Summary of Contents for KING WATER FILTRATION KW-ECOX 1235
- Page 1 O W N E R ' S M A N U A L ECO-X 7-Stage Non Backwashing Municipal Water Treatment System M O D E L S : K W - E C O X 1 2 3 5 / 1 0 5 4 / 1 2 5 2...
-
Page 2: Table Of Contents
K I N G W A T E R F I L T R A T I O N K W - E C O X - 1 2 3 5 / 1 0 5 4 / 1 2 5 2 A L L - I N - O N E W H O L E H O U S E W A T E R F I L T R A T I O N A N D C O N D I T I O N I N G S Y S T E M TABLE OF CONTENTS Table of Contents... -
Page 3: Important Information
• These codes are established for your protection. Check with your local public works department for current plumbing codes. • Installation errors can cause property damage. King Water Filtration® assumes no liability whatsoever for systems improperly installed or those installed by someone other than a licensed plumber or qualified contractor. -
Page 4: Product Specifications And Operation Parameters
PRODUCT SPECIFICATIONS AND OPERATION PARAMETERS ECOX-1054 Specification Description ECOX-1235 ECOX-1252 10 GPM Rated Service Flow Rate 10 GPM 15 GPM 12 GPM Peak Flow Rate 12 GPM 18 GPM 20 PSI Min Water Pressure 20 PSI 20 PSI 80 PSI Max Water Pressure 80 PSI 80 PSI... -
Page 5: Parts List
PARTS LIST Note: King Water supplies the following items below: Table 1: Parts List MODELS: KW-ECOX-1235 / 1054 / 1252 Note: Images above are for representation purposes only and are not intended to be depicted to scale. Additional fittings, materials and supplies will likely be needed for your installation. ***PLEASE TAKE NOTE: Valve head on top of tank may loosen during transit. -
Page 6: How To Properly Level Your Eco-X System
HOW TO PROPERLY LEVEL THE ECO-X SYSTEM It is important to do this step BEFORE you fill the tank with water as it will be very difficult to lift once it i s full. Note that the black base of the filtration tank is not permanently attached to the rest of the tank. If your tank appears to be crooked, the base has likely been knocked out of alignment during shipping. -
Page 7: Installation Preparation
INSTALLATION PREPARATION Bypass Valve Installation The Bypass Valve comes assembled and ready to install with the O-Rings, Split Rings, and Quick Connect Fittings in place. Apply food grade silicone grease to the o-rings and push the Bypass Valve all the way into the valve head, hand-tighten the Quick Connect Toolless Connectors until they are fully seated and secured to the bypass valve, (Use a firm grasp with both hands to ensure secure fitment). -
Page 8: Water Filter- Media Soaking Procedure
WATER FILTER- MEDIA SOAKING PROCEDURE VERY IMPORTANT STEP The carbon should be soaked for 48 hours prior to flushing. Here are the steps: 1. Install the included "Hose Bib Purge Kit w/ flow adaptor" as shown on the “UPFLOW or INLET”... - Page 9 WATER SYSTEM FLUSHING PROCEDURE DO NOT Flush the system until it has been soaking for a minimum of 48 hours as instructed in previous page. Perform the following in an area where running water can flow on the the ground, or into a drain, for an extended period. 1.
- Page 10 WATER SYSTEM FLUSHING PROCEDURE 5. Remove the Hose Bib Assembly from the OUTLET side of the Bypass Valve and attach it to the INLET side of the Bypass Valve. (By doing this we will be flushing the media downward, resetting the systems media and preparing it for operation). 6.
