BioLAB BFCG-150-102 Operation Manual

-150 c cryogenic freezer chest type
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operation
Manual
BFCG-150-102
-150°C Cryogenic Freezer Chest type
Thank you for Choosing Biolab products. Please read the "Operating Instructions" and
"Warranty" before operating this unit to assure proper operation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BFCG-150-102 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BioLAB BFCG-150-102

  • Page 1 Operation Manual BFCG-150-102 -150°C Cryogenic Freezer Chest type Thank you for Choosing Biolab products. Please read the “Operating Instructions” and “Warranty” before operating this unit to assure proper operation.

  • Page 2: Table Of Contents

    -150°C Cryogenic Freezer Chest type BFCG-150-102 Index 1. Preface............................03 2. Features............................04 3. Precautions for Safe Operation ....................04 4. Handling considerations ......................11 5. Precautions of using ......................11 6. Ambient Conditions ........................14 7. Installation ............................14 8. Start-up of Appliance .........................15 9. Components ...........................17 10.

  • Page 3: Preface

    -150°C Cryogenic Freezer Chest type BFCG-150-102 Preface • Please read the Operation Manual carefully before operation for your safety. • We do not guarantee any safety if the appliance is used for any objects other than intended use or used by any procedures other than those mentioned in this manual.

  • Page 4: Features

    -150°C Cryogenic Freezer Chest type BFCG-150-102 Features • LCD touch screen controller, temperature range -40 ~-150 ℃ ℃ adjustable. • Multiple protection functions Compressor start delay protection, protection for high （ pressure of cooling system, protection of power phase sequence ）...
  • Page 5 -150°C Cryogenic Freezer Chest type BFCG-150-102 < Mark on the Appliance> This label is on the cover in which the electrical components of high voltage are enclosed to prevent the electric shock. The cover should be removed by a qualified engineer or a service personnel only.
  • Page 6 -150°C Cryogenic Freezer Chest type BFCG-150-102 < Mark on the Appliance> This label is marked around the door handle to indicate the door handle's opening and closing direction. Warning This appliance should only be installed by qualified engineers or service personnel.
  • Page 7 -150°C Cryogenic Freezer Chest type BFCG-150-102 corners. When removing the plug from the power outlet, hold the power plug firmly and do not pull the power cord. If you pull the cord by hand, it may cause electric shock or a short circuit that may cause a fire.
  • Page 8 -150°C Cryogenic Freezer Chest type BFCG-150-102 and warning label to operate, otherwise it may be dangerous or cause performance degradation. The product does not emit chemical substances, waste, or liquids. The product does not involve the storage life limit of the stored item.
  • Page 9 -150°C Cryogenic Freezer Chest type BFCG-150-102 alkalis may be stored in this equipment, otherwise it may cause corrosion of components and electrical components inside the box. If the container cannot be sealed, do not store volatile or flammable substances in the device. Doing so may cause an explosion or fire.
  • Page 10 -150°C Cryogenic Freezer Chest type BFCG-150-102 Do not touch stored objects directly with your hands. Direct contact with frozen objects or the inside of the equipment may cause frostbite. Wear antifreeze gloves. The patient does not control or affect the use of the product.

  • Page 11: Handling Considerations

    -150°C Cryogenic Freezer Chest type BFCG-150-102 Do not put your hand into the cabin space or the top space of the cabinet, otherwise there is a risk of electric shock. Do not store excessively high humidity items in the product. This can cause serious frosting on the evaporator and affect the cooling performance.
  • Page 12 -150°C Cryogenic Freezer Chest type BFCG-150-102 disk to make the supporting cushion and the floor support. • When the storage box is running, the surrounding of the storage box frame may become hot. This is not a malfunction. In order to prevent condensation around the box frame, a dew- proof tube was installed around the cabinet.
  • Page 13 -150°C Cryogenic Freezer Chest type BFCG-150-102 closing the door, wipe the ice water on the door seal to ensure a good sealing effect. Failure to do so may cause the temperature in the storage tank to remain below the set temperature, and at the same time reduce the frost on the evaporator and the inner wall of the tank.

  • Page 14: Ambient Conditions

    -150°C Cryogenic Freezer Chest type BFCG-150-102 Ambient Conditions • Ambient temperature 10 -32 . And the maximum temperature is no more than 32°C. ℃ ℃ ： The ideal temperature is 18 to 25°C. If necessary, an air conditioning system should be used.

  • Page 15: Start-Up Of Appliance

    -150°C Cryogenic Freezer Chest type BFCG-150-102 the diluted detergent, always wipe it off with a wet cloth. Then wipe off the panels with a dry cloth. Warning  Use a power supply outlet with ground (earth) to prevent electric shock. If the power supply outlet is not grounded, it is necessary to install a ground by qualified engineers.
  • Page 16 -150°C Cryogenic Freezer Chest type BFCG-150-102 • Due to the refrigeration inertia, there is a certain difference between the actual display temperature and the set temperature (the lower the set temperature, the smaller the difference will be, and vice versa), which is a normal phenomenon.

  • Page 17: Components

    -150°C Cryogenic Freezer Chest type BFCG-150-102 Components 1 Spin Button Spin to right-ON, Spin to left-OFF,(no Standby state).If the machine stops for ： a long time, please turn off the switch at the power supply 。 2 LCD Touch Screen: display all information, change set parameter 3 Current Temp: the actual temperature inside the cabinet.
  • Page 18 -150°C Cryogenic Freezer Chest type BFCG-150-102 14. Running time display: the total time of this power on. 15.Buzzer Off: Temporarily shut off the buzzer when alarming. 16 USB port: It can be connected to a U disk for data export.

  • Page 19: System Settings

    -150°C Cryogenic Freezer Chest type BFCG-150-102 12. Electric control box: do not open it without authorization. It must be opened by qualified engineers or professional maintenance personnel. 13. High and low pressure meter: display the high and low pressure value of the unit system.
  • Page 20 -150°C Cryogenic Freezer Chest type BFCG-150-102 15.2Clean condenser filter Filter replacement instructions, Please following the steps to clean the filter ： a. As shown in the picture, pull out the flip b. Get out of the filter net c. Clean the strainer with water and dry it d.

  • Page 21: Failure Recovery

    -150°C Cryogenic Freezer Chest type BFCG-150-102 Failure Recovery Please check the fault as following before notifying the repair service: Faults Checking/Solutions  Check the appliance if connect to the power supply?  Check if the power voltage is too low? The cabinet is not ...

  • Page 22: Specification

    -150°C Cryogenic Freezer Chest type BFCG-150-102 Disposal of Abandoned Appliance Warning • If the appliance is to be stored unused in the open area for an extended period, ensure that children don’t approach the appliance and the cabinet door can not be closed completely.

  • Page 23: Performance

    -150°C Cryogenic Freezer Chest type BFCG-150-102 Optional Parts Caution: • Design specifications are subject to change without prior notice. • The battery for power failure alarm is consumable; it is suggested to replace it every 3 years for once. To replace the battery, please contact the representative of us, agent or after-sale service.
  • Page 24 BIOLAB SCIENTIFIC LTD. 3660 Midland Avenue, Suite 300, Toronto, Ontario M1V 0B8 Canada Email: contact@biolabscientific.com Tel: +1 707 533 1445 Website: www.biolabscientific.com...
