OWNER'S MANUAL
WASHING MACHINE
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
T2553VSPM / T2555VSPM / T2517VSPB
MFL71799909
Rev.01_021422
Copyright © 2021-2022 LG Electronics Inc. All Rights Reserved.
www.lg.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LG T2553VSPM
Summary of Contents for LG T2553VSPM
- Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH T2553VSPM / T2555VSPM / T2517VSPB www.lg.com MFL71799909 Rev.01_021422 Copyright © 2021-2022 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
Preparing the Wash Load ................15 Adding Detergents, Softeners and Bleaches..........17 Control Panel ....................19 Programme Table ....................21 Extra Options and Functions ................23 SMART FUNCTIONS LG ThinQ Application ..................27 Smart Diagnosis ....................27 MAINTENANCE Cleaning after Every Wash ................28 Cleaning the Appliance Periodically ..............28 TROUBLESHOOTING... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk. - Page 4 • The inlet water pressure must be between 50 and 800 kPa. Maximum Capacity The maximum capacity in some cycles for dry clothes to be washed is: T2553VSPM T2555VSPM T2517VSPB 13.5 kg...
- Page 5 SAFETY INSTRUCTIONS • Do not modify the power plug provided with the appliance. If it does not fit the power outlet, have a proper outlet installed by a qualified electrician. • This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current.
- Page 6 • Make sure that drainage is working properly. If water is not drained properly, your floor may get flooded. • If, during spinning, opening the door does not stop the drum within about 10 seconds, immediately discontinue operating the appliance and contact your dealer or LG Electronics service centre.
- Page 7 • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
-
Page 8: Installation Parts And Specifications
Door Cold Water Inlet Hose Handle Drain Hose Tempered Glass Anti-Rat Cover Detergent Dispenser Drawer Screw for Anti-Rat Cover Bleach Dispenser Drum Specifications Model T2553VSPM / T2555VSPM / T2517VSPB Power Supply 220 V~, 50 Hz Product Weight Approx. 42 kg... - Page 9 INSTALLATION Dimension(mm) D’ H’ 1020 1390...
-
Page 10: Installation Place Requirements
Contact your local 2 cm 2 cm 10 cm authorised LG repairer. • The power plug must be plugged into an WARNING appropriate outlet socket that is installed and • This appliance must only be used for domestic... -
Page 11: Connecting The Water Inlet Hoses
INSTALLATION Connecting the Water Inlet Connecting the Hose to the Water Tap Hoses Connecting Screw-Type Hose to Tap with Thread Before connecting the water inlet hose to the water Screw the hose connector onto the water supply tap, check the hose fitting type and follow the tap. - Page 12 INSTALLATION completely to the tap and then tighten the connector latch plate. Make sure the adapter hose by screwing it to the right. locks into place. Connecting One Touch Type Hose to Tap Without Thread Unscrew the adapter ring plate and loose NOTE the 4 fixing screws.
-
Page 13: Installing The Drain Hose
INSTALLATION Installing the Drain Hose • The outlet of the drain hose should not be submerged in water. Before connecting the drain hose, check your drain hose model and follow the instructions for that model. Installing the Drain Hose in a Floor Drain Push the elbow end of the hose onto the drain •... - Page 14 INSTALLATION • Turn the adjustable feet clockwise to raise or Insert the anti-rat cover to the assembling turn the adjustable feet counterclockwise to bracket from the back of the appliance. lower the appliance. NOTE • Do not insert pieces of wood etc. under the feet. •...
-
Page 15: Operation Operation Overview
OPERATION OPERATION Operation Overview End of cycle. • When the cycle is finished, a melody will sound. Immediately remove your clothing Using the Appliance from the appliance to reduce wrinkling. Before the first wash, select the Normal programme and add a half amount of detergent. NOTE Start the appliance without clothes. - Page 16 OPERATION Checking the Fabric Care Label cause irreparable damage to both your appliance and clothes. This will tell you about the fabric content of your clothes and how it should be washed. Symbols on the Care Labels Symbol Wash / Fabric type •...
-
Page 17: Adding Detergents, Softeners And Bleaches
OPERATION Adding Detergents, CAUTION Softeners and Bleaches • Using liquid detergent without diluting, or leaving laundry for a long time after pouring Detergent Dosage diluted liquid detergent into the drum might cause the clothes to be damaged, bleached, • Detergent should be selected according to fabric discoloured. - Page 18 OPERATION Adding Fabric Softeners bleach dispenser . Avoid splashing or overfilling. Add a fabric softener to the maximum fill line. • If the softener is concentrated, then it should be diluted. • Mix powdered bleach with water to a liquid consistency and pour it into the bleach •...
