REGAL GAS DETECTOR

The REGAL Series 3000 Gas Detector (Chlorine or Sulfur

Dioxide) is a very important accessory item that should

be part of ALL Regal Gas Feed System installations.

The REGAL Series 3000 Gas Detector is a safety device

that is as important as a gas mask or self contained

breathing apparatus. It should not be deleted from the

system solely on the basis that current regulations in

a given geographical area do not specifically require

this item.

1. All software including design, appearance, algorithms and

source codes are copyrighted and owned by Chlorinators

Incorporated.

2. The entire contents of this manual MUST be read and understood

prior to installing and operating this equipment.

3. DO NOT discard this instruction manual upon completion of the

installation as this manual contains information essential to the

safe handling, operation and maintenance of this equipment.

4. Additional instruction manuals are available at nominal cost from

Chlorinators Incorporated.

5. Plastic pipe or tubing connector fittings may be broken or

damaged if tightened excessively. HAND TIGHTEN ONLY.

6. For maximum operation, the installation should be indoors so

that the minimum and maximum temperature limitations as listed

in the "TECHNICAL SPECIFICATIONS" section of this manual

are not exceeded.

7. This equipment is suitable for use only with the gases specified.

DO NOT USE THIS EQUIPMENT WITH OTHER GASES. Such

use can result in failures having hazardous consequences.

8. To insure proper and safe operation of this equipment, use only

REGAL parts. The use of non-REGAL parts can result in equip-

ment failures having hazardous consequences and voids the

REGAL warranty.

Series 3000

IMPORTANT NOTES AND WARNINGS

1044 SE Dixie Cutoff Road, Stuart, Florida 34994 USA

Phone: (772) 288-4854 Fax: (772) 287-3238

www.regalchlorinators.com Email: chlorinc@aol.com

A properly installed and calibrated REGAL Series 3000

Gas Detector can save lives and protect equipment and

property from the effects of these gases by providing

warning of gas leaks AS SOON AS THEY OCCUR. Properly

installed, calibrated and maintained, REGAL Series

3000 Gas Detectors can accurately sense and display

the presence of free Chlorine or free Sulfur Dioxide in

the environment at levels below those mandated by

OSHA and throughout the working life of the unit.

9. Maintenance should be performed by qualified personnel familiar

with this type of equipment, such as Chlorinators Incorporated

themselves.

10. It is essential that all external wiring be done exactly as shown

on the diagrams depicted in this manual. Incorrect wiring or

improper grounding of this equipment WILL cause improper

operation and presents a safety hazard.

11. Field wiring MUST conform to national and local electrical

codes.

12. Disconnect power BEFORE removing the cover or servicing

this equipment.

13. ALWAYS make sure that the cover is in place and securely

fastened to prevent the entry of moisture, water or corrosive

gases and also to eliminate the potential for electrical shock.

14. Any equipment powered by AC line voltage presents a potential

shock hazard. Installation and servicing of this equipment

should only be attempted by qualified electronics technicians.

15. Damage to the circuit boards or internal components incurred

by drilling the enclosure for field wiring or connecting power

lines to low voltage signal terminals VOIDS the warranty.

16. Ground MUST be provided as part of the installation.

INSTRUCTION BULLETIN 13000

Table of Contents

Need help?

Do you have a question about the 3000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Regal 3000 Series

