INSTALLATION AND OPERATION MANUAL
2400
(OB02411 model)
250, rue de Copenhague, St-Augustin-de-Desmaures (Quebec) Canada G3A 2H3
After-sale service: 418-908-8002
This manual is available for free download on the manufacturer's web site. It is a copyrighted
document. Re-sale is strictly prohibited. The manufacturer may update this manual from time to
time and cannot be responsible for problems, injuries, or damages arising out of the use of
information contained in any manual obtained from unauthorized sources.
Printed in Canada
www.osburn-mfg.com
Stove Builder International Inc.
READ AND KEEP THIS MANUAL FOR REFERENCE
US ENVIRONMENTAL PROTECTION
AGENCY PHASE II CERTIFIED WOOD
Safety tested according to ULC S627
and UL 1482 Standards
by an accredited laboratory
E-mail: tech@sbi-international.com
STOVE
45110A
05-08-2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OSBURN 2400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Beyond OSBURN 2400

Summary of Contents for Beyond OSBURN 2400

  • Page 1 INSTALLATION AND OPERATION MANUAL 2400 (OB02411 model) US ENVIRONMENTAL PROTECTION AGENCY PHASE II CERTIFIED WOOD STOVE Safety tested according to ULC S627 and UL 1482 Standards by an accredited laboratory www.osburn-mfg.com Stove Builder International Inc. 250, rue de Copenhague, St-Augustin-de-Desmaures (Quebec) Canada G3A 2H3 After-sale service: 418-908-8002 E-mail: tech@sbi-international.com This manual is available for free download on the manufacturer’s web site.
  • Page 2 Osburn 2400 Installation and Operation Manual THANK YOU FOR CHOOSING THIS OSBURN WOOD STOVE As one of North America’s largest and most respected wood stove and fireplace manufacturers, Stove Builder International takes pride in the quality and performance of all its products. We want to help you get maximum satisfaction as you use this product.

  • Page 3: Table Of Contents

    Osburn 2400 Installation and Operation Manual Table of content PART A - OPERATION AND MAINTENANCE ....... 6 1 Safety Information ..............6 Summary of Operation and Maintenance Cautions and Warnings ........6 2 General Information on 2400 Osburn (OB02411) ....7 Appliance performance ......................
  • Page 4 Osburn 2400 Installation and Operation Manual 5 Maintaining Your Wood Heating System ....... 22 Stove Maintenance ......................22 5.1.1 Plated Finish Maintenance....................22 5.1.2 Cleaning Door Glass ......................22 5.1.3 Door adjustment ......................23 5.1.4 Replacing the Door Gasket ....................23 5.1.5...
  • Page 5 Osburn 2400 Installation and Operation Manual 8.5.2 Air Supply in Conventional Houses .................. 40 Installing the Chimney Connector ..................40 8.6.1 Installation of Single Wall Chimney Connector ............... 41 Appendix 1: Installing the Optional Door Overlay ..... 43 Appendix 2: Installing the Optional Fresh Air intake Kit (OA10500/AC02090) ..........

  • Page 6: Part A - Operation And Maintenance

    Osburn 2400 Installation and Operation Manual PART A - OPERATION AND MAINTENANCE Please see Part B for installation instructions. 1 SAFETY INFORMATION 1.1 SUMMARY OF OPERATION AND MAINTENANCE CAUTIONS AND WARNINGS HOT WHILE IN OPERATION, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. CONTACT •...

  • Page 7: General Information On 2400 Osburn (Ob02411)

    Osburn 2400 Installation and Operation Manual GENERAL INFORMATION ON 2400 OSBURN (OB02411) 2.1 APPLIANCE PERFORMANCE Fuel type Dry cordwood Recommended heating area 1,000 to 2,700 ft2 (93 to 251 m Firebox volume 3.4 ft3 (0.096 m Maximum burn time 10 h...

