Summary of Contents for Manostar EMD8A066
- Page 1 READ THE INSTRUCTION MANUAL BEFORE USING I N S T R U C T I O N M A N U A L MANOSTAR DIGITAL SENSOR E M D 8 A 0 6 6 N o . T R - E M D 8 A 0 6 6 - E 0 0 1-2-3,Nishi-shiriike-cho,Nagata-ku,Kobe,Hyogo 653-0031 JAPAN TEL.
-
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE INTRODUCTION ........................1 Ⅰ． PRECAUTIONS ......................2 Ⅱ． SPECIFICATIONS 1．Outline drawing ....................3 2．Function 2-1 Display function ................... 4 2-2 Digital communication function (MODBUS) ........5 2-3 Max. and min. value memory function ..........5 2-4 Function of low power consumption ............. 5 2-5 Function of test mode ................ -
Page 3: Introduction
INTRODUCTION Thank you very much for purchasing of “MANOSTAR DIGITAL SENSOR EMD8A”. Features ・Compact size This instrument is a compact digital micro differential pressure gage composed of the diaphragm type detection part and display part incorporated in 24 × 48 size. -
Page 4: Ⅰ． Precautions
Ⅰ． PRECAUTIONS △ Warning ！ ・Do not use the instrument where flammable gas is present. The instrument is not explosion-proof. Do not use instruments in the circumstance where flammable gas is present. It may cause explosion. ・Do not use the instrument at the place where corrosive gas is present. he instrument is not corrosion resistance construction. -
Page 5: Ⅱ． Specifications
Ⅱ． SPECIFICATIONS 1．Outline drawing Fig.2-(1) EMD8A066 outline drawing （ ）... -
Page 6: 2．Function
2．Function The pressure sensor of this product can measure differential pressures. If the pressure on the H side is higher than that of the L side, the pressure display shows a positive value. This sensor performs A/D conversion of the signal from the pressure sensor, then performs zero compensation and movement average processing, and finally displays the value and performs the digital communication output. -
Page 7: Digital Communication Function (Modbus)
2-2 Digital communication function (MODBUS) 1）Digital communication (input/output) By means of RS-485 (MODBUS/RTU) communication, it is possible to acquire pressure measurement values, execute zero adjustment, and change the various settings. For the items and effective value ranges, refer to P.18 “4-5 MODBUS address map“. 2）Output filter The number of the moving average filter for digital communication output is set in the output filter setting mode. -
Page 8: Function Of Set Value Protecting
・Do not let rating of each terminal go beyond the specifications. ！ ・When wiring, be sure to separate the wiring from the wiring of power supply. Caution Fig.3-(1) External connection diagram EMD8A066 type CN1-1 Power supply +（12 to 24 VDC） CN1-2 Power supply -（0 V）... - Page 9 Fig.3-(2) Example of connection EMD8A066 type Accessory ・RITS plug connector 6P (produced by TE Connectivity) Applied cable Product code Color of cover Nominal O.D of the wire cover cross-sectional areas 1473562-6 Yellow 0.1 0.5mm 1.0 1.15mm ・For crimping wire to connector, a RITS plug connector must be used.
-
Page 10: 4．Piping
4．Piping The instrument, a differential pressure gage, is provided with Fig.3-(4) Layout of tube tap taps at the rear side : one for high pressure (HIGH) and the other for low pressure (LOW). Depending on the application and use, connect piping as follows. 4-1 Measured pressure and connection of piping Please connect the piping shown in the table below according High pressure... -
Page 11: Piping Material
4-2 Piping material Fig.3-(6) For tubing material used for taps of this unit, be sure to use tubing material of I.D 4. Vinyl or rubber tubes are suitable. As shown in Fig.3-(6), when inserting the piping into the tap, be sure to push it in until the piping hit the bottom of tap. -
Page 12: Ⅳ． Operation
Ⅳ． OPERATION 1．Before trial running Before supplying power to this unit for the first time after installation, take care of the following matters. 1）Make sure again of the followings and see if they are correct: location of installation, environment and how the instrument is installed, wiring and piping etc. - Page 13 to operate Fig.4-(2) Change-over of mode (Please refer to P.10 “3．How “ for a basic operation in each mode.) Setting value Max. and min. value display Zero adjustment protecting Setting mode Sets the address in MODBUS communication. Every second 01 to FE(hexadecimal) Memory reset Setting / release Selects the communication speed...
