Summary of Contents for Vibrationmaster J600
- Page 1 Installation Guide J600/J900 Fastener Test bench August 2018 Document Reference J600-J900 Installation Guide 2018_V1.3...
- Page 2 Page 2 Document Reference J600-J900 Installation Guide 2018_V1.3...
- Page 3 à r. l., or any third party. Except as expressly provided above, nothing contained herein shall be construed as conferring any licence or right under any Vibrationmaster Technology Centre s. à r. l. trademark or copyright. This document is intended solely for the recipient, and as such is confidential, and may legally be privileged.
- Page 4 Page 4 Document Reference J600-J900 Installation Guide 2018_V1.3...
-
Page 5: Table Of Contents
When the J600/J900 arrives to you Installation equipment and tools needed Unloading the J600/J900 Unpacking the J600/J900 Preparing the J600/J900 for use The J600/J900 is now ready to be operated. Contact information Document Reference J600-J900 Installation Guide 2018_V1.3 Page 5... -
Page 6: About This Manual
This Installation Guide will explain how to prepare before the arrival of your J600/J900 Fastener Test bench and how to correctly install your J600/J900 Fastener Test bench and have it ready for operation once it has arrived to you. Throughout this document, we may refer indiscriminately to the J600 and J900 Fastener Test benches as “J600/J900”, “machine(s)”... -
Page 7: Before The J600/J900 Arrives To You
1. Before the J600/J900 arrives to you Thank you! Thank you for purchasing a J600 or J900 Fastener Test bench. We have put considerable effort into designing and manufacturing the J600/J900 machines and we hope it will be useful to you in testing bolted joint integrity, the relationship between applied torque and achieved tension and the self-loosening behaviour under vibration conditions. -
Page 8: Preparing The Floor Space
Floor load The operating location of the machine should be a levelled surface strong enough to carry the weight of the machine (1,540 kg [3,395 lbs] for J600 and 1,580 kg [3,493 lbs] for J900). The machine is supported by eight feet which span over a surface of 1580 mm [62.2”] by 580 mm [22.8”]. - Page 9 Accessibility from all sides The J600/J900 Fastener Test Bench should be accessible from all sides. Service doors on the back of the machine have to have the necessary space so that they can be opened fully. Document Reference J600-J900 Installation Guide 2018_V1.3...
- Page 10 Recommended working area In order to work comfortably around the machine, we recommend to allow for a minimum working area of 3500 mm [11’6”] by 2800 mm [9’2”]. Machine height Page 10 Document Reference J600-J900 Installation Guide 2018_V1.3...
-
Page 11: Environmental Conditions
J600/J900. Acoustic noise The maximum level of noise exhibited for the J600/J900 is < 85 dB(A) as measured by a sound level meter in 1 meter distance from the J600/J900. Electrical and magnetic fields (shielding) -
Page 12: Packaging And Shipping
11.7 vibrations (m/s2) Packaging and shipping Your J600/J900 will be packed in a wooden box on a pallet suitable for export and confirming to ISPM 15. J600 shipping dimensions Length 2240 mm x Width 1070 mm x Height 1630 mm... -
Page 13: When The J600/J900 Arrives To You
Spirit level Unloading the J600/J900 The J600/J900 Fastener Test bench will be delivered in a wooden box on a pallet. Depending on the destination, a waterproof protective film will protect the machine from humidity. The box has to be removed off the truck by using a forklift and should be placed onto solid ground. -
Page 14: Preparing The J600/J900 For Use
Preparing the J600/J900 for use Levelling the machine The J600/J900 rests on eight feet which are individually adjustable in height. Slight unevenness of the ground can be compensated by adjusting the feet. Use a spirit level to adjust the feet and to assure that the J600/J900 is levelled. -
Page 15: The J600/J900 Is Now Ready To Be Operated
Wire Colour Description Brown Black Grey Blue Yellow/green The J600/J900 is now ready to be operated. Contact information Vibrationmaster Technology Centre s.à r.l. Rue du Commerce, Technoport 3A 3895 Foetz Luxembourg Telephone: +352 24 55 90 68 Web: www.vibrationmaster.com E-mail: support@vibrationmaster.com...
