Solitary Pour
User Instructions
INTRODUCTION
This product has been manufactured to the highest standards of performance
and safety, assuring your complete peace of mind.
IN THE UNLIKELY EVENT THAT YOU NEED TO REPORT AN ISSUE CONTACT
OUR HELPLINE DIRECT BEFORE RETURNING YOUR PRODUCT TO STORE.
PRODUCT SUPPORT | helpline: 01405 869333 | email: productsupport@ames-uk.com
45171L_Solitary Pour_IM.indd 1
45171L_Solitary Pour_IM.indd 1
45171L_Solitary Pour_User Guide_V1
Product code: 45171L
Height: 650mm
Width: 430mm
Depth:
510mm
Power Pump Supply: 220-240V - 50Hz
Power Pump Rating: 16W
Pump Ingress Protection Rating: IPX8
30/06/2021 14:42
30/06/2021 14:42
Advertisement
Table of Contents
Related Manuals for EASYFOUNTAIN Solitary Pour 45171L
Summary of Contents for EASYFOUNTAIN Solitary Pour 45171L
- Page 1 45171L_Solitary Pour_User Guide_V1 Solitary Pour User Instructions Product code: 45171L Height: 650mm Width: 430mm Depth: 510mm Power Pump Supply: 220-240V - 50Hz Power Pump Rating: 16W Pump Ingress Protection Rating: IPX8 INTRODUCTION This product has been manufactured to the highest standards of performance and safety, assuring your complete peace of mind.
- Page 2 SAFETY INFORMATION • The water pump must always be connected though a portable residual- current device (RCD), or a built-in residual current circuit breaker (RCCB), having a rated residual operating current not exceeding 30mA. (This level of electrical protection was first incorporated into UK homes built after 2001.) If in doubt consult a certified electrician.
- Page 3 PARTS LIST 1. Fountain part (x2) 2. Water Pump (x1) 3. Transformer (x1) ring lock *Actual pump and transformer may differ from images shown PLEASE FOLLOW THE STEPS BELOW BEFORE UNPACKING • Unpack with care onto a smooth surface to avoid scratching •...
- Page 4 ASSEMBLY INSTRUCTIONS Reach inside the opening in Connect the tubing to the Connect the two ends of the the rear of the fountain pulling outlet of the pump and place it L.E.D. lighting wires together out the tubing/water pipe and in the water reservoir through and screw over the plastic internal L.E.D.
- Page 5 TROUBLE SHOOTING WINTERCARE PUMPS • Check the water is covering the • If possible, bring your water feature indoors for example in a pump by at least 5cm. garage or shed during the winter • Check the flow dial on the pump or periods of extreme weather to ensure that an adequate flow conditions.
- Page 6 WARRENTY CONDITIONS COVERED UNDER WARRANTY NOT COVERED UNDER WARRANTY • If it has a crack or leak and has been reported within 28 days • Flickering lights caused by build- from purchase it is under warranty up of algae and limescale on the and should be returned complete connectors with electrics and accessories in...
- Page 7 • Removes dirt from your • Leaves a smear free water feature shine • Limescale buster Fountain One Shot Algae Remover 100g Please note: the easyfountain aftercare range ® 4596 is only available in the UK and Republic of • Easy to use Ireland.
- Page 8 PROOF OF PURCHASE YOUR DETAILS Name: Address: Tel: Email: Date of purchase: Purchased from: ATTACH PROOF OF PURCHASE HERE PRODUCT SUPPORT | helpline: 01405 869333 | email: productsupport@ames-uk.com 45171L_Solitary Pour_IM.indd 8 45171L_Solitary Pour_IM.indd 8 30/06/2021 14:42 30/06/2021 14:42...
