www.ime.de
Residential Gas Detector
Featuring LoRaWAN
®
GS101
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Milesight GS101 and is the answer not in the manual?

Questions and answers

Summary of Contents for IME Milesight GS101

  • Page 1 Residential Gas Detector Featuring LoRaWAN ® GS101 User Guide...
  • Page 2 DANGER If you hear the gas leak alarm or smell the gas even without an alarm, please keep calm and carry out the following actions, not necessarily in the order given: Extinguish all naked flames, including all smoking material;...
  • Page 3 Declaration of Conformity GS101 is in conformity with the essential requirements and other relevant provisions of the CE, FCC, and RoHS. Copyright © 2011-2022 Milesight. All rights reserved. All information in this guide is protected by copyright law. Whereby, no organization or individual shall copy or reproduce the whole or part of this user guide by any means without written authorization from Xiamen Milesight IoT Co., Ltd.

  • Page 4: Table Of Contents

    Contents 1. Product Introduction ......................... 5 1.1 Overview ...........................5 1.2 Features ........................... 5 2. Hardware Introduction ........................5 2.1 Packing List ..........................5 2.2 Hardware Overview ......................... 6 2.3 Wiring ............................6 2.4 LED and Button Patterns ......................7 2.5 Dimensions ..........................8 3.

  • Page 5: Product Introduction

    1. Product Introduction 1.1 Overview GS101 is a LoRaWAN ® residential gas detector to detect the natural gas leak and send alarms. When the concentration caused by gas leak reaches the preset threshold, the detector will trigger LED light alarm and buzzer sound alarm, it also supports controlling outputs to close the gas valve and open the vent fans to prevent potential accidents.

  • Page 6: Hardware Overview

    If any of the above items is missing or damaged, please contact your sales Representative. 2.2 Hardware Overview Note: The historical record interface is only for professional use. Users can use Milesight ToolBox App to read the historical records.

  • Page 7: Led And Button Patterns

    Wiring Step Insert a flathead screwdriver into the square holes and insert the wire into the circle holes, then release the screwdriver and ensure the cable is locked. Note: power off all devices when wiring, do not touch the bare wires after the device is powered 2.4 LED and Button Patterns...

  • Page 8: Dimensions

    Mute: Press the button (≤3s) Steady Alarm Light On, While Stop Beeping for 1 when device is in alarm status Other Lights Off Minute Reboot: Hold on the button for All Lights Blink Slowly 3s to 10s Reset to Factory Default: Hold...

  • Page 9: Lorawan Settings

    Note: 1) After the warm-up, if the device is powered off for a short time, it will not warm up again. 2) If the device detects the threshold reaches during the warm-up, it will stop warming up and send alarms.
  • Page 10 Parameters Description Device EUI Unique ID of the device which can also be found on the label. App EUI Default App EUI is 24E124C0002A0001. Application Port The port is used for sending and receiving data, the default port is 85.
  • Page 11 LinkCheckReq MAC packets to the network server every 30 mins to validate connectivity; If there is no response, the device will re-join the network. Reporting interval > 30 mins: the device will send a specific number of LinkCheckReq MAC packets to the network server every reporting interval to validate connectivity;...

  • Page 12: Basic Settings

    1-40, 60: Enabling Channel 1 to Channel 40 and Channel 60 All: Enabling all channels Null: Indicates that all channels are disabled Note: For -868M model, the default frequency is EU868; For -915M model, the default frequency is AU915.

  • Page 13: Historial Record Storage

    3.4 Historial Record Storage GS101 supports storing more than 800 historical records locally in 7 types and these records will not be cleared even reset to factory default. When storing records reach the max capacity, the device will cover the oldest records according to record types. Record type, description and...

  • Page 14: Maintenance

    3.5 Maintenance 3.5.1 Upgrade 1. Download firmware from www.milesight-iot.com to your smartphone. 2. Open ToolBox App and click “Browse” to import firmware and upgrade the device. Note: 1) Operation on ToolBox is not supported during the upgrade. 2) Only Android version ToolBox supports the upgrade feature.

  • Page 15: Reboot And Reset

    Note: Slide the template item to the left to edit or delete it. Click the template to edit the configurations. 3.5.3 Reboot and Reset Please select one of the following methods to reset or reboot the device: Via Hardware: Hold on the button on the front panel for 3 to 10s to reboot, and more than 10s to reset.

  • Page 16: Installation

    4. Installation Recommended Installation Locations The residential gas detector is designed to be installed in every room where gas leak may occur, such as the kitchen. The installation location should meet these requirements: within the range of the LoRaWAN gateway;...
  • Page 17 The place where strong vibration may happen or easy to be subject to physical shock;  On the top of cook appliances or sink or way of smoke;  Enclose space or the place where curtains, furniture or other objects block the flow of air to ...

  • Page 18: Maintenance

    5. Maintenance The working life of the detector is 5 years from power on, replace the device if you observe  Invalid indicator blinks. The newly decorated or re-decorated room should be ventilated for some time before  installing the detector.

  • Page 19: Sensor Data

    Example: ff0bff ff0101 ff166747c21194300001 ff090100 ff0a0101 Channel Type Value 0b (Power On) ff: device is powered on 01 (Protocol version) 01 (V1) 16 (Device SN) 6747c21194300001 09 (Hardware Version) 0100: V1.0 0a (Software Version) 0101: V1.1 6.2 Sensor Data GS101 device will report the below packages: 1.

  • Page 20: Downlink Commands

    8e (Methane Alarm) 00: normal 01: valve on 00: relay output off 2. Device is powered off ff3f00 Channel Type Value 00: device is powered off 3f (Alarm Report) 6.3 Downlink Commands GS101 supports downlink commands to configure the device. The application port is 85 by default.
  • Page 21 03 (Set Reporting Interval) b0 04 => 04 b0 = 1200s = 20 minutes 3. Set time zone to GMT-4 for time display on ToolBox App. ff17d8ff Channel Type Value 17 (Set Time Zone) d8 ff => ffd8 = -40 = -4 * 10 4.
