Summary of Contents for marinco 10108
- Page 1 Dual Trumpet Mini Air Horn 10108 & 10121 Installation Instructions...
- Page 2 * See Wiring Chart For Wire Size Tools Required for Installation: • Phillips-Head Screwdriver • 7/16” Drill Bit • Electric Drill • Soldering Gun & Solder (Optional) • Crimping/Cutting Pliers If any hardware components are missing, please contact Marinco Customer Service at 1-800-307-6702. www.marinco.com 800.307.6702...
- Page 3 Connect the other end of each 4” air hose to the three-prong tee fitting. If you have difficulty getting the air hose onto the tee fitting, heat the air hose by placing it into a pan of hot (not boiling) water until it is soft, then slide it over the tee fitting. www.marinco.com 800.307.6702...
- Page 4 Dual Trumpet Mini Air Horn 10108 & 10121 www.marinco.com 800.307.6702...
- Page 5 Do not over lubricate. Let the oil set for a few minutes and then activate the compressor momentarily to distribute the oil. Failure to activate the compressor before re-connecting the air hose may result in oil being blown onto the horn diaphragm and contaminating it. 6) Re-connect the air hose. www.marinco.com 800.307.6702...
- Page 6 3) Connect the wires as shown in the wiring diagram. It is recommended that the quick-connect tabs be soldered to the stranded wire for the best and most reliable connection to the compressor. Suggestion: Use the Marinco Direct Connect Multi Connection Battery Terminals (Part #12VTR) to connect the wiring to the battery.
- Page 7 6) It is very important that when lubricating the compressor, the oil is allowed to settle and the compressor is activated BEFORE re-attaching the air hose. Failure to do this may result in oil being blown onto the diaphragm and contaminating it. www.marinco.com 800.307.6702...
- Page 8 Warranty information: www.marinco.com/limited-warranty www.marinco.com 800.307.6702 FAX 800.799.3779 12/2012 20142...
