13. TECHNICAL DATA ............23 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler –...
ENGLISH 1. SAFETY INFORMATION Before the installation and use of the appliance, careful- ly read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use cau- ses injuries and damages. Always keep the instructions with the appliance for future reference. 1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly quali- fied persons in order to avoid a hazard. • The operating water pressure (minimum and maxi- mum) must be between 0,5 bar (0,05 MPa) and 8 bar (0,8 MPa) •...
Page 5
ENGLISH Water connection • Do not put a container to collect pos- sible water leakage under the appli- • Make sure not to cause damage to the ance. Contact the Service to ensure water hoses. which accessories can be used. •...
3. PRODUCT DESCRIPTION Control panel Door handle Rating plate Drain pump filter Feet for the appliance level 3.1 Fixing plate kit (4055171146) Use this special accessory, when you in- stall the appliance on a plinth. It prevents the movements of the appli- ance when it operates.
ENGLISH 4.1 Display The temperature area: – : the spin phase – – : Temperature indicator : the child safety lock – – : Cold water indicator. : the Door locked The spin area: – : the delay start. – : the Spin speed indicator The time area: –...
Page 8
Programme Type of load and soil Temperature range Maximum load, Maximum spin Feinwäsche Delicate fabrics as acrylics, viscose, polyester 40°C - Cold items. Normal soil and light soil. 3.5 kg, 1200 rpm Machine washable wool, hand washable wool Wolle/Seide and delicate fabrics with «hand washing»...
Page 9
ENGLISH Type of load Max. load Programme Temperature Cotton and synthetic items. up to 1.5 Kg Steam – Glätten This programme helps to dew- rinkle the laundry. 40 °C Steam can be used for dried, washed or worn once laundry. These pro- grammes can reduce creases and odours and make your laundry more smooth.
10 www.aeg.com Programme ■ ■ 20 Min. - 3 kg ■ ■ ■ ■ ■ ■ Baumwolle Eco 1) If you set No Spin option the only drain phase is available. 6. CONSUMPTION VALUES At programme start the display shows the duration programme for the max- imum load capacity.
ENGLISH Programmes Load Energy con- Water con- Approxi- Remaining (Kg) sumption sumption (li- mate pro- moisture (kWh) tre) gramme duration (minutes) Standard 40 0.52 °C cotton 1) At the end of spin phase. Off Mode (W) Left On Mode (W) 0.48 0.48 The information given in the chart above are in compliance with the EU Com-...
12 www.aeg.com • Press this button one time to set • Before you press Start/Pause: the ap- 'Shortened duration' for items with pliance cannot start. daily soil. • Press this button two times to set 'Ex- 7.8 Permanent extra rinse...
ENGLISH 9. DAILY USE 9.1 Loading the laundry Open the appliance door. Put the laundry in the drum, one item at a time. Shake the items be- fore you put them in the appliance. Make sure not to put too much laun- dry in the drum.
Page 14
14 www.aeg.com Liquid or powder detergent • Position A for powder detergent (factory setting). • Position B for liquid detergent. When you use the liquid detergent: – Do not use gelatinous or thick liquid detergents. – Do not put more liquid then the maximum level.
Page 15
ENGLISH 9.5 Starting a programme Press Start/Pause. The indicator flashes. without delay start Change the options. Press Start/Pause: Press Start/Pause again. The pro- • The indicator Start/Pause stops to gramme continues. flash and stays on. • The indicator 9.8 Cancelling a programme starts to flash on the display.
16 www.aeg.com Close the appliance door. Press Start/Pause. The appliance drains the water and spins. Set the programme again. When the programme is comple- ted and the door lock indicator 9.11 At the end of the goes off, you can open the programme door.
ENGLISH – Use a washing bag to wash small • If your appliance has not the deter- items. gent dispenser with the flap device, add the liquid detergents with a dos- • A very small load can cause balance ing ball. problems with the spin phase.
Page 18
18 www.aeg.com 11.3 Maintenance wash • Remove the laundry from the drum. • Set the cotton programme with the With the low temperature programmes it highest temperature with a small is possible that some detergent stays in quantity of detergent.
Page 20
20 www.aeg.com 11.7 Cleaning the inlet hose and the valve filter 45° 20° 11.8 Emergency drain Put 2 litres of water in the main wash compartment of the detergent dis- Because of a malfunction, the appliance penser. cannot drain the water.
ENGLISH Disconnect the mains plug from the When the drain pump is empty, in- mains socket. stall the inlet hose again. Close the water tap. WARNING! Remove the water inlet hose. Make sure that the temperature is more than 0 °C before you use Put the two ends of the inlet hose in the appliance again.
Page 22
22 www.aeg.com Problem Possible solution Make sure that the filter of the inlet hose and the filter of the valve are not clogged. Refer to “Care and clean- ing”. Make sure that the inlet hose has no kinks or bends.
ENGLISH Problem Possible solution The appliance fills Make sure that the drain hose is in the correct position. with water and drain The hose may be too low. immediately. The cycle is shorter The appliance calculates a new time according to the than the time dis- laundry load.
Page 24
24 www.aeg.com 14. ENVIRONMENT CONCERNS Recycle the materials with the appliances. Do not dispose symbol . Put the packaging in appliances marked with the symbol applicable containers to recycle it. with the household waste. Return the Help protect the environment and...
