Summary of Contents for AVARRO NX-FMM3763
- Page 1 NX-FMM3763 Full Motion Medium TV Mount 37-63"/70lb...
- Page 2 ENGLISH 1. Limited Warranty a. General Subject to the terms and conditions of this Limited Warranty, from the date of sale through the period of time for product categories specified in Section 1(a), ADI warrants ADI branded products to be free from defects in materials and workmanship under normal use and service, normal wear and tear excepted.
- Page 3 a. Specific Warranties for product categories are as follows : B Connectors Limited Lifetime Bus Terminals Limited Lifetime Extension Cords Limited Lifetime HDMI Cables Limited Lifetime Jacks, Cords and Intrusion Communication Accessories Limited Lifetime Patch Cables Limited Lifetime Patch Panels & Brackets Limited Lifetime Raceway Conduit Limited Lifetime...
-
Page 4: Tools Needed
4. Returns Subject to the terms and conditions listed below, during the applicable warranty period, ADI will replace Product or provide a credit at purchase at its sole option free of charge any defective products returned prepaid. Any obliga- tions of ADI to replace Limited Lifetime warranty products pursuant to this warranty which result from defect are limited to the availability of replacement product. -
Page 5: Hardware Part Numbers
MONITOR PLATE AND ADAPTERS Use diagrams to determine which mounting configuration is needed to attach monitor plate (with or without adapters) to the back of TV. Please check TV wall mounting compatibility before proceeding with installation. Please ensure A and B adapters are positioned as shown in the below diagrams. - Page 6 STEP 1- REMOVE MONITOR PLATE FROM MOUNT AND REMOVE COVERS FROM WALL PLATE Remove monitor plate from wall plate Loosen Remove and save Phillips head screws and washers. Screws and washers will be used to reattach monitor plate in step 4. Remove covers STEP 2A- MONITOR PLATE ATTACHMENT Connect monitor plate to TV...
- Page 7 STEP 2B- IF NEEDED, ATTACH MONITOR ADAPTERS TO MONITOR PLATE (See page 3 for options) Connect monitor plate with adapters to TV STEP 2C- IF MORE CLEARANCE IS NEEDED (MONITOR PLATE) Connect monitor plate to TV Conecte el adaptador al monitor Connectez l'adaptateur au moniteur Spacers can to be used when more clearance is required.
- Page 8 STEP 2D- USE M8 STEEL WASHER IF THE PHILLIPS SCREWS FROM THE HARDWARE KIT ARE TOO LONG Diagrams show three possible options for using additional washers if hardware screws are too long to properly tighten into the back of the TV. B or C OPTION B or C...
- Page 9 STEP 3A- WOOD STUD (CONCRETE INSTALLATION SKIP TO 3B) Find stud and mark edge and center locations Ubique el panel y marque las ubicaciones de los bordes y el centro DRILL BIT Repérez l'emplacement d'une poutre, puis marquez l'emplacement des bords et du centre de cette poutre NOT INCLUDED STEP 3A- DRILL PILOT HOLES AND MOUNT WALL PLATE Mount wall plate...
- Page 10 STEP 3 B – SOLID CONCRETE Level Solid concrete Drill bit DRILL BIT NOT INCLUDED 3/8” STEP 3B – DRILL PILOT HOLE AND MOUNT WALL PLATE Drill pilot hole Attach wall plate covers after wall plate is mounted to wall.
- Page 11 STEP 4- ATTACH PANEL TO MOUNT Hang with TV attached Heavy, Assistance Required TRES LOURD ! Cette etape requiert deux personnes !PESADO! Necesitara ayuda para realizar esta operacion ARM ASSEMBLY, LEVEL, AND TILT STEP 4- ADJUST TILT TENSION/ POST INSTALLATION LEVEL ±...
- Page 12 CAUTION: DO NOT EXCEED MAXIMUM WEIGHT CAPACITY. SERIOUS INJURY NX-FMM3763 OR PROPERTY DAMAGE MAY OCCUR! Max Loading Weight: 70 lbs PN: NX-FMM3763 40049 30315...
