Summary of Contents for TUFTINGSHOP AK-I
- Page 1 GUN MANUAL A K - I , A K - I I , A K H I G H A N D A K D U O Version 1.0 COPYRIGHT © 2023 TUFTINGSHOP COPYRIGHT © 2023 TUFTINGSHOP Page 1 of 24...
-
Page 2: Table Of Contents
MATERIAL ADJUSTMENT SELECTION STEP 1: PILE HEIGHT ADJUSTMENT FOR THE DUO MACHINE CLOTH STEP 2: AK-I AND AK-II PILE HEIGHT YARN ADJUSTMENTS STEP 3: ADJUST THE SCISSORS CLOSER SECONDARY BACKING AND GLUE STEP 4: ADJUSTING THE SCISSOR OPENER MACHINE MARTS... - Page 3 Whether you're a beginner or an experienced user, this manual will help you get the most out of your tufting gun and create beautiful, high-quality textiles. Let's get started! COPYRIGHT © 2023 TUFTINGSHOP Page 3 of 24...
-
Page 4: Safety Notice
By adhering to these safety guidelines, you can help ensure safe and efficient use of the tufting gun, Net Weight 1.5 kg 1.5 kg 1.5 kg minimizing the risk of accidents and injuries. COPYRIGHT © 2023 TUFTINGSHOP Page 4 of 24... -
Page 5: Maintenance
Oil the machine on a regular basis. Each machine has 4 oil holes, and each oil hole drips 3-5 drops of oil. Turn the big gear to make the oil fully lubricate the machine. COPYRIGHT © 2023 TUFTINGSHOP Page 5 of 24... -
Page 6: Connecting The Machine
Turn on the machine: Once the power cord and adapter are properly connected, turn on the machine using the on/off switch or button. Test the machine to make sure it is working properly. COPYRIGHT © 2023 TUFTINGSHOP Page 6 of 24... -
Page 7: Threading The Machine
➔ For the AK HIGH pile, you will find 2 eyes on the needle. Choose the eye right in front of the foot. o The front eye is for 30-40 mm o The other is for 40 - 48 mm COPYRIGHT © 2023 TUFTINGSHOP Page 7 of 24... -
Page 8: Start Tufting
If you are well practiced, you might try making circles. COPYRIGHT © 2023 TUFTINGSHOP Page 8 of 24... -
Page 9: Pile Height Adjustment
(Figure 4). If you need a 17-18mm pile height firstly adjust the positioning screw on wheel to the number 16,then adjust the tooth on the eccentric COPYRIGHT © 2023 TUFTINGSHOP Page 9 of 24... -
Page 10: Adjustments
(structure drawing 20) to the slot at the front end (this slot is special for 17-18mm). STEP 2. AK-I, AK-II AK HIGH PILE HEIGHT ADJUSTMENTS Unscrew the screw on the upper bearing rod (machine part 2) and take it off. -
Page 11: Step 4: Adjusting The Scissor Opener
(Figure14). When the yarn height increases, it moves backward, and when the yarn height decreases, it moves forward; COPYRIGHT © 2023 TUFTINGSHOP Page 11 of 24... -
Page 12: Backing Line And Front Pile Parameter List
Spot strip & positioning holee mouth & bow & scissors blade needle hole needle hole 16-17mm 3-4mm 9-10mm 10mm 17-18mm 3-4mm 11-12mm 12mm 19-20mm 3-4mm 12-14mm 14mm 21-22mm 3-4mm 15-17mm 16mm 25-26mm 3-4mm 20-21mm COPYRIGHT © 2023 TUFTINGSHOP Page 12 of 24... - Page 13 STEP 6. ADJUSTING THE FOOT Always make sure the needle hole is right in front of the foot. COPYRIGHT © 2023 TUFTINGSHOP Page 13 of 24...
-
Page 14: From Cut To Loop
This creates a more textured surface that is often more durable and better suited to high-traffic areas. COPYRIGHT © 2023 TUFTINGSHOP Page 14 of 24... - Page 15 OPTION 1. BOTH DUO AND AK-I and AK- HIGH This is the simplest method to changing you machine from cut to loop. You deactivate the scissors by moving the part that makes the scissors cut. The scissors stay open this way and the machine will create a loop effect.
-
Page 16: Option 2: Only For The Duo
Turn the gear and push the connecting rod to the front side. Use a screwdriver to unscrew the scissors. The scissors can be easily removed from the side with pliers. COPYRIGHT © 2023 TUFTINGSHOP Page 16 of 24... -
Page 17: Step 2: Remove The Scissor And
Finally, check the position of a loop head in the needle. Make sure the loop head is in the middle of the needle and doesn’t scratch the needle when moving back and forth. For further details, please check the video. https://www.youtube.com/w atch?v=llk4kXvzcfU&t=40s COPYRIGHT © 2023 TUFTINGSHOP Page 17 of 24... -
Page 18: Running Check
RUNNING CHECK If you change the scissor or function, please do this running check before you start. For further details, please check the video. https://www.youtube.com/w atch?v=9Z84OCC7-vI&t=48s COPYRIGHT © 2023 TUFTINGSHOP Page 18 of 24... -
Page 19: Trouble Shooting
Regular cleaning and maintenance of the tufting gun can help prevent this issue. COPYRIGHT © 2023 TUFTINGSHOP Page 19 of 24... -
Page 20: The Machine Is Beeping
Try adjusting the speed and pressure to achieve a more consistent stitch. • Clogged or damaged needles: If the needles of the tufting gun are clogged or damaged, this can cause an uneven COPYRIGHT © 2023 TUFTINGSHOP Page 20 of 24... -
Page 21: Material Selection
It's always a good idea to experiment with different fabrics and yarns to find the best combination for your particular project. COPYRIGHT © 2023 TUFTINGSHOP Page 21 of 24... -
Page 22: Secondary Backing And Glue
However, be sure to use a high-quality fabric glue that is suitable for use with the materials you are working with, and follow the manufacturer's instructions carefully. COPYRIGHT © 2023 TUFTINGSHOP Page 22 of 24... -
Page 23: Machine Marts And Names
MACHINE MARTS AND NAMES COPYRIGHT © 2023 TUFTINGSHOP Page 23 of 24... - Page 24 LAAN VAN HAAGVLIET 30 2271 XP VOORBURG NETHERLANDS Contact: Email: info@tuftingshop.com Phone: +31 6 40194349 T U F T I N G S H O P . C O M COPYRIGHT © 2023 TUFTINGSHOP COPYRIGHT © 2023 TUFTINGSHOP Page 24 of 24...