  • Page 8: General Features

    Osburn 2400 Installation and Operation Manual 2.2 GENERAL FEATURES Maximum log length 21 in (533 mm) east-west* Flue outlet diameter 6 in (152 mm) Recommended connector pipe diameter 6 in (152 mm) Type of chimney CAN/ULC S629, UL 103 HT (2100 °F)
  • Page 9 Osburn 2400 Installation and Operation Manual _______________________________________________________________________________ 9...

  • Page 10: Zone Heating And How To Make It Work For You

    2.3 ZONE HEATING AND HOW TO MAKE IT WORK FOR YOU Your new Osburn 2400 wood stove is a space heater, which means it is intended to heat the area it is installed in, as well as spaces that connect to that area, although to a lower temperature. This is called zone heating and it is an increasingly popular way to heat homes or spaces within homes.

  • Page 11: The Benefits Of Low Emissions And High Efficiency

    2.4 THE BENEFITS OF LOW EMISSIONS AND HIGH EFFICIENCY The low smoke emissions produced by the special features inside the Osburn 2400 firebox mean that your household will release up to 90 percent less smoke into the outside environment than if you used an older conventional stove.

  • Page 12: Fuel

    Osburn 2400 Installation and Operation Manual 3 FUEL 3.1 MATERIALS THAT SHOULD NOT BE BURNED GARBAGE OF ANY KIND, • COAL OR CHARCOAL, • • TREATED, PAINTED OR COATED WOOD, PLYWOOD OR PARTICLE BOARD, • • FINE PAPER, COLORED PAPER OR CARDBOARD, •...

  • Page 13: Log Length

    Osburn 2400 Installation and Operation Manual 3.2.3 LOG LENGTH Logs should be cut about 1” (25 mm) shorter than the firebox so they fit in easily. Pieces that are even slightly too long make loading the stove very difficult. The most common standard length of firewood is 16”...

  • Page 14: How To Dry Firewood

    Osburn 2400 Installation and Operation Manual 3.2.5 HOW TO DRY FIREWOOD Firewood that is not dry enough to burn is the cause of most complaints about wood inserts. Continually burning green or unseasoned wood produces more creosote and involves lack of heat and dirty glass door.

  • Page 15: Judging Firewood Moisture Content

    Osburn 2400 Installation and Operation Manual 3.2.6 JUDGING FIREWOOD MOISTURE CONTENT You can find out if some firewood is dry enough to burn by using these guidelines: • cracks form at the ends of logs as they dry as it dries in the sun, the wood turns from white or cream coloured to grey or yellow, •...

  • Page 16: Operating Your Stove

    Osburn 2400 Installation and Operation Manual 4 OPERATING YOUR STOVE 4.1 YOUR FIRST FIRES Two things will happen as you burn your first few fires; the paint cures and the internal components of the stove are conditioned. As the paint cures, some of the chemicals vaporize. The vapors are not poisonous, but they do smell bad.

  • Page 17: The Top Down Fire

    Osburn 2400 Installation and Operation Manual 4.2.2 THE TOP DOWN FIRE The top down fire starting method solves two problems with the conventional method: first, it does not collapse and smother itself as it burns; and second, it is not necessary to build up the fire gradually because the firebox is loaded before the fire is lit.

  • Page 18: Ash Removal

    Osburn 2400 Installation and Operation Manual Wood burns best in cycles. A cycle starts when a new load of wood is ignited by hot coals and ends when that load has been consumed down to a bed of charcoal about the same size as it was when the wood was loaded.

  • Page 19: Raking Charcoal

    Osburn 2400 Installation and Operation Manual 4.3.3 RAKING CHARCOAL Rekindle the fire when you notice that the room temperature has fallen. You will find most of the remaining charcoal at the back of the firebox, furthest from the door. Rake these coals towards the door before loading.