Page 1 VOIDS the warranty. 8. To insure proper and safe operation of this equipment, use only REGAL parts. The use of non-REGAL parts can result in equip- 16. Ground MUST be provided as part of the installation.
Page 2 TERM OF WARRANTY NO OTHER WARRANTIES C.I. warrants its REGAL Series 3000 Gas Detector for a period of one (1) year from date of shipment from C.I. Date of shipment Unless otherwise explicitly agreed in writing, and signed by a from the factory shall be determined solely on the basis of the C.I.
Page 3: Table Of Contents
MODEL NUMBER DESIGNATION RELAY OPERATION OPTIONAL BATTERY BACK-UP OPERATION INSTALLATION IMPORTANT: Please mail or fax this registration form to establish your warranty. WIRING REGAL Registration Card START-UP AND OPERATION SPECIFICATIONS CALIBRATING THE DETECTOR (AUTOCAL) 10.0 SERIAL COMMUNICATIONS 11.0 SENSOR CROSS-SENSITIVITY DATA...
Page 4 Interfaced With Chlorine Room Exhaust Fan Fill out and mail or fax the form on the reverse side Drawing No. 7 to establish your warranty. Connecting The REGAL VAC/AL-1 Remote Alarm Horn/Light To The Detector Relays Drawing No. 8 Sensor Replacement Drawing/Procedure Drawing No.
Page 5: General
Power for the analog output loop is accomplished using a DC Power Supply not furnished by Chlorinators The front cover of the REGAL Series 3000 Gas Detector Incorporated. The Power Supply can be 12 VDC minimum includes the following displays: to 30 VDC maximum.
Page 6: Model Number Designation
10.5 and 8.5 Volts while under battery power, the INDICATES “BATTERY” LED “blinks.” If battery voltage degrades to less than 8.5 Volts, the REGAL Gas Detector is shut off C = RS232 Serial Communications output circuit board (#8500-1). and the battery MUST be charged or replaced. The monitor D = RS485 Serial Communications output circuit board (#8500-2).
Page 7: Wiring
5.5.3 Route the battery cable through the cable grip on IMPORTANT: SENSOR LOCATIONS MUST BE CARE- the bottom of the monitor enclosure. FULLY CHOSEN TO ASSURE A GAS LEAK WILL BE DETECTED AS SOON AS IT OCCURS. THE FOLLOWING 5.5.4 In the monitor enclosure, connect the RED battery MUST ALSO BE TAKEN INTO CONSIDERATION.
Page 8: Start-Up And Operation
To change factory settings and to set REGAL Series 3000 Gas Detector by qualified electricians ALARM RELAY “LATCH” TIME(S), you must enter the conforming to all appropriate electrical codes.
Page 9: Specifications
7.4 “rly” = Relay Test. This parameter runs through a 8.0 SPECIFICATIONS sequential test cycle of all alarm relays. Initiating this test takes you to the Operating Mode when complete. Press “ENTER” to run through a test cycle of all 8.1 Power Supply: alarm relays which when complete automatically Input: 100-250 VAC 50/60 Hz.
Page 10: Calibrating The Detector (Autocal)
In most cases, it is unnecessary to calibrate the sensors during this time period unless regulations or personal preferences dictate otherwise. To calibrate a REGAL Series 3000 Gas Detector you MUST have the shipping/calibration plug originally furnished with It is, however, suggested that the sensors be periodically...
Page 11: Serial Communications
SILENCE and ENTER keypad buttons. The monitor locks on that sensor and the numeric display should indicate “CAL” REGAL offers a choice of two interface standards, RS232 for calibrate. or RS485. 9.3.5 Connect the hose from the pressure regulating...
Page 12: Important
FOLLOW INSTRUCTIONS OUTLINED IN PARAGRAPH 10.3 BELOW. Response (server) msg: N (nak) ascii-hex error code 10.2 When CP2 (OPTO-22) is selected, the REGAL ERROR communications protocol. OPTO-22 is a half-duplex, poll and respond protocol. The monitor waits for a command message then responds with a return message.
Page 13 MODBUS. and is not recommended for normal operation. 10.2.2 ERROR CODES If an error is detected by the REGAL device, it will respond with the NAK character (N) followed by one of the error codes in the list below.
Page 14 The MODBUS spec defines other error codes but only the baud rate to 1200 after returning the value for above are used by REGAL monitors. No error msg is verification as :7F440201A8(CRLF). The value, in returned for communication errors, such as checksum or both the command and return messages, is always a time-out.
Page 15 01-04 00-FF CRLF The sensors used in all REGAL Series 3000 Chlorine Gas Detectors may exhibit a response to certain gases in a The MEI type field is always 0E for this function. The sample stream other than chlorine. The table below shows...
Page 16 DRAWING NO. 1 #4100 Display/CPU Circuit Board Chlorine and Sulfur Dioxide 1. S1 This is the connector the #8400 Analog Output NOTES: (mA) Board or the #8500 Serial Output (Digital) A. Only one board (8400 or 8500) can be used at a time. Board plugs into.
Page 17 DRAWING NO. 2 #8300 Power Supply PCB Assembly Chlorine and Sulfur Dioxide INDEX Double Pole, Double Throw DANGER Gas Concentration Alarm Relay (RL1 & RL7) for Sensor #1. Double Pole, Double Throw DANGER Gas Concentration Alarm Relay (RL3 & RL8) for Sensor #2. Universal Power Supply (100-240 VAC –50/60 Hz).
Page 18 DRAWING NO. 3 Typical Wiring Schematics Chlorine and Sulfur Dioxide A. Typical wiring schematic of the 4-20 mA Output Circuit Board. Maximum 30 Volt DC Power Supply (BY OTHERS) + – B. Typical wiring schematic of the OPTIONAL RS232 Serial Output Circuit Board. C.
Page 19 DRAWING NO. 4A REGAL Series 3000 Gas Detector (Chlorine or Sulfur Dioxide) Typical Installation - 1 Sensor GAS DETECTOR DRAWING NO. 4B REGAL Series 3000 Gas Detector (Chlorine, Sulfur Dioxide or Chlorine and Sulfur Dioxide) Typical Installation - 2 Sensors GAS DETECTOR...
Page 20 DRAWING NO. 5 REGAL Series 3000 Gas Detector (Chlorine and Sulfur Dioxide) Faceplates GAS DETECTOR GAS DETECTOR Gas Detector — 1 Sensor Gas Detector — 2 Sensors DRAWING NO. 6 Wiring Diagram Remote alarm light and Chlorine room exhaust fan connections showing the exhaust fan...
Page 21 DRAWING NO. 7 Connecting the REGAL VAC/AL-1 Remote Alarm Horn/Light Chlorine and Sulfur Dioxide This drawing shows the strobe light connected This drawing shows the strobe light and the to one of the "WARNING" relays and the alarm horn alarm horn connected to a common relay, in connected to one of the "DANGER"...
Page 22 DRAWING NO. 8 Sensor Replacement Chlorine and Sulfur Dioxide SENSOR ENCLOSURE Sensor Transmitter Circuit Board "ORANGE" SENSOR (TOP VIEW) CABLE CONNECTOR "ORANGE" Connector Sensor SENSOR Leads TRANSMITTER CIRCUIT BLACK (-) SENSOR BOARD Sensor Wire CABLE Connects Here RED (+) SENSOR Sensor Wire Connects Here SENSOR "BULKHEAD NUT"...
Page 23 DRAWING NO. 9 Engineering Data Sheet Series 3000 Gas Detector Enclosure Dimensions DIMENSIONS — Inch (mm)