-
Page 11: Installation Procedures
INSTALLATION PROCEDURE Bypass Valve Fittings Determine the size and material of your incoming water supply and choose the appropriate plumbing required to adapt to the 1” Male NPT Assembly of the ECO-X system. Do not over-tighten any of the fittings during installation. Note: The fitting below is designed with a ¼"... -
Page 12: Bypass Valve Settings
BYPASS VALVE SETTINGS Figure A - Shows the valve in "Service Mode" which allows water to flow through the filtration & conditioning system. For ease of reference, this should be considered as the "ON" Position. Figure B - Shows the valve in "Bypass Mode" this setting bypasses the filtration & conditioning system and the water will bypass the system and flow directly to the home untreated as it bypassed the system. -
Page 13: Post Installation "To Do's
POST INSTALLATION "TO DO'S" Avoid high flow rates such as bathtub, utility sinks, hose bibs, multi- headed showers, body sprayers, or anything that is considered high flow for the first 72 hours to avoid flow restrictions. Carbon dust may be released into the water lines of the house/building during the first few days of water use after carbon tank installation. -
Page 14: Expectations
EXPECTATIONS Expectations for your new salt-free whole home filtration and conditioning system If a water softener was NOT previously installed: After installation, you will notice a much cleaner, healthier, better tasting conditioned water. Soaps and detergents will lather and perform better than with untreated water. Scale build up inside your plumbing system will begin to dissolve and break free. - Page 15 EXPECTATIONS Expectations for your new salt-free whole home filtration and conditioning system If you are switching from a traditional salt based water softener, you may noticed some differences, such as: • The water may not feel as soft or slippery. Being water softeners remove calcium and replace the calcium with salt, the absence of the calcium makes the water feel slippery and slimy.
-
Page 16: Tips For Maximum Performance And Fyi's
TIPS FOR MAXIMUM PERFORMANCE AND FYI'S Evaporative Spotting is Normal Remember, the beneficial minerals have been from a bicaronate to a carbonate and left in your water. These conditioned minerals will be easier to wipe up than unconditioned minerals, however if water is left to accumulate and evaporate time and time again on hard surfaces, evaporative spotting will begin to form. -
Page 17: Testing For Water Hardness And Tds
***Testing for Water Hardness and TDS (Total Dissolved Solids) King Water Filtration Water Treatment Systems are designed to keep the beneficial minerals in your water, this helps provide a healthy pH balanced drinking water. When testing for water... -
Page 18: Does The Eco-X Remove Tds From Water
DOES THE ECO-X "SALT-FREE" FILTRATION & CONDITIONING SYSTEM REMOVE TDS FROM WATER? The Answer is No, and Here is Why? We get this question often and this can help explain your TDS meter's Parts Per Million or"PPM" readings. Our multi stage municipal water filters utilize redox and adsorptive technologies to remove potentially detrimentally affecting contaminants from your drinking water. -
Page 19: Troubleshooting
TROUBLESHOOTING... -
Page 20: Shipping Policy
Refused Shipments If an item is refused upon delivery at no fault of King Water Filtration®, we may at our own discretion, charge the customer for ALL shipping fees, both to and from the destination address. King Water Filtration® cannot be liable for the shipping charges if the item is refused before delivery. -
Page 21: Return Policy
General Return Policy We will accept return of King Water Filtration® brand items if unused and in their original condition within 30 days of delivery for a full refund of your purchase price. Shipping and Brokerage charges are not refundable. -
Page 22: Return Procedure
Return Shipping King Water Filtration® may, at our discretion, send you a pre-paid return label for you to return your product. If you use this mailing label and the return is a result of our error (you received an incorrect or defective item, etc.), we’ll pay the return shipping costs. -
Page 23: Warranty
King Water Filtration's trademarks and exchange dress may not be utilized as a part of association with any item or administration that isn't King Water Filtration® or the property of King Water Filtration® in any way that is probably going to cause perplexity, or in any way that criticizes or disparages King Water Filtration®. -
Page 24: Claim Information
WARRANTY REGISTRATION AND CLAIM INFORMATION Scan QR Code to fill out your Owner Warranty Registration Visit us at https://kingwaterfiltration.com/apps/product-registration To view the latest edition of the Whole Home Municipal and Well Water Treatment Systems and for further assistance visit us at www.KingWaterFiltration.com Please call customer service at 855-957-2166.