  • Page 20: Building Different Fires For Different Needs

    Osburn 2400 Installation and Operation Manual If the flames get small and almost disappear when you turn down the air, you have turned down the air too early, or your firewood is wetter than it should be. With good fuel and correct air control use, the flames should slow down, but should stay large and steady, even as the air supply is reduced.
  • Page 21 Osburn 2400 Installation and Operation Manual 4.3.6.4 Maximum Burn Cycle Times The burn cycle time is the period between loading wood on a coal bed and the consumption of that wood back to a coal bed of the same size. The flaming phase of the fire lasts for roughly the first half of the burn cycle and the second half is the coal bed phase during which there is little or no flame.

  • Page 22: Maintaining Your Wood Heating System

    Osburn 2400 Installation and Operation Manual 5 MAINTAINING YOUR WOOD HEATING SYSTEM 5.1 STOVE MAINTENANCE Your new stove will give many years of reliable service if you use and maintain it correctly. Some of the internal components of the firebox, such as firebricks, baffles and air tubes, will wear over time under intense heat.

  • Page 23: Door Adjustment

    Osburn 2400 Installation and Operation Manual 5.1.3 DOOR ADJUSTMENT In order for your stove to burn at its best efficiency, the door must provide a perfect seal with the firebox. Therefore, the gasket should be inspected periodically making sure to obtain an air tight fit.

  • Page 24: Replacing The Glass Gasket And/Or The Glass

    Osburn 2400 Installation and Operation Manual 5.1.5 REPLACING THE GLASS GASKET AND/OR THE GLASS It is a good idea to replace the glass gasket when the door gasket is replaced. The gasket is flat, adhesive-backed, woven fibreglass. Remove the glass retaining screws (A) and metal frame (B) that holds the glass (D) to the door frame (E).

  • Page 25: Cleaning And Painting The Stove

    Osburn 2400 Installation and Operation Manual 5.1.6 CLEANING AND PAINTING THE STOVE Do not attempt to clean or paint the stove when the unit is hot. Painted surfaces can be wiped down with a damp cloth. Plated surfaces may be scratched by abrasive cleaners. To maintain the finish at its original brilliance, use only a damp soft cloth to clean plated surfaces.

  • Page 26: Cleaning The Chimney

    Osburn 2400 Installation and Operation Manual 5.2.3 CLEANING THE CHIMNEY Chimney cleaning can be a difficult and dangerous job. don’t have experience cleaning chimneys, you might want to hire a professional chimney sweep to clean and inspect the system for the first time.

  • Page 27: Part B - Installation

    Osburn 2400 Installation and Operation Manual PART B - INSTALLATION 6 SAFETY INFORMATION 6.1 SUMMARY OF INSTALLATION CAUTIONS AND WARNINGS • THE INFORMATION GIVEN ON THE CERTIFICATION LABEL AFFIXED TO THE APPLIANCE ALWAYS OVERRIDES THE INFORMATION PUBLISHED, IN ANY OTHER MEDIA (OWNER’S MANUAL, CATALOGUES, FLYERS, MAGAZINES AND/OR WEB SITES).

  • Page 28: Regulations Covering Stove Installation

    When installed and operated as described in these instructions, the Osburn 2400 wood stove is suitable for use as a freestanding heater in residential installations. The Osburn 2400 wood stove is not intended for installation in a sleeping room of a mobile home.
  • Page 29 Osburn 2400 Installation and Operation Manual If the above clearances are met, then the distances measured from the flue outlet will be: DISTANCES* FROM PIPE CONNECTOR DISTANCES* FROM PIPE CONNECTOR TO THE COMBUSTIBLE MATERIALS TO THE COMBUSTIBLE MATERIALS CANADA CANADA 21½"...
  • Page 30 Osburn 2400 Installation and Operation Manual Clearances to combustible materials and floor protection 30 ______________________________________________________________________________...