-
Page 19: Control Panel
OPERATION Control Panel Control Panel Features * Extra Function : Hold 3 seconds POWER Button • Press this button to turn on or off the appliance. • The appliance automatically turns off once a certain time has passed after the wash has completed. START/PAUSE Button •... - Page 20 OPERATION - If the display shows , then the time will be displayed after the load sensing has detected the -:-- laundry size. - The time shown is only an estimate. Several external factors (laundry size, room temperature, incoming water temperature, etc.) can affect the actual time. •...
-
Page 21: Programme Table
OPERATION Programme Table Washing Programme Wash programmes are designed for the best wash performance for different types of clothes. • Press the Program button to select the desired programme. • When you select a wash programme, the light for the corresponding wash programme will turn on. Normal Description Use this programme to wash normal laundry. - Page 22 OPERATION Duvet Description Use this programme to wash a blanket or bedclothes that have the hand wash sign on the care label. • Cashmere bedclothes, acrylic blanket, mixed spinning blanket, woollen blanket, infilling (polyester 101), and bed sheets might be damaged if they are allowed to float.
-
Page 23: Extra Options And Functions
OPERATION Quick Wash Description Use this programme to wash lightly soiled clothes for a short time. • This programme's recommended laundry amount is under 3 kg. Extra Clean Description Use this programme to increase rinsing performance. • This programme is recommended for underwear and baby clothes. •... - Page 24 OPERATION • When water level is automatically detected, it NOTE may differ depending on the amount of laundry even though the same water level is indicated on • This function is the time to the end of the the control panel. programme, not the start.
- Page 25 OPERATION Press and hold the Rinse and Spin buttons simultaneously for 3 seconds to activate this function. Unlocking the Control Panel Turn on the power. Press and hold the Rinse and Spin buttons simultaneously for 3 seconds to deactivate this function.
- Page 26 OPERATION Manual Washing When you need a rinse and spin, spin only, rinse only or wash only cycle, these can be set manually. Rinse and Spin Spin only Rinse only Wash only Press the POWER button. Press the Rinse Press the Spin Press the Rinse Press the Wash button.
-
Page 27: Smart Functions
Using Audible Diagnosis to Diagnose Issues Follow the instructions below to use the audible diagnosis method. • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions for audible diagnosis provided in the LG ThinQ application. -
Page 28: Maintenance
MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, electric shock, or death. • Never use harsh chemicals, abrasive cleaners, or solvents to clean the appliance. They may damage the finish. - Page 29 MAINTENANCE • For models without a lint filter, the lint is holiday), especially if there is no floor drain discharged when the water drains during (gully) in the immediate vicinity. washing. • error message will be displayed on the control panel when water is not entering the detergent drawer.
- Page 30 MAINTENANCE Close the lid and then insert the lower part of CAUTION the filter into the wash drum. Press the top of the filter until you hear a click sound. • If the mesh hole of the lint filter is clogged, foreign objects in the laundry may not be filtered.
-
Page 31: Troubleshooting
You can remedy most of the problems by yourself, consequently save time and money, since you do not need to call LG Electronics service centre. The following table should assist you by troubleshooting. - Page 32 TROUBLESHOOTING Symptoms Possible Cause & Solution Foreign objects, such as coins, pins, clips, etc.,are caught between the pulsator and the inner drum. FOREIGN OBJECTS ERROR • Turn off the appliance and then press the POWER button. Press the Spin button without selecting a cycle to drain and spin the laundry. When the spin is complete, remove the clothes and then find and remove any objects caught in the pulsator gap.
- Page 33 TROUBLESHOOTING Symptoms Possible Cause & Solution A motor error has occurred. DRAIN MOTOR ERROR • Unplug the appliance and call for service. is not an error. This prevents children from changing cycles or operating the appliance. CHILD LOCK FUNCTION • Turn off the Child Lock function in the control panel. Noises Symptoms Possible Cause &...
- Page 34 TROUBLESHOOTING Symptoms Possible Cause & Solution Appliance will not Water supply is turned off. operate. • Turn on the water supply tap completely. Controls are not set properly. • Make sure the cycle is correctly set. Close the door and press the START/ PAUSE button.
- Page 35 TROUBLESHOOTING Symptoms Possible Cause & Solution Water leaking Drain hose has come out of drain or is not inserted far enough. • Tie drain hose to supply hose or standpipe to prevent it from coming out during drain. For smaller drain pipes, insert the drain hose into the pipe as far as the drain hose flange.
- Page 36 TROUBLESHOOTING Symptoms Possible Cause & Solution Poor stain removal Previously set stains. • Items that have previously been washed may have stains that have been set. These stains may be difficult to remove and may require hand washing or pretreating to aid in stain removal. Staining Bleach or softener dispensed too soon.
