- Page 1 MLS STRIKER SOCCER TABLE ASSEMBLY INSTRUCTIONS NGD1031...
- Page 2 THANK YOU! Thank you for your purchase of this Harvil product. We work around the clock and around the globe to ensure that Harvil products maintain the highest possible quality. However, in the rare in- stance that your product is defective or missing parts, contact your retail- er to submit parts requests or warranty claims.
- Page 3 PARTS IDENTIFIER (NOT TO SCALE)
-
Page 4: Assembly Tips
ASSEMBLY TIPS 1. Find a clean, level surface to begin the assembly of your game table. The table will be partially assembled upside down and then turned over onto its legs. This is a heavy game and turning it over will require at least two strong adults. 2. - Page 5 ASSEMBLY INSTRUCTIONS 1. Insert pre-assembled BLUE PLAYER RODS and GREEN PLAYER RODS into one SIDE PANEL #7 as shown below. Note: Although this table is assembled upside down, players are shown up- right for clarity. Each team should face the opposite goal when table is turned over. Ensure that FOAM BUMPERS and PLASTIC ROD WASHERS are in place before inserting rods.
- Page 6 ASSEMBLY INSTRUCTIONS (CONT.) 5. Attach remaining END PANEL #8 to the opposite end of the table with 1-1/2" FLAT SCREW 6. Attach each PLAYFIELD SUPPORT BRACE #23 across the underside of the PLAYFIELD by fastening to the SIDE PANELS with 1-1/2" SCREW #3. 7.
- Page 7 ASSEMBLY INSTRUCTIONS (CONT.) 8. Attach each LEG PANEL #12 to LEGS with 1/2" SCREW #4. Note: MLS graphics should face outward. Carefully turn table over. 9. Attach HAND GRIP #13 to the marked end of each PLAYER ROD. Attach ROD END CAP #22 to the opposite end of PLAYER RODS.
-
Page 8: Care And Use
CONGRATULATIONS! You have now assembled your MLS Soccer Table. Please note the Care and Use instructions below to ensure years of trouble free use of your game table. CARE AND USE 1. This product is intended for INDOOR use only. -
Page 9: 90-Day Limited Warranty
90-DAY LIMITED WARRANTY This Harvil product is warranted to the original purchaser to be free from defects in material or work- manship for a period of ninety days from the date of the original retail purchase. This warranty does not cover defects or damage due to improper installation, alteration,accident or any other event beyond the control of the manufacturer.