  • Page 31: Floor Protector

    Osburn 2400 Installation and Operation Manual 7.3 FLOOR PROTECTOR Your stove has been conceived to prevent the floor from overheating. However, it must be placed on a noncombustible surface to protect the floor from hot embers that could fall from the stove while loading or cleaning.

  • Page 32: Reducing Wall And Ceiling Clearances Safely

    F Mounting hardware must not be located closer than 200 mm (8 in.) from the vertical centre line of the appliance. G Edge clearance for ceiling shields to side and back walls: 75 mm (3 in.). H Shield extension beyond each side of appliance: 450 mm (18 in.). 32 ______________________________________________________________________________...
  • Page 33 Osburn 2400 Installation and Operation Manual Clearances for shield construction ______________________________________________________________________________ 33...

  • Page 34: Table Of Clearance Reduction Percentages

    Osburn 2400 Installation and Operation Manual 7.4.2 TABLE OF CLEARANCE REDUCTION PERCENTAGES Clearances may be reduced by these percentages Sides Top % Type of shield and rear % (ceiling) Can/USA Can/USA min. min. Sheet metal, a minimum of 24 gauge (0.61 mm) in thickness , spaced out at...

  • Page 35: The Venting System

    Osburn 2400 Installation and Operation Manual 8 THE VENTING SYSTEM 8.1 GENERAL The venting system, made up of the chimney and the connecting pipe between the stove and the chimney, acts as the engine that drives your wood heating system. Even the best stove will not function safely and efficiently as intended if it is not connected to a suitable chimney.

  • Page 36: Factory-Built Metal Chimneys In Mobile Homes

    Osburn 2400 Installation and Operation Manual 8.2.2 FACTORY-BUILT METAL CHIMNEYS IN MOBILE HOMES For use in a mobile home, this stove is to be connected to a 6” in diameter double wall factory built chimney conforming to CAN/ULC-S629, Standards 650°C Factory-built chimney.

  • Page 37: Masonry Chimneys

    Osburn 2400 Installation and Operation Manual 8.2.3 MASONRY CHIMNEYS The stove may also be connected to a masonry chimney, provided the chimney complies with the construction rules found in the building code enforced locally. The chimney must have either a clay liner or a suitably listed stainless steel liner.

  • Page 38: The Relationship Between The Chimney And The House

    Osburn 2400 Installation and Operation Manual 8.4 THE RELATIONSHIP BETWEEN THE CHIMNEY AND THE HOUSE Because the venting system is the engine that drives the wood heating system, it must have the right characteristics. The signs of bad system design are cold backdrafting when there is no fire in the stove, slow kindling of new fires, and smoke roll-out when the door is opened for loading.

  • Page 39: Why The Chimney Should Penetrate The Highest Heated Space

    Osburn 2400 Installation and Operation Manual 8.4.2 WHY THE CHIMNEY SHOULD PENETRATE THE HIGHEST HEATED SPACE When it is cold outside, the warm air in the house is buoyant so it tends to rise. This tendency of warm air to rise creates a slight pressure difference in the house. Called ‘stack effect’, it produces a slightly negative pressure low in the house (relative to outside) and a slightly positive pressure zone high in the house.

  • Page 40: Combustion Air Supply In Mobile Homes

    Only a wood stove certified and labelled as ‘mobile home approved’ may be installed in a mobile home. This Osburn 2400 stove is ‘mobile home approved’. Wood stoves installed in mobile homes must have a ducted supply of combustion air from outdoors. This air supply should be routed down through the house floor into the vented crawl space under the mobile home.

  • Page 41: Installation Of Single Wall Chimney Connector

    Osburn 2400 Installation and Operation Manual 8.6.1 INSTALLATION OF SINGLE WALL CHIMNEY CONNECTOR The chimney connector assembly has been called ‘the weak link’ in the safety of wood heating systems because failure to install the connector properly (which has been common in the past) can result in house fires.
  • Page 42 Osburn 2400 Installation and Operation Manual The rules below are based on those found in the CSA B365 installation code. Please carefully follow these installation instruction rules, or those enforced where you live. Maximum overall length of straight pipe: 3 m (10 ft.) including elbows.

