Summary of Contents for Fredette AR-S10

  • Page 1 AR-S10...
  • Page 2 This Guide provides necessary instructions on machine operation and maintenance. Before operation or use of this machine, please carefully read and understand this Guide. When ordering the replacement parts, please refer to the spare and accessory parts manual attached to the machine.

  • Page 3: Table Of Contents

    CONTENT Precautions.............................. 1 Instructions on Machine Operation.......................3 Reception of Machine..........................6 Machine Unpackaging........................6 Battery Installation......................... 7 Machine Cleaning Method........................7 Information on Brush and Scouring Pad..................... 8 Machine commissioning and pre-operation inspection..............8 Check before operation........................ 8 Machine commissioning....................... 8 Machine Operation..........................

  • Page 4: Precautions

    FREDETTE Precautions This machine is suitable for industrial and commercial use and specially used for cleaning indoor hard floor instead of other purposes. Please use the suggested scouring pad and brush as well as the commercially available floor cleaner suitable for this machine.
  • Page 5 FREDETTE -please wear anti-skid shoes. -Please slow down when turning. -report immediately when the machine is broken or the operation fails. -do not let the children play on or around the machine. -observe the mixing ratio and processing instructions on the chemical vessel.

  • Page 6: Instructions On Machine Operation

    FREDETTE Instructions on Machine Operation...
  • Page 7 FREDETTE Control system Power key switch When the key is turned to the ON position, the vehicle power is turned on, and when the key is turned to the OFF position, the power is turned off. Manual/automatic switch button Button panel manual/automatic buttons can enter and exit the automatic state.
  • Page 8 FREDETTE Power display Display the current battery power, this light will be on as long as the machine is turned on, the power meter displays the power from right to left. The rightmost is the highest voltage. When the voltage is as low as 20.5V, stop the brushing, suction, and water spray functions, and retain the driving function.

  • Page 9: Reception Of Machine

    FREDETTE ECO button When the ground is relatively flat and there is little dirt, you can press this button to work, work under this function, the vehicle can save energy and extend the use time of the machine. Press again to exit the energy saving mode.

  • Page 10: Battery Installation

    FREDETTE Battery Installation Warning: fire or explosion hazard. The battery releases hydrogen. Please be away from spark or open fire. The battery cover must be kept open when charging. For safety: Please wear protective gloves and eye protectors when treating the battery and battery wiring when repairing the machine.

  • Page 11: Information On Brush And Scouring Pad

    FREDETTE In f o r m a t i o n on Br u s h a n d Scouring Pa d To ensure the optimum efficiency, please use the correct type of brush for cleaning. The brush and scouring pad suggested for use are as follows: Soft nylon brush (white) - It is suggested to clean the coated floor without damaging the floor.
  • Page 12 FREDETTE the flange buckle. Keep your hands away from the disk brush without falling off. Make sure that the panel is in manual working state, and then press the brush to press the key. After the brush is lowered to the ground, the system will automatically start to rotate, and at the same time, the brush is installed.

  • Page 13: Machine Operation

    FREDETTE Machine Operation Pre-operational Examination Check the water volume of the water volume scale tube, if the water volume is insufficient, you should add the appropriate amount of water beforeoperating; Close the water tank cover, make sure that the water tank cover is properly closed, and form a preliminary seal.

  • Page 14: Machine Operation Complete

    FREDETTE If there is too much foam in the sewage tank, please use the defoaming liquid to pour into the sewage tank for defoaming. In the process of working, you must observe the power display meter at any time. When the voltage is as low as 20.2V, the last two grids of the power flash continuously.

  • Page 15: Machine System&Maintenance

    FREDETTE Battery charging Place the charger and the machine in a well-ventilatedplace. Turn off the power of the machine. Plug the AC power cord of the charger into a well-grounded power outlet. Insert the DC output terminal of the charger into the charging port of the seat bucket of the machine.
  • Page 16 In the manual state, the brush plate button can be turned on and off independently. When the brush plate button is pressed, the brush plate pusher motor turns on and lowers the brush plate FREDETTE assembly. When the brush plate assembly is lowered to the ground, the brush plate begins Rotate to work.

  • Page 17: Water Absorption System

    FREDETTE 2.Water absorption system Schematic diagram Sewage suction pipe hole: It is an important part of sewage suction, connecting the squeegee assembly and the sewage tank hose. The squeegee rotating frame: used as a conductive bridge for squeegee components to go straight, turn and return.

  • Page 18: Waterway System

    FREDETTE spraying are all started, but the function in the automatic state is linked to the driving and walking. This function will only work when the current line is in progress. When it stops moving, the corresponding function will also stop working.

  • Page 19: Periodic Inspection

    FREDETTE Method of operation The vehicle waterway system and cleaning system are designed to work synchronously. In the manual state, the water release button can be independently turned on and off, and at the same time, the water volume can be adjusted independently.

  • Page 20: Monthly Maintenance (Every 80Hours)

    FREDETTE as required 4. Dismantle the scouring pad/brush for cleaning. If there is any abrasion, overturn or replace the scouring 5. Wipe the squeegee adhesive tape. Place the squeegee component in the rising position to avoid damage to adhesive tape.
  • Page 21 FREDETTE When the machine is operated for a period of time, the battery power will drop. When the last display of the power indicator flashes, it means that the power is insufficient and it needs to be charged in time.

  • Page 22: Troubleshooting

    FREDETTE Troubleshooting Fault Code source Fault description Possible cause of failure display 1. The emergency stop switch on The LCD Emergency stop signal wrong [01] the LCD panel is not short- panel connected; 1. CAN communication line The LCD CAN dropped error...

  • Page 23: Machine Fault Code Analysis

    FREDETTE 1. Short circuit at controller output of brush motor,or suction motor,or Control panel Relay connection failure 2 [33] brush lifting motor, or water-scraper lifting motor; 1. Short circuit of walking motor;2. Control panel VDD short circuit fault 1 [34] Internal fault of the controller;...
  • Page 24 FREDETTE 1. The temperature of the drive circuit module of the suction motor in the controller is too high (the The temperature sensor of Control panel [55] operation time of the suction motor suction motor is different exceeds the rated power is too...

  • Page 25: Machine Parameters

    FREDETTE Machine Parameters Parameters of AR-S10 Driving Scrubber Technical parameter UNIT AR-S10 Productivity M2/H 6500 Squeegee width 1350 Cleaning width 1060 Clean water tank capacity Waste water tank capacity Battery 36V/200A Brush motor 550*2 Vacuum motor Gradeability Noise level DB(A)
  • Page 26 FREDETTE Warranty Card of Series Products Card No.: User Name: Telephone No.: Address: Postcode: Purchase Date: Invoice No.: Item No.: Serial No.: Spare Part: Trouble Description: Signature of Dealer 1. This document will be confirmed under the signature of dealer.

  • Page 27: Certificate Of Test Approval

    FREDETTE Certificate of TestAppr ova l Cable: ☑ Charger: ☑ Batteries: ☑ Switch: ☑ Outside: ☑ Fittings: ☑ Speed: ☑ Control: ☑ Fuselage: ☑ Operation: ☑ Manual: ☑ Packing: ☑ QC by: ☑ Date: □ Customer acceptance: □ Date: □...
