Summary of Contents for ASUSTOR AS5004U
- Page 1 Quick Installation Guide Applicable Model AS5004U Ver.4.2.0 (2023-6-7) Ver.2.3.0903 (2015-3-2)
-
Page 2: Table Of Contents
Table of Contents NOTICES ..................................3 SAFETY PRECAUTIONS ..............................4 1. PACKAGE CONTENTS ..............................5 2. OPTIONAL ACCESSORIES ............................6 3. HARDWARE INSTALLATION GUIDE ..........................7 ........................... 7 OOLS EEDED FOR NSTALLATION ................................7 NSTALLATION ................................9 ECURING THE OWER ................................ -
Page 3: Notices
Notices Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules. -
Page 4: Safety Precautions
Safety Precautions The following safety precautions will increase the life of the NAS. Follow all precautions and instructions. Electrical Safety Unplug this product from the power source before cleaning. Use only the bundled power adapter. Using other power adapters may damage your device. Ensure that you plug the power adapter to the correct power input rating. -
Page 5: Package Contents
1. Package Contents Applicable Models: AS5004U NAS Device AS5004U Power Cord Adapter USB 3.2 Gen2 Cable Screws for use with 2.5” HDD Quick Installation Guide... -
Page 6: Optional Accessories
2. Optional Accessories The items below may be purchased from the ASUSTOR Accessories Store http://shop.asustor.com. -
Page 7: Hardware Installation Guide
Phillips head screwdriver ⚫ At least one 2.5 or 3.5 inch SATA hard disk. (For a list of compatible hard disks, please see http://www.asustor.com/service/hd?id=hd) Hard Disk Installation 1. Remove the front panel as shown in the image below. 2. Using the latch, gently pull the disk tray out of the disk bay. - Page 8 4. Slide the disk tray onto the rails of the disk bay. Using the latch, gently push the disk tray all the way into the disk bay. Secure the disk tray in place by pushing down on the latch. The latch should close easily and snap in with an audible ‘click’.
-
Page 9: Securing The Power Cord
Attach the bracket to the power cord as shown in the graphic below. Connecting Your Device 1. Plug the USB 3.2 Gen2 cable into AS5004U, and lock the screw in the direction of the arrow. 2. Connect the power cable to the device. - Page 10 3. Connect the other end of the USB 3.2 Gen2 cable to a USB 3.2 port on your NAS, which should not be powered on yet. When the NAS is powered on, the AS5004U will also be powered on. When the NAS is powered off or in sleep mode, the AS5004U will also enter into sleep mode.
-
Page 11: Appendix
4. Appendix LED Indicators AS5004U 1. Power LED Indicator 2. Status LED Indicator 3. Hard Disk LED Indicator Color Description State Indicator Blue Steadily lit Power on Power Orange Steadily lit Sleep mode Unlit Power off Green Steadily lit RAID mode... -
Page 12: Front Panel
Front Panel AS5004U 1. Power Button 2. HDD 1 3. HDD 2 4. HDD 3 5. HDD 4 Rear Panel AS5004U 1. USB 3.2 Gen2 Type-C Port 2. DC Input 3. K-lock 4. System Fan... -
Page 13: Powering Off Your Device
NAS models that are able to support 2 simultaneous AS5004U expansion units: AS11 / AS67 / FS67 / AS65 Series Troubleshooting If you encounter any problems during the installation process, please contact your local ASUSTOR dealer or ASUSTOR Technical Support. You can also access the ASUSTOR knowledge base on the technical support website.
