Summary of Contents for evergreen energy homely CEF9H7TC3FE Series
- Page 1 Homely System Installation Manual Daikin Any outdoor unit models from C series onwards (aside from all ERGA models and CA series ERLQ)
- Page 2 Safety Symbols The following symbols are used in this manual. Hazards or unsafe practices DANGER that may result in electric shock and severe personal injury or death. Hazards or unsafe practices WARNING that may result in severe personal injury or death. Safety Information Before proceeding, ensure that all power supplies in the...
-
Page 3: Table Of Contents
About this Manual Contents Installation Requirements This manual has been developed to make installation of the Homely system a straightforward process. Pre-Installation Checks Follow the steps illustrated in the following pages to ensure that the Homely device is installed safely and correctly. Installer’s Notes Scan the QR code below to visit our YouTube channel where you will find further information about Homely, as well as... -
Page 4: Installation Requirements
Installation Requirements Items Supplied Items Required But Not Supplied HOMELY INSTALLER DATA CABLE BELDEN 8723 OR STRANDED CAT-5 RECOMMENDED HOMELY NODE HOMELY HUB 5V POWER Tools Required SUPPLY MODBUS WIRE 2 X CRIMP PLIERS ADAPTER NODE STICKER STRIPPERS FERRULE MULTIMETER 120-OHM 15V POWER STICKY PAD... -
Page 5: Pre-Installation Checks
Pre-Installation Checks Installer’s Notes Use this space to record any Before starting the Homely installation, ensure that the observations about the installed system. heat pump has been installed in accordance with the manufacturer’s instructions. -
Page 6: Step 1: Install The Modbus Adapter
STEP 1: Install the Modbus Adapter Connect to the P1/P2 terminals at either end of the device chain. Refer to Daikin manual for wire specification. The Daikin controller is connected to the outdoor unit via a 2-wire P1/P2 connection as shown below. Optionally, a wired thermostat may also be connected via P1/P2, extending the chain of devices. -
Page 7: Step 2: Connect The Homely Hub
STEP 2: Connect the Homely Hub For systems with a secondary system pump, use the DCOM Relay 1 output (terminals 6 & 7) to drive the pump. The pump must comply with the following requirements: • The pump must have built-in safety mechanisms so that it will not operate in the case of a fault condition (e.g., overheating). - Page 8 STEP 3: Connect the Homely Hub Connect the Homely Hub to the Daikin controller/outdoor unit with data cable. Belden 8723 or stranded Cat-5 are recommended. Remove the back of the Homely Hub and identify the terminals for Modbus connection. A single twisted pair must be used. Connect the A terminal in the Homely Hub to terminal 3 on the Modbus adapter.
-
Page 9: Step 3: Connect The Power Supply
STEP 4: STEP 5: Connect the Power Supply Controller Configuration Connect the power supply to the Homely Hub as shown and plug into a power outlet. Plug the Modbus adapter power supply into a power outlet. On the controller, scroll to the “User Profile” setting with the left wheel and select with the left button. -
Page 10: Step 4: System Configuration
STEP 6: System Configuration Download Go to “Installer Settings” and select with the left button, then “Configuration Wizard”, then “OK”. the Homely Installer App In the wizard, choose your preferred language, then set and register the time and date. Use the right wheel to select individual parameters and the right button to confirm them, then the an account left button to confirm all time &... -
Page 11: Specifications
Specifications Homely Hub Homely Node Dimensions: Dimensions: 86 x 86 x 25mm 43 x 43 x 14mm Communication protocols: Communication protocols: Proprietary 868MHz Proprietary 868MHz Bluetooth v4.2 WiFi 802.11 b/g/n Power: Internal: CR2450 battery Power: 1.0A Temperature Sensor Accuracy: Internal: 0.4 ºC (max), 10 to 85 ºC Recommended operating conditions: 10 to 35 ºC Humidity Measurement:... - Page 12 – EMC requirements – Part 1: General requirements EN 62368-1:2020 Audio/video, information and communication technology equipment – Part 1: Safety requirements Signed for and on behalf of Evergreen Energy Ltd: Name: Steve Elliott Function: Technical Director Place of issue:...
- Page 13 – EMC requirements – Part 1: General requirements EN 62368-1:2020 Audio/video, information and communication technology equipment – Part 1: Safety requirements Signed for and on behalf of Evergreen Energy Ltd: Name: Steve Elliott Function: Technical Director Place of issue:...
- Page 14 Printed on FSC-certified paper Hub v3 Rev 1.4 June 2023...
