation by controlling TDR characteristic
impedance as 100 Ω
● Satisfaction of eye pattern standards of HDMI waveforms with capability to improve waveform fluctuations of
Jitter and phase shift etc
● Elimination of radiation noises from high-speed differential transmissions
● Magnetic shield type with no leakage
● RoHS compliant
Recommended applications
● AV equipment (LCD-TV, DVD/Blu-ray drives), Information equipment (PCs, HDD),
Communications equipment (Mobile phones, Smartphones)
● Noise suppression of high-speed differential data lines such as HDMI, SATA and LAN
Explanation of part numbers
1
2
C
E
X
Product code
Dimensions (mm)
Code
Noise filter
2.0×1.0×0.5
2
(L)×(W)×(H)
Construction
Inner conductor
Dimensions in mm (not to scale)
Part No.
(inch size)
EXC28CG (0804)
1.00 ± 0.15
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
3
4
5
2
8
Number of
terminals
8 Terminals
Ferrite
Electrode
C
A
A
B
2.0 ± 0.2
0.5 ± 0.1
6
7
8
C
9
G
Code
Type
Code
Characteristics
Coupled
High speed
C
differential
type
G
transmission
(for Gbps)
Circuit configuration (No polarity)
8
7
1
2
※ The pin numbers shown here are for reference purposes only.
F
D
E
B
Dimensions
C
D
0.2 ± 0.15
9
10
11
0
0
U
Nominal impedance
Code
The first two digits are
U
significant figure of
impedance value, and
the third one denotes
the number of zeros
following.
8
6
5
3
4
1
E
F
0.5 ± 0.1
0.25 ± 0.1
12
Suffix
Packing form
Embossed carrier
taping
4 mm pitch,
5,000 pcs
7
6
5
2
3
4
Unit : mm
Mass (Weight)
(mg/ pc.)
5.0
20-Jan-23

Advertisement

loading
Need help?

Need help?

Do you have a question about the EXC28CG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Panasonic EXC28CG

  • Page 1 Common Mode Noise Filters Array EXC28CG type Features ● Small and thin type, two built-in filter circuit (L 2.0 mm×W 1.0 mm×H 0.5 mm) ● Prevention of weakening of transmission signals by controlling singal pass band as 3 GHz or above ●...
  • Page 2 EXC28CG type Ratings Impedance (Ω) at 100 MHz Rated voltage Rated current DC resistance Part number (V) DC (mA) DC (Ω) max. Common mode Differential mode EXC28CG240U 24 Ω ± 25 % 15 Ω max. EXC28CG900U 90 Ω ± 25 % 17 Ω...
  • Page 3 Common Mode Noise Filters / Common perfomance Perfomance Test item Performance requirements Test conditions resistance Resistance Within specified tolerance 25 ℃ Overload ― Rated voltage Resistance to ±30 % (Impedance change) 260 ℃, 10 s soldering heat Rapid change of ±30 % (Impedance change)...
  • Page 4 ■ The technical information contained in this catalog is intended to show only typical operation and application circuit examples of this product. This catalog does not guarantee that such information does not infringe upon the intellectual property rights of Panasonic or any third party, nor imply that the license of such rights has been granted.
  • Page 5 Matters to Be Observed When Using This Product Matters to Be Observed When Using This Product (Common mode noise filter)  Use environments and cleaning conditions ■ This product (fixed resistor) is not designed for use in specific environments. Using the resistor in the following specific environments or service conditions may affect the performance/reliability of the resistor.
  • Page 6: Mounting Conditions

    Matters to Be Observed When Using This Product  Reliability and product life A capacitor conforming to "AEC-Q200" refers to a capacitor having passed some or all of evaluation test items defined in AEC-Q200. To know the detailed specifications of each capacitor or specific evaluation test scores, please contact us. We issue a delivery specification sheet for each product ordered.
