Manual 80-M001
November 2005
Revision 1
www.mcmflow.com
MODEL 80
MODEL 80S
MODEL 80D
MODEL 80SD
®
THERMAL MASS FLO-CONTROLLERS
Installation Manual & Operating Instructions
READ THIS MANUAL COMPLETELY BEFORE ATTEMPTING TO CONNECT
OR OPERATE YOUR FLO-SENSOR. FAILURE TO DO SO MAY RESULT IN
INJURY TO YOU OR DAMAGE TO THE FLO-SENSOR.
© C O P Y R I G H T 2 0 0 5 R . D . M C M I L L A N C O M P A N Y , I N C .
80-M001, pg. 1 of 32
Advertisement
Table of Contents
Summary of Contents for McMillan 80
- Page 1 © C O P Y R I G H T 2 0 0 5 R . D . M C M I L L A N C O M P A N Y , I N C . 80-M001, pg. 1 of 32...
-
Page 2: Table Of Contents
® 2. Mounting The FLO-CONTROLLER ..............6 3. Tubing Connections .................... 7 4. Installing a McMillan Inline Filter (Optional) ............7 5. Electrical Connections ..................8 a) Overview ....................8 b) Connecting The 6 Pin Mini Din Connector............ 9 c) Connecting The 6 Pin Mini Din Connector and Cable Assembly ..... 10 d) Connections For The 9 Pin D Sub Connector .......... -
Page 3: Introduction
If any shortages or damage is noted, please contact the shipping company and/or McMillan Company to resolve the problem. Contents of Box Model 80/80S shown; Model 80D and 80SD have an integrated display. drop Caution: Take care not to your controller. -
Page 4: Product Overview And Principle Of Operation
Flow in the Model 80 Series is controlled by a proportional solenoid valve with active servo electronics. The flow measurement signal is analyzed by micro-processor controlled electronics and compared to a set-point. Adjustments are then made to the valve in order to achieve the required flow rate. -
Page 5: Installation
Installation Caution: Do not exceed the pressure, temperature or power operating ranges detailed in the SPECIFICATIONS section of this manual. McMillan Company shall not be liable for any damage or injury caused by incorrect operation of their products. 1. General Considerations It is recommended that a safety shut-off valve be installed upstream (before) of the controller. -
Page 6: Mounting The Flo-Controller
® 2. Mounting the FLO-CONTROLLER McMillan Model 80 series controllers have no particular orientation or installation requirements so may be mounted in any convenient position. It is recommended that units be fixed to a suitable substrate using the two 4-40 mounting holes provided. -
Page 7: Tubing Connections
When connecting the sensor to the tubing, take care not to over-tighten the fittings or leaking may occur. 4. Installing a McMillan Inline Filter (Optional). An optional 20 Micron Aluminum filter is available for use with the Model 80 series. If ® this is ordered at the same time (recommended) as the FLO-CONTROLLER it will be preinstalled at the factory. -
Page 8: Electrical Connections
Read the following instructions carefully before making any connections. a) Overview The Model 80 Series provides a 0-5VDC analog output proportional to the flow rate. This output may be connected to a display, data acquisition system or voltmeter with an impedance of greater than 2.5 kΩ (kilo ohms). -
Page 9: B) Connecting The 6 Pin Mini Din Connector
(Ground) terminal of the voltage source. Caution: Avoid high voltage static discharges to the input signal connection. Do not short the input/output signal wires or allow them to contact the power wires at any time. DAMAGE WILL RESULT! 80-M001, pg. 9 of 32... -
Page 10: C) Connecting The 6 Pin Mini Din Connector And Cable Assembly
Caution: Avoid high voltage static discharges to the input signal connection. Do not short the input/output signal wires or allow them to contact the power wires at any time. DAMAGE WILL RESULT! 80-M001, pg. 10 of 32... -
Page 11: D) Connections For The 9 Pin D Sub Connector
Pins 1, 5, and 9 are not used. Caution: Avoid high voltage static discharges to the input signal connection. Do not short the input/output signal pins or allow them to contact the power connections at any time. DAMAGE WILL RESULT! 80-M001, pg. 11 of 32... -
Page 12: E) Connections For The 15 Pin D Sub Connector
Pins 3, 4, 6, 9, 11, 12, 13, 14 and 15 are not used. Caution: Avoid high voltage static discharges to the input signal connection. Do not short the output signal pins or allow them to contact the power connections at any time. DAMAGE WILL RESULT! 80-M001, pg. 12 of 32... -
Page 13: F) Using A 0-5Vdc Output / Input Power Adapter Package
An optional 0-5VDC Input / Output Power Adapter Package is available for use with the Model 80 series. This consists of a power source (115VAC or 230VAC), a connection hub and two cable assemblies with pig-tail (soldered wire) ends. This should be assembled as shown in the following diagram. -
Page 14: Operation
At 500sccm the output signal would be 5VDC If the output signal were 3.5VDC then the flow rate would be: 500 ÷ 5 × 3.5 = 350sccm If the maximum flow rate is exceeded non-linear and inaccurate readings will result. 80-M001, pg. 14 of 32... -
Page 15: Changing The Flow Rate Set-Point (From An External Voltage Source)
For a flow range of 0-500sccm (Range 6) : A 5 VDC Input Signal would correspond to a flow rate of 500sccm If a flow rate of 300sccm were required then the set-point would be: (300 ÷ 500) × 5 = 3.0VDC 80-M001, pg. 15 of 32... -
Page 16: Changing The Flow Rate Set-Point - Model 80D And 80Sd
Model 80D /80SD Set-Point Potentiometers 6. Power Save Mode. To improve valve performance and reliability over time, the Model 80 Series features a Power Save Mode. This is activated after a prolonged application of a zero or 80-M001, pg. 16 of 32... -
Page 17: Zero Adjustments
8. Recalibration If recalibration is required please contact the McMillan Service Department. 9. Changing the Calibration Gas – Model 80 and 80SD Only The Model 80D and 80SD may be calibrated for up to three gases. These gases, their corresponding flow ranges and accuracy specifications are detailed on the calibration certificate. -
Page 18: Maintenance And Product Care
To return a unit for repair or recalibration please contact the McMillan Service Department or follow the procedure detailed on the McMillan web site. A Return to Manufacturer Authorization (RMA) number will then be issued to enable the unit to be returned. - Page 19 No charges will be made for Warranty Repairs (see section ). The McMillan Service Department may be contacted as follows: Mailing address: McMillan Company P.O. Box 1340 Georgetown, TX 78627 U.S.A.