  • Page 43: Appendix 1: Installing The Optional Door Overlay

    Osburn 2400 Installation and Operation Manual APPENDIX 1: INSTALLING THE OPTIONAL DOOR OVERLAY In order to complete the assembly of your wood stove, you need to install the door overlay. See figure below for installation instructions: Position the overlay (A) on the door frame and secure it from inside the door using the 4 included screws (B).

  • Page 44: Appendix 2: Installing The Optional Fresh Air Intake Kit (Oa10500/Ac02090)

    Osburn 2400 Installation and Operation Manual APPENDIX 2: INSTALLING THE OPTIONAL FRESH AIR INTAKE KIT (OA10500/AC02090) When installed with a fresh air kit, the stove must be anchored to the floor. This mobile home approved stove requires installation of a fresh air intake kit (A) and an insulated fresh air intake pipe (B), sold separately.

  • Page 45: Appendix 3: Installation And Use Of The Optional Blower (Oa10510)

    Osburn 2400 Installation and Operation Manual APPENDIX 3: INSTALLATION AND USE OF THE OPTIONAL BLOWER (OA10510) An optional blower can be installed on the back of the stove to increase the flow of air past heat exchange surfaces and to help circulate warm air in the room. When used regularly, the blower can provide a small increase in efficiency, up to 2 percent.
  • Page 46 Osburn 2400 Installation and Operation Manual The blower has a rheostat, see the illustration on the right to identify the different adjustment positions; either from high (HI) to low (LO) or closed (OFF). When using the optional blower, allow the stove to reach operating temperature (approximately one hour), before turning it on.

  • Page 47: Appendix 4: Installation Of Secondary Air Tubes And Baffle

    Osburn 2400 Installation and Operation Manual APPENDIX 4: INSTALLATION OF SECONDARY AIR TUBES AND BAFFLE To make a replacement, please remove the following parts: PARTS SECONDARY AIR TUBE COTTER PIN BAFFLE SUPORT C-CAST BAFFLE BAFFLE INSULATION BAFFLE INSULATION WEIGHT 1. Remove the top left bricks as shown in picture.
  • Page 48 Osburn 2400 Installation and Operation Manual 2. Starting with the rear tube, lean and insert the right end of the secondary air tube into the rear right channel hole. Then lift and insert the left end of the tube into the corresponding nozzle in the left channel.

  • Page 49: Appendix 5: Exploded Diagram And Parts List

    Osburn 2400 Installation and Operation Manual APPENDIX 5: EXPLODED DIAGRAM AND PARTS LIST ______________________________________________________________________________ 49...
  • Page 50 Osburn 2400 Installation and Operation Manual IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your stove, please provide the model number and the serial number. We reserve the right to change parts due to technology upgrade or availability. Contact an authorized dealer to obtain any of these parts.
  • Page 51 Osburn 2400 Installation and Operation Manual Item Description PL36014 4" X 6 1/2'' X 1 1/4" REFRACTORY BRICK PL36048 4" X 4" X 1 1/4'' REFRACTORY BRICK PL36084 4" X 4 1/2'' X 1 1/4'' REFRACTORY BRICK PL36025 2 1/2" X 8" X 1 1/4" REFRACTORY BRICK AC03030 4'' X 8"...

  • Page 52: Osburn Limited Lifetime Warranty

    Osburn 2400 Installation and Operation Manual OSBURN LIMITED LIFETIME WARRANTY The warranty of the manufacturer extends only to the original retail purchaser and is not transferable. This warranty covers brand new products only, which have not been altered, modified nor repaired since shipment from factory. Proof of purchase (dated bill of sale), model name and serial number must be supplied when making any warranty claim to your OSBURN dealer.
