- Page 1 Tripod BO-DS5000 Last update: Apr. 2023 User Manual User Manual Please read and follow the installation instructions before operating the equipment, and keep the instructions for future reference or use after debugging.
-
Page 2: Table Of Contents
Tripod BO-DS5000 Contents 1. Note..........................3 1.1 Note..........................3 2. Turnstile electric control system..................3 2.1 Turnstile electric control system................3 3. Install Instruction......................4 3.1 Installation note & suggestion................4 3.2 Turnstile circuit board wiring diagram..............5/6 4. Menu Parameter Setting....................6 4.1 Button introduction....................6/7 4.2 Menu setting......................7 ......7/8... -
Page 3: Note
Tripod BO-DS5000 1. Note 1.1 Note Before installation, operation or maintenance, turn off power. Do not change the inside wiring, take a photo before any disconnection. Do not use the turnstile inside power supply to connect other third-party device. Do not operate when thundering and lightning, in case damage the turnstile electrical parts. -
Page 4: Install Instruction
Tripod BO-DS5000 3. Install Instruction 3.1 Installation note & suggestion Note: During installation and construction, relevant circuits should be disconnected to ensure that all circuits are correct before energizing. ►►Installation Suggestion: For cables, suggest laid 60mm deep, over 50mm, and connector area be bending to avoid water. -
Page 5: Turnstile Circuit Board Wiring Diagram
Tripod BO-DS5000 3.2 Turnstile circuit board wiring diagram *Turnstile electrical parts area with power supply port, please connect to 110V/220V electrical power supply. *Turnstile circuit board with port “OP-L”,” COM”, “OP-R”, it can be connected to any type of the third-party access controller device. -
Page 6: Menu Parameter Setting
Tripod BO-DS5000 4. Menu Parameter Setting 4.1 Button introduction Control board buttons: "MENU" menu key/confirm key, "INC" up/plus key, "DEC" down/minus key, three operation buttons. Explanation of each function key: "MENU" key: 1. It functions as the menu key on the standby interface, long press this key to enter the menu;... -
Page 7: Menu Setting
Tripod BO-DS5000 "INC" key: It functions as the +1 key when scrolling up to select system menus and set parameters. "DEC" key: It functions as the -1 key when scrolling down to select system menus and set parameters. NOTE: In the system menu and menu setting interface, if there is no key operation within 5 seconds, the system will automatically exit the menu and return to the standby interface. - Page 8 Tripod BO-DS5000 After turning off the memory function, swiped multiple cards only the last swipe card is valid, allowing only one person to pass. (Default is 0, turn off the memory function) 5. "F05" Repeated gate opening and closing test, mainly used to test the stability and aging of the gate control board.
-
Page 9: Product Maintenance
Tripod BO-DS5000 5. Product Maintenance 5.1 Daily maintenance To avoid the risk of electric shock, always ensure the power off before inspecting. Suggest inspected at regular time, to ensure all parts in good working. The material made by stainless steel, do not use hard material to clean it. -
Page 10: Customer Services
Tripod BO-DS5000 6. Customer Service We are very happy to help you in the future when you encounter problems or product defects, if the use or operation is not clear, please timely contact the after-sales service staff. www.wano.pl...