-
Page 20: Part Number Information
Part Number Information CODE DESCRIPTION ® Model 80 Aluminum Mass FLO-CONTROLLER ® Model 80D Aluminum Mass FLO-CONTROLLER w/display ® Model 80S Stainless Steel Mass FLO-CONTROLLER ® Model 80SD Stainless Steel Mass FLO-CONTROLLER w/display 80SD Flow Range (sccm of air) 0-50 sccm... -
Page 21: Accessories
210R Rate Display, 3½ digit, 5-30 VDC Power 250 Multi-Function Display, 115 VAC Power 250E 250E Multi-Function Display, 230 VAC Power Filters (Order Separately) Aluminum Filter, Ranges 3-8 Screws into Inlet Port Aluminum Filter, Ranges 9-10 Screws into Inlet Port 80-M001, pg. 21 of 32... -
Page 22: Specifications
CE Approved 89/336/EEC (EN 55011 & EN 50082-1) 73/23/EEC Low Voltage Directive *Specifications from 10-100% of rated flow. Linearity is best fit straight line. All calibrations performed with air unless otherwise stated on calibration certificate. 80-M001, pg. 22 of 32... -
Page 23: Dimensions
Dimensions ALL DIMENSIONS IN INCHES (MILLIMETERS IN BRACKETS) Model 80 / 80S Flow Ranges 3-10, “S4” Fittings Shown FLOW 3.80 [ 96.5 ] [ 12.7 ] [ 12.7 ] [ 81.3 ] 1.00 [ 25.4 ] [ 131.1 ] 2.200 [ 55.9 ]... -
Page 24: Limited Warranty
Replacement parts are warranted to be free from defects in material or workmanship for ninety (90) days or for the remainder of the Limited Warranty period of the McMillan product in which they are installed, whichever is longer. Parts not installed by factory authorized service centers may void the warranty. - Page 25 If customer’s product fails to work as warranted herein, customer’s sole and exclusive remedy shall be the repair or replacement at McMillan’s option. McMillan is not liable for any damages caused by the product or the failure of the product to perform, including any lost profits or savings, incidental or consequential damages. McMillan is not liable for any claim made by a third party or made by a buyer for a third party.
- Page 26 The arbitration shall be conducted in English. The UN Convention on Contracts for the International Sale of Goods shall not apply to this Limited Warranty. R. D. McMillan Company, Inc. 7075 R.R. 2338 P. O. Box 1340 Georgetown, Texas U.S.A. 78627 80-M001, pg. 26 of 32...
-
Page 27: Gas K Factors
These K Factors are given for reference only and are not intended as a recommendation of application suitability. Accuracy and response will be affected depending on the gas and flow range. Check the compatibility of all wetted materials before using any gas other than the calibration gas for the unit. 80-M001, pg. 27 of 32... -
Page 28: Troubleshooting Guide
Section C The gain potentiometer has Contact the factory been adjusted Unit needs recalibration Contact the factory Flow too high for the unit Ensure that the flow being measured is within the capabilities of the unit 80-M001, pg. 28 of 32... - Page 29 Unstable power supply Check the stability and suitability of the power source Insufficient warm-up period Allow the unit to warm-up for at least 5 minutes. 80-M001, pg. 29 of 32...
-
Page 30: Contacting Mcmillan
Georgetown, TX 78627 U.S.A. Shipping address: McMillan Company 7075 RR 2338 Georgetown, TX 78628 U.S.A. Phone: (512) 863-0231 Fax: (512) 863-0671 For repairs and/or return information, please contact our service department any of the ways shown above. 80-M001, pg. 30 of 32... - Page 31 THIS PAGE INTENTIONALLY LEFT BLANK. Manual 80-M001 November 2005 Revision 1 www.mcmflow.com...
- Page 32 THIS PAGE INTENTIONALLY LEFT BLANK. Manual 80-M001 November 2005 Revision 1 www.mcmflow.com...
