Summary of Contents for Fun & Function SC7259
- Page 1 Custom Corner Bubble Tube Area SC7259 User Manual 82722 September 2022...
-
Page 2: Table Of Contents
Contents Warnings Description Includes Installation 5-13 Connecting the Power Cleaning and Maintenance Guarantee Technical Contact us... -
Page 3: Warnings
Warnings All our equipment is designed for users with special needs. We suggest supervision at all times when using this equipment. For indoor use only. The panel uses a mains power supply. Do not use any other power cord than the one supplied. The platform is designed to support no more than 275 lbs. - Page 4 Pieces and Hardware 1 x LH Wall panel 1 x RH Wall panel 1 x Top Part Number 1 Part Number 2 Part Number 3 Front Front 1 x Platform Panels are Identified viewing from front edge 12 x 6 mm Screws 12 x 6 mm Washers Power Cord Note: 8 x 6 mm screws and washers are required for this installation.
-
Page 5: Installation
Installation The sensory equipment connects to a power supply. All the connecting cables are pre-installed in the top section and the platform. Connect the power cord to the equipment and install all the cables before the corner is pushed into the final corner position and attached to the wall. Corner Placement DO NOT use as standalone equipment. - Page 6 • Screw 2 x corner brackets to the top (A) and bottom (B) of the panel using 4 x 6mm washers Step 2 and 4 x 6 mm screws. Some models will already have these brackets fitted to them. Part 2...
- Page 7 Step 3 Take the LH Wall Panel (Part 1) and stand on its end with edge packer on the right side while • looking at the back. Attach 1 x corner bracket and use 2 x 6mm washers and 2 x 6mm screws. •...
- Page 8 Part 3 Step 4 Place Top (Part 3) and align holes. Screw 4 x 6mm washers and 4 x 6mm screws into holes identified with arrows. Holes are Holes on top Holes are identified identified with arrows. with arrows. Part 2 Part 1 RH Wall panel LH Wall panel...
- Page 9 Step 5 Remove cover from top by detaching the Velcro closures . Fiber Optic Lightsource is secured in place with a Velcro strip (not shown). The Fiber Optic harness is pre-installed (not shown). Step 6 Move the entire corner piece near the final location and rotate so the plinth can be installed. Velcro Tabs Velcro Tabs...
- Page 10 Step 7 • Push the Platform into the corner created by part 1 and part 2 wall panels. • Attach the velcro tabs to the wall panels Velcro Tabs Step 8 Remove seating area of the platform by lifting up on it. The Velcro closures will need to be gently but firmly pulled apart.
- Page 11 Installing the Power Cables The power cables are all flexible cables fitted with IEC plugs and sockets. They are fed from the top section behind the wall panels and into the platform and to the power cord. IEC Plugs and sockets Top Section Panel 1 1 ) Carefully draw the two IEC cables out of the...
- Page 12 3 ) Plug the other lead from the top section labeled “B” and connect to the cable fastened to RH wall panel 2. Cable C is used to supply power to other pieces of equipment you may buy in the future. It should be tucked out of the way if not in use.
-
Page 13: Connecting The Power
Attaching to the Wall The panels must be installed to a permanent wall of solid construction. The panels have wall brackets, but screws or wall anchors are not provided. Your professional installer will need to use the appropriate screws and anchors for your type of wall to be attached to. Professional installation is highly recommended. Step 1 Attach panels to the wall using the four brackets. -
Page 14: Cleaning And Maintenance
Step 3 Mirrors are covered in a protective film. Carefully, peel the film away and dispose of it. Step 4 Connect the electrical supply to the mains power cord. Please refer to the Waterless LED Color Column and the Fiber Optic Strands with Lightsource instructions for further information. -
Page 15: Guarantee
Guarantee CONDITIONS OF GUARANTEE This guarantee is in addition to and does not in any way affect any statutory or other rights of consumer purchasers.If within the applicable guarantee period (as shown in 8 below) the appliance proves to be defective by reason of faulty design, workmanship or materials, we undertake subject to the following conditions to have the defective appliance (or any part or parts thereof) repaired or at our discretion replaced free of charge. -
Page 16: Technical
Electrical information The Custom Corner Bubble Tube Area uses no electrical power , it is a piece of furniture. When the sensory equipment is installed it uses an IEC mains lead to supply power to the equipment. Sensasoft LH Wall Panel - Weight 33 lbs. (15 KG) Sensasoft RH Wall Panel - Weight 33 lbs.
