- Page 1 Operation Manual Auto Blower PF-6302 * Rack mount products in the Western Hemisphere(North America, South America, and the Caribbean) do not have handles installed due to customer preference.
- Page 2 A personal welcome to you from the management and employees of Inter-M All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products.
-
Page 3: Table Of Contents
AUTO BLOWER Contents Contents Unpacking ............................2 Installation Environment............................2 Important Safety Instructions......................2 Features ............................3 Accessories.............................3 Front Panel ............................4 Rear Panel ............................5 Applications ............................6 Block Diagram ..........................7 Specifications ..........................8 Service Procedures............................10 Schematic.............................10 Parts List ............................10 Warranty ............................10 PF-6302... -
Page 4: Unpacking
AUTO BLOWER Unpacking Unpacking Although your PF-6302 is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation. As with most electronic devices, we strongly recommend you retain the original packaging. In the unlikely event the product must be returned for servicing, the original packaging (or reasonable equivalent) is required. -
Page 5: Features
- MANUAL MODE OPERATION When it's manual mode, the fan operates always regardless of temperature. - AUTO MODE OPERATION When it’s auto mode, the fan operates at 35°C/95°F. Accessories One detachable DC power cord is provided for use with this product. PF-6302... -
Page 6: Front Panel
You can select the operating mode by using this switch. When its OFF mode the fan is stopped. When it’s manual mode, the fan always works regardless of temperature. When it’s auto mode, the fan starts automatically over 35°C/95°F. PF-6302... -
Page 7: Rear Panel
AUTO BLOWER Rear Panel Rear Panel THERMAL DC INPUT 1. THERMAL SENSOR AND SENSOR HOLE It detects the inside temperature of PA RACK. 2. DC INPUT TERMINAL It connected to DC +24V. 3. FAN PF-6302... -
Page 8: Applications
AUTO BLOWER Applications Applications ※ Please be careful the polarity DC power. PF-6302 PD-6359 PF-6302... -
Page 9: Block Diagram
AUTO BLOWER Block Diagram Block Diagram PF-6302... -
Page 10: Specifications
AUTO BLOWER Specifications Specifications PF-6302 Operating Mode Off/Manual/Auto Operating Temperature at Auto Mode 35°C Current Max. 240mA Opeating Speed 2600 RPM Air Flow Max. 2.33m /min Operation Temperature -10°C ~ +40°C / 14°F~104°F Power Source 24V DC Weight (SET) 1.28kg/2.82lb Dimensions (SET) 482(W)x132(H)x35(D)mm/19(W)x5.2(H)x1.4(D)in... - Page 11 AUTO BLOWER ※ DIMENSIONS PF-6302...
-
Page 12: Service
To obtain specific warranty information and available service locations contact Inter-M directly or the authorized Inter-M Distributor for your specific country or region. - Page 13 NOTE PF-6302...
- Page 14 NOTE PF-6302...
- Page 15 PF-6302...
- Page 16 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
