ASSEMBLY INSTRUCTIONS
Flyby Echo screen
with L-brackets
COMPONENTS
A
Echo Plate x 1
B
L Bracket x2
C
Clamps cover x2
D
Screws x4
E
Wood screws x 4
Experienced assembly is required. User will need to drill wood screws into underside of desk. No pre-drilled holes are provided for this system.
2 Persons required for installation *
www.jasonl.com.au
Need help!
Call us on
1300 527 665
C
Power Drill tool is required.
B
A
D
Page 2 of 4
