- Page 1 ALPHAWORKS AIR-OPERATED DOUBLE DIAPHRAGM PUMP USER MANUAL...
- Page 2 GENERAL SAFETY REGULATIONS WARNING: The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions or situations that could occur. It must be understood by the operator that common sense and caution are factors that cannot be built into this product, but must be supplied by the operator.
- Page 3 TECHNICAL DETAILS Model GUF014 Inlet/Outlet 1/2" Air Inlet 1/4" Flow Rate 12GPM/ 45LPM Maximum Air Inlet Pressure 115PSI/ 8BAR Maximum Outlet Pressure 115PSI/ 8BAR Max. Diameter Solid 1/8" Pump Body Aluminum Nitrile, Fluorin Rubber & EPDM is optional Membrane AIR CONSUMPTION CHART...
- Page 4 OPERATING AND SAFETY PRECAUTIONS READ, UNDERSTAND, AND FOLLOW THIS INFORMATION TO AVOID INJURY AND PROPERTY DAMAGE. WARNING! EXCESSIVE AIR PRESSURE. Can cause personal injury, pump damage or property damage. • Do not exceed the maximum inlet air pressure as stated on the pump model plate. •...
- Page 5 CAUTION! Prevent unnecessary damage to the pump. Do not allow pump to operate when out of material for long periods of time. Disconnect air line from pump when system sits idle for long periods of time. GENERAL DESCRIPTION • The diaphragm pump offer high volume delivery even at low air pressure. •...
- Page 6 EXPLODED AND PARTS LIST Part No. Description Q’ty Part No. Q’ty Description Hex-bolt M8×55 Diaphragm Discharge Manifold Air Chamber Plate Valve cover Screw M8X16 Valve Ball Connecting Shaft Valve Seat Air Chamber O-ring 28.24x2.62 O-ring 94.92X2.62 Nut M8 Hex-bolt M8 Liquid Chamber Screw M5X8 Hex-bolt...
- Page 7 EXPLODED AND PARTS LIST AIR MOTOR SECTION 14 15 9 10 11 Part No. Description Q’ty Part No. Description Q’ty Hex-bolt M6X20 Major Valve Press board O-ring 9.93X2.62 Seal for press board Sleeve Spacer O-ring 20.35X1.78 Spacer Retaining Ring 25 Spacer O-ring 7.1X2.65 O-ring 20.35X1.78...
- Page 8 Great Circle USA Support Line: 1-866-493-0524 help@greatcircleus.com www.greatcircleus.com Size: 145x210mm REV 10/24/19 2.09.05.30.926...
