- Page 1 ES-M1826C1-1...
- Page 2 LC-40Q3000U LC-40Q3020U LC-40Q3030U LC-40Q3040U LC-40Q3050U LC-40Q3060U LC-40Q3070U LC-40Q3080U LC-40Q3090U Quick Start Guide Help SHARP improve the environment by reducing paper waste. For detailed instructions and feature descriptions, access the full User Manual online.
-
Page 4: Table Of Contents
Table of Contents Register Your TV! ........................2 Packaged Contents ........................3 Buttons and Ports on the TV ....................4 Attach the TV Stand or Wall Mount Bracket ................5 Connect Devices to your TV .....................7 Buttons on your TV Remote .....................9 Begin Using your Remote.......................10 Power on the TV ........................ -
Page 6: Packaged Contents
PACKAGED CONTENTS Your package in which you purchased your new TV contains the following items: ● TV ● 2 base stands ● 4 screws (M4×20) ● Remote Control ● 2 AAA batteries ● Quick Start Guide (this document) ● Important Safety Information and Warranty Card IMPORTANT: To prevent accidentally discarding items that came with your TV, be sure to check ALL of the foam in the carton box. ·... -
Page 7: Buttons And Ports On The Tv
BUTTONS AND PORTS ON THE TV Back View of the TV TV Side View TV Bottom View... -
Page 8: Attach The Tv Stand Or Wall Mount Bracket
STEP 1. Attach the TV Stand or Wall Mount Bracket Attach the TV Stand Follow the illustrations and instructions below to complete the installation steps: 1. Carefully place your TV facedown on a soft, flat surface to prevent damage to the TV or scratching to the screen. 2. Remove the 2 stands from the accessory bag and then insert the stands into the bottom slots of the TV. 3. - Page 9 Attach the Wall Mount Bracket (not included) • To prevent internal damage to the TV and ensure it is mounted securely, be sure to use fixing screws (not Before you begin the third-party manufacturer instructions, be provided) that are 8 - 10 mm in length when measured from sure to do the following things: the attaching surface of the mounting hook. 1.Place the TV face down on a clean, safe and cushioned surface. 8 - 10 mm 2.Remove the TV stand if you already attached it.
-
Page 10: Connect Devices To Your Tv
STEP 2. Connect devices to your TV Check to ensure that you have selected the right cables for the ports and that they are connected securely. Loose connections can affect the quality of the picture image and color. TV label Port Cable External Equipment Brief Description VHF/UHF Antenna Connect an outdoor VHF/UHF antenna. - Page 11 TV label Port Cable External Equipment Brief Description Connect an optical cable from an external DIGITAL AUDIO OUT digital audio system. Speaker Connect headphones to hear audio from the / AUDIO OUT White Connect an audio adapter (not provided) from an external analog audio system.
-
Page 12: Buttons On Your Tv Remote
Buttons on your TV remote Infrared transmitter Change TV input source The button for the Quick setup menu Power on / off Enter Channels / input numbers Dash button / Select a digital sub-channel Display the channel list Mute and restore sound Go to the previous channel Volume (up/down) Channel (up/down) Enter the Live TV... -
Page 13: Begin Using Your Remote
STEP 4. Begin using your remote • Do not continue using the remote if it gets warm or hot. Call our Support Center immediately on the support 1. Press the battery case cover, when the cover is unlocked, pull it website. backward to open the battery compartment of the remote control. Remote Control Range Information ● The remote control can work at a distance of up to 26 feet in front of the TV set. ● It can work at a 30 degree horizontal or vertical angle. Press and pull it Insert the batteries Press the cover... -
Page 14: Power On The Tv
STEP 5. Power on the TV Comcast..0178, 10178, 10463, 11463, 10748, 11314, 11660, 10171, 11204, 11326, 11517, 11641, 11780, 11785, 11892, 11963, 12002 Plug the power cord into a wall outlet. Cox Communications..0178, 10178, 1326, 1463 Dish Network..505, 627, 538, 720, 659 If the code associated with your Cable or Satellite provider is not listed, does not work or you cannot locate the instructions to program your remote, call your local Cable or Satellite provider's customer service center. -
Page 15: Complete The Setup Wizard
STEP 6. Complete the first-time setup menu Screen Task Live TV Source Select how you receive your TV channels. After the splash screen that shows the logo appears, begin the first- If you have a Satellite/Cable box, choose Yes, then time setup menu. choose from one of the following sources below and then move to the next screen. •... -
Page 16: Product Speci Ications
PRODUCT SPECIFICATIONS LC-40Q3000U/LC-40Q3020U/LC-40Q3030U/LC-40Q3040U/LC-40Q3050U Model Name LC-40Q3060U/LC-40Q3070U/LC-40Q3080U/LC-40Q3090U Dimension Without Stand 35.6 × 20.6 × 3.4 inches (W × H × D) (903 × 523 × 86 mm) With Stand 35.6 × 22.2 × 8.2 inches (903 × 563 × 208 mm) -
Page 17: Quick Problem-Solving Tips
QUICK PROBLEM-SOLVING TIPS When you experience an issue with your TV, turn it off and on again. If this does not resolve the problem, then refer to the tips below. If the problem is still not resolved, then contact us at one of the phone numbers on Page 2. ISSUES POSSIBLE SOLUTIONS • Check if the power cord is plugged into a powered AC outlet. No sound or picture • Press the Power button on the remote control to activate the unit from 'Standby' mode. •... - Page 18 The plastic cabinet makes a • The 'click' sound can occur when the temperature of the television changes. This change causes the television "clicking" type of sound cabinet to expand or contract, which makes the sound. This is normal and the TV is OK. • Confirm that TV still has power and is operational. The remote control does not work • Change the batteries in the remote control. • Check if the batteries are correctly installed. Need more help? Additional help is available online at support links on Page 2. You will find answers to frequently asked questions, downloadable firmware and more.
-
Page 19: Certification And Compliance
©2018. All rights reserved. SHARP and the SHARP logo are trademarks may cause harmful interference to radio communications. of SHARP. Other brand and product names are trademarks of their However, there is no guarantee that interference will not respective owners.
