Summary of Contents for AvaValley 193W4GD15
- Page 1 User Manual 09/2023 Glass-Sided Wine Merchandiser Single Section #193W4GD15 81 Bottles Note: AvaValleyRefrigeration.com You should read this manual in its entirety prior to equipment setup, operation, and maintenance.
- Page 2 User Manual Glass-Sided Wine Merchandiser Warnings DANGER – RISK OF FIRE OR EXPLOSION. FLAMMABLE REFRIGERANT USED. TO BE REPAIRED ONLY BY TRAINED SERVICE PERSONNEL. DO NOT PUNCTURE REFRIGERANT TUBING. PELIGRO – RIESGO DE INCENDIO O EXPLOSION. REFRIGERANTE INFLAMABLE UTILIZADO. PARA SER REPARADO SOLAMENTE POR PERSONAL DE SERVICIO CALIFICADO.
-
Page 3: Before Installation
User Manual Glass-Sided Wine Merchandiser Installation This unit is intended for use in a temperature-controlled environment of less than 75°F and 60% relative humidity. Malfunction due to improper conditions is not covered under warranty. Before Installation • If the unit has recently been transported on its side, please let unit stand upright for a minimum of 24 hours before plugging it in. -
Page 4: Safety Information
User Manual Glass-Sided Wine Merchandiser Electrical • Ensure that the required voltage is being supplied at all times. • The unit should be plugged into a grounded and properly-sized electrical outlet with appropriate over-current protection. Refer to the electrical requirements on the unit's nameplate. •... -
Page 5: Front Panel Operation
User Manual Glass-Sided Wine Merchandiser Operation Refrigerant Front Panel Operation Temperature Defrost °F °F Adjusting the Temperature 1. Press the SET button to begin adjusting temperature. 2. Press the ▲ or ▼ buttons to increase or decrease the temperature inside the unit. 3. -
Page 6: Loading Product
User Manual Glass-Sided Wine Merchandiser Operation Loading Product • DO NOT block the air duct/fan at the top of the unit. Always maintain a minimum of 4" of clearance between products and the fan. • Ensure all shelves are sitting level and properly secured before loading products. •... -
Page 7: Cleaning The Condenser Coil
User Manual Glass-Sided Wine Merchandiser Cleaning DISCONNECT POWER CORD BEFORE CLEANING ANY PARTS OF THE UNIT. It is strongly recommended that any servicing of the unit be performed by an authorized service technician. Fan Blades & Motor • If necessary, clean the fan blades and motor with a soft cloth. •... -
Page 8: Troubleshooting
User Manual Glass-Sided Wine Merchandiser Troubleshooting Problem Possible Cause Possible Solution Fuse blown or circuit breaker tripped. Replace fuse or reset circuit breaker. Power cord unplugged. Plug in power cord. Compressor not running. Thermostat set too high. Set thermostat to lower temperature. Cabinet in defrost cycle.