- Page 14 Mode table Factory default setting Mode Mode type Mode name Setting range display Display Set value Unit Normal ― ― Pa / kPa ― Pressure Upper limit over range ― ― ― ― display Lower limit over range ― ― ―...
-
Page 15: Basic Operation In Each Mode
3-2 Basic operation in each mode Please refer to P.11 “Fig.4-(2) Change-over of mode“ for the order of shifting each mode etc. As for the following items, it is executable from the pressure display mode according to a quick operation. All basic operations of other each program mode are united as shown in Fig.4- (3). -
Page 16: Operation Of Test Mode
4）Clearing of the Max. and Min. value It becomes the following with 《Enter》 key in the following mode. Max. value display mode : The max.value is reset. Min. value display mode : The min.value is reset. 5）Set value clear mode : A set each value is returned to the state of the factory shipment. When ”YES”... -
Page 17: 4．Modbus Communication
4．MODBUS communication 4-1 Communication specifications Communication method EIA-485（RS-485） Protocol MODBUS/RTU Communication speed 9.6kbps ,19.2kbps Data length 8 bits (fixed) Parity None (fixed) Stop bit 1 bit (fixed) Address setting range 1 to 254 (01 to FE) 4-2 Communication setting Set the slave address and communication speed in accordance with P.11 “Fig.4-(2) Change-over of mode“. *The factory default settings are “slave address: 01”... - Page 18 “ ” Query 01 04 00 00 00 01 31 CA Slave Function Data Start address code Start address Number of registers △ ！ Items cannot be continuously read. Set “00 01” to “Number of registers.” Caution Response *wh “ ”...
- Page 19 0x 0 : E “L ” Query 01 10 00 00 00 01 02 00 01 67 90 Data Slave Function Start Number of Number address code Start address Changed data registers of bytes *When “FF” is set to the slave address, broadcast communication is enabled. ・Items cannot be continuously written.
-
Page 20: Modbus Address Map
4-5 MODBUS address map The details of addresses are as shown in the table below. MODBUS address map Read Function Data Data Initial Address Item Effective data range Reference code type size value Write Same as pressure range indication Signed 2 bytes Pressure value : −... -
Page 21: Status History List
4-6 Status history list The presence/absence of status abnormality is indicated by the lower 6 bits. Upper Lower Reserved Item Description 0: normal 1: occurrence of overflow Overflow “ ” 0: normal 1: occurrence of underflow Underflow “ ” 0: normal 1: occurrence of communication error MODBUS error When an error related to MODBUS communication has “... -
Page 22: Ⅴ． Information On Software
Ⅴ． INFORMATION ON SOFTWARE In part of this sensor, the following OSS (open-source software) is used. The product use FreeRTOS. More detail read below. * FreeRTOS Kernel V10.0.1 * Copyright (C) 2017 Amazon.com, Inc. or its affiliates. All Rights Reserved. * Permission is hereby granted, free of charge, to any person obtaining a copy of * this software and associated documentation files (the "Software"), to deal in * the Software without restriction, including without limitation the rights to... -
Page 23: Ⅵ． Product Warranty
Ⅵ． PRODUCT WARRANTY Warranty Period The warranty period shall be for one year from the date that the product has been delivered to the location specified by the purchaser. Warranty Scope In the event of any failure or defect in the product or non-conformity of specifications due to the reasons solely attributable to Yamamoto Electric Works, Yamamoto Electric Works shall remedy such malfunctioning or defective product at its own cost in one of the following ways to be selected by Yamamoto Electric Works: ⅰ) repair such product, ⅱ) replace such product.
