Max Machinery 286 Series Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Max Machinery, Inc. reserves the right to make changes to the product in this instruction manual to improve
performance, reliability, or manufacturability. Contact MMI for the latest available specifications and
performance data.
Although every effort has been made to ensure accuracy of the information contained in this instruction
manual, MMI assumes no responsibility for inadvertent errors.
INSTRUCTION MANUAL
286-300 SERIES TRANSMITTERS
286-313: Transmitter with Amphenol Connector
286-323: Transmitter, Weather-Tight, Explosion Proof*
286-3x4: Transmitter with Output Level Shifter Option
286-31x-5xx: Transmitter with Remote PCA

TABLE OF CONTENTS

General Description................................................... Pg 2
Specifications ............................................................ Pg 3
Mechanical Installation ............................................. Pg 4-5
Outputs, Options, and Indicators............................... Pg 6-8
Calibration................................................................. Pg 9-10
Maximum Transmission Distance............................. Pg 11-12
K-factors.................................................................... Pg 13
Appendix A: Remote Mount Transmitter ................. Pg 14-15
Schematics:
286-313-201 RVDT Schematic
181-000-250 Interconnect Schematic
* U.L. Class I, Group C & D
Class II, Group E, F & G
286-300-350 © 2002, Max Machinery, Inc.
nd
Rev: 4/03, added Appendix A and B
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 286 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Max Machinery 286 Series

Summary of Contents for Max Machinery 286 Series

  • Page 1: Table Of Contents

    286-300-350 © 2002, Max Machinery, Inc. Rev: 4/03, added Appendix A and B Max Machinery, Inc. reserves the right to make changes to the product in this instruction manual to improve performance, reliability, or manufacturability. Contact MMI for the latest available specifications and performance data.

  • Page 2: General Description

    The user can select from square wave outputs of 24, 50, 100, 200, 300, 500, 600 or 1000 pulses per revolution, or two-phase outputs of 12, 25, 50, 100, 150, 250, 300 or 500 pulses per revolution (on each phase). 286-300-350 © 2002, Max Machinery, Inc.

  • Page 3: Specifications

    15 mA on two outputs). Events are seen as output transitions 0.25 mS after they occur Temperature of metered fluid will affect transmitter temperature, see pg. 4 See pg. 8 for more information 286-300-350 © 2002, Max Machinery, Inc.

  • Page 4: Mechanical Installation

    It is a good idea to locate the transmitter away from hot spots such as steam pipes, ovens and heaters. The electronics of the 286 Series Transmitters are rated for operation up to 80° C (175° F). Because some heat travels from the flow meter to the transmitter electrical enclosure, the temperature of the electronics is a function of both the ambient and the flow meter temperature.
  • Page 5 1/2" NPT or Weather tight Amphenol Circuit Board Retaining Clamp Screw Ring LOOSEN TO ROTATE ELECTRICAL HOUSING O-Ring Wrench Flats Stator Assembly Rotor Assembly Transmitter - Flowmeter Threaded Connection O-Ring 210 Series Flow Meter 286-300-350 © 2002, Max Machinery, Inc.

  • Page 6: Outputs, Options And Indicators

    (see chart below). Terminal Output Signals vs. S4-2 Setting Connector S4-2 = 'COMB OUT' S4-2 = '2Ph' Terminal(s) (combined output) (2-phase output) Pulse Output Phase A Direction Phase B 286-300-350 © 2002, Max Machinery, Inc.
  • Page 7 1000 piston and gear style meters, reverse flow on helix meters). Indicated at * Not Specified, Usually same as S3=8 terminal 6 by a 5 VDC signal and the changing of D10 to green. 286-300-350 © 2002, Max Machinery, Inc.
  • Page 8 If the transmitter does not appear to be functioning correctly and this LED is on, the unit should be sent back to the factory for service. 286-300-350 © 2002, Max Machinery, Inc.

  • Page 9: Calibration

    Rotational Speed of Piston Meter Crankshaft At Constant Flow Crankshaft Angle 286-300-350 © 2002, Max Machinery, Inc.
  • Page 10 LED’s in the center of the board will pause. As soon as the calibration is complete, they will resume activity. 6. The calibration is now complete. Return S3 to the appropriate setting to get the desired number of output pulses per revolution. (10) 286-300-350 © 2002, Max Machinery, Inc.

  • Page 11: Maximum Transmission Distance

    Belden 8762 V1000 (20 GA), Belden 8723 (2 Shielded Pair) 7 Conductor Cable National Type N W718-J (18 GA) 4 16 Gauge Wires in EMT Conduit RG 59U Coaxial Cable Columbia 1112 Foam 0.01 1000 Cable Length (feet) 286-300-350 © 2002, Max Machinery, Inc. (11)
  • Page 12 286-313 Output Rise and Fall Time vs. Load Capacitance (rise and fall time measured between 10% and 90% of full output swing) 1000 0.001 0.01 Output Capacitance Load (uF) 286-300-350 © 2002, Max Machinery, Inc. (12)

  • Page 13: K-Factors

    K-factors represent the number of pulses the transmitter outputs per unit volume of fluid passing through the flow meter. This number is dependent on the flow meter and the transmitter resolution setting (switch S3). Max Machinery indicators can be adjusted to display the desired units (ccs, lbs, gallons, quarts, etc.) by using the K-factor.

  • Page 14: Appendix A: Remote Mount Transmitter

    The polycarbonate box has 0.175” dia. holes with space for a 0.265” or smaller head. The aluminum box has 0.185” holes with space for 0.300” or smaller head. An 8-32 socket head cap screw works well for both. (14) 286-300-350 © 2002, Max Machinery, Inc.
  • Page 15 S5: Calibrate Stator Offsets (and Angle). Need S3 in S4-1: Select Meter Type position 0 to start Calibration. Type S4-2: Output Select (2- Phase or Combined Output) 1000 * Not Specified, Usually same as S3=8 286-300-350 © 2002, Max Machinery, Inc. (15)

  • Page 16: Appendix B: Output Level Shifter Option

    Rise Time ................. 0.8 uS (90%) Fall Time .................. 1.0 uS (90%) Maximum Frequency .................60 kHz Minimum Frequency ................0 Hz Continuous Short Circuit is not recommended. The output current should not exceed 30 mA per output. (16) 286-300-350 © 2002, Max Machinery, Inc.
