- Page 1 SVF 1U Multimode State Variable Filter Manual (English) Revision: 2023.07.24...
-
Page 2: Table Of Contents
TABLE OF CONTENTS COMPLIANCE INSTALLATION Before You Start Installing Your Module FRONT PANEL Controls Jacks BACK PANEL TECHNICAL SPECIFICATIONS SVF 1U Manual... -
Page 3: Compliance
(2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by Intellijel Designs, Inc. could void the user’s authority to operate the equipment. Any digital equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. -
Page 4: Installation
INSTALLATION This module is designed for use within an Intellijel-standard 1U row, such as contained within the Intellijel Palette, or 4U and 7U Eurorack cases. Intellijel’s 1U specification is derived from the Eurorack mechanical specification set by Doepfer that is designed to support the use of lipped rails within industry standard rack heights. -
Page 5: Installing Your Module
Eurorack case. Ensure the red stripe on the cable lines up with the -12V pins on the bus board. On Intellijel power supplies the pins are labeled with “-12V” and/or a thick white stripe,... -
Page 6: Front Panel
( BP ) filter or a NOTCH filter. NOTE: The LP/HP trimmer on the back panel adjusts the LP/HP balance of the notch — altering the volume, sonic character and resonance produced by a notch filter. See BACK PANEL for more information. SVF 1U Manual... -
Page 7: Jacks
Jacks IN - Input to the SVF 1U module. PITCH CV In - CV input for controlling the cutoff frequency. This jack accepts 1 V/oct signals, and allows the CUTOFF frequency to track a keyboard or sequencer input. This is particularly useful when Q... -
Page 8: Back Panel
— but if you’d like the notch to have a different sonic characteristic, you can find it via this trimmer. TECHNICAL SPECIFICATIONS Width 20 hp Maximum Depth 35 mm Current Draw 27 mA @ +12V 30 mA @ -12V SVF 1U Manual...
