Wine/Beverage
Refrigerators
Single Temperature
Single Glass Door
#342WRC20SZ
20 Bottles
#342WRC32SZ
32 Bottles
#342WRC46SZ
46 Bottles
#342WRC128SZ
128 Bottles
#342WRC165SZ
165 Bottles
#342WRC220SZ
220 Bottles
#342BRC52SZ
52 Cans
#342BRC78SZ
78 Cans
#342BRC84SZ
84 Cans
Dual Solid Drawers
#342BDR84SZ
84 Cans
Note:
AvaValleyRefrigeration.com
You should read this manual in its entirety prior to equipment setup, operation, and maintenance.
User Manual
Dual Temperature
Single Glass Door
#342WRC20DZ
17 Bottles
#342WRC32DZ
32 Bottles
#342WRC46DZ
46 Bottles
#342WRC128DZ
128 Bottles
#342WRC165DZ
165 Bottles
#342WRC220DZ
220 Bottles
Dual Glass Doors
#342WBRC20DZ 20 Bottles/51 Cans
#342WBRC32DZ 32 Bottles/126 Cans
Glass Door/Solid Drawer Combo
#342DSR20DZ
22 Bottles/70 Cans
08/2023
Advertisement
Table of Contents
Summary of Contents for AvaValley 342WRC20SZ
- Page 1 User Manual 08/2023 Wine/Beverage Refrigerators Single Temperature Dual Temperature Single Glass Door Single Glass Door #342WRC20SZ 20 Bottles #342WRC20DZ 17 Bottles #342WRC32SZ 32 Bottles #342WRC32DZ 32 Bottles #342WRC46SZ 46 Bottles #342WRC46DZ 46 Bottles #342WRC128SZ 128 Bottles #342WRC128DZ 128 Bottles #342WRC165SZ...
- Page 2 User Manual Wine Refrigerators Warnings DANGER – RISK OF FIRE OR EXPLOSION. FLAMMABLE REFRIGERANT USED. TO BE REPAIRED ONLY BY TRAINED SERVICE PERSONNEL. DO NOT PUNCTURE REFRIGERANT TUBING. PELIGRO – RIESGO DE INCENDIO O EXPLOSION. REFRIGERANTE INFLAMABLE UTILIZADO. PARA SER REPARADO SOLAMENTE POR PERSONAL DE SERVICIO CALIFICADO.
-
Page 3: Before Installation
User Manual Wine Refrigerators Installation This unit is intended for use in a temperature-controlled environment of less than 75°F and 60% relative humidity. Malfunction due to improper conditions is not covered under warranty. Before Installation • If the unit has recently been transported on its side, please let unit stand upright for a minimum of 24 hours before plugging it in. - Page 4 User Manual Wine Refrigerators Installation Changing Door Swing Direction • The door of your appliance has the capability of opening from either the left or the right side. • The unit is delivered to you with the door opening from the left side. If you desire to reverse the opening direction, follow the instructions below before modifying.
- Page 5 User Manual Wine Refrigerators Installation 7. On the bottom of the door, 8. Move the stop plate from the 9. Use a utility knife to remove remove the placeholder screws right side to the left side and metal handle hole covers. Swap on the left side.
-
Page 6: Structure & Components
User Manual Wine Refrigerators Structure & Components Single Temperature (342WRC__SZ Models) Reversible Upper Hinge Control Panel Cold Air Fan Sensor Odor Filter Glass Door Exhaust Vents Door Seal Removable Wooden Shelves Reversible Lower Hinge Kick Plate Feet Single Temperature (342BRC__SZ Models) Reversible Upper Hinge Control Panel... - Page 7 User Manual Wine Refrigerators Structure & Components Dual Temperature (342WRC__DZ Models) Reversible Upper Hinge Removable Wooden Shelves Cold Air Fan Glass Door Odor Filter Sensor Exhaust Vents Door Seal Control Panel Reversible Lower Hinge Kick Plate Feet Dual Temperature (342WBRC__DZ Models) Control Panels Upper Hinges Cold Air Fans...
- Page 8 User Manual Wine Refrigerators Structure & Components Dual Temperature (342DSR20DZ Model) Reversible Upper Hinge Control Panel Odor Filter Sensor Glass Door Removable Wooden Shelves Door Seal Exhaust Vents Reversible Lower Hinge Cold Air Fan Drawer Kick Plate Feet Electrical • Ensure that the required voltage is being supplied at all times. •...
-
Page 9: Operation
User Manual Wine Refrigerators Operation Adjusting the Temperature • The controller will lock after 10 seconds of no use. To unlock controller, hold the unlock button for 5 seconds until there is a beep. If this does not work, unplug the unit and plug it back in. If the controller still does not allow you to adjust temperature, the digital controller is the problem. -
Page 10: Loading Product
User Manual Wine Refrigerators Operation Loading Product • DO NOT block the air duct/fan at the top of the unit. Always maintain a minimum of 4" of clearance between products and the fan. • Ensure all accessories are sitting level and properly secured before loading products. •... -
Page 11: Safety Information
User Manual Wine Refrigerators Safety Information Pay close attention to the safety notices in this section. Disregarding these notices may lead to serious injury and/or damage to the unit. • To minimize shock and fire hazards, be sure to not overload outlet. This unit should be given its own outlet. •... -
Page 12: Cleaning The Condenser Coil
User Manual Wine Refrigerators Cleaning DISCONNECT POWER CORD BEFORE CLEANING ANY PARTS OF THE UNIT. It is strongly recommended that any servicing of the unit be performed by an authorized service technician. Fan Blades & Motor • If necessary, clean the fan blades and motor with a soft cloth. •... -
Page 13: Troubleshooting
User Manual Wine Refrigerators Troubleshooting Problem Possible Cause Possible Solution Fuse blown or circuit breaker tripped. Replace fuse or reset circuit breaker. Power cord unplugged. Plug in power cord. Compressor not running. Thermostat set too high. Set thermostat to lower temperature. Cabinet in defrost cycle.
