  • Page 1 LED TV TV122 INSTRUCTION MANUAL...

  • Page 2: Table Of Contents

    TO THE CUSTOMER: Thank you for purchasing this LED TV. When opening the box for the first time, please check whether all the accessories are present. Before connecting parts and power, please carefully read the user manual and always keep these instructions handy and close by your LED TV.

  • Page 3: Safety Precaution

    1.Safety precaution Notes: The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of insinuated WARNING dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION:...

  • Page 4: Accessories

    SAFETY WARNINGS Before using this product, read and follow all warnings and instructions. This product is not intended for use by young children. Young children should be p roperly s upervised. This product is intended for household use only and not for commercial or industrial use.

  • Page 5: Remote Control Manual

    3.Remote control manual Power button NICAM function button Sound mode button Picture mode button Sleep button Numeric button Return channel button Channel list button Signal source selection button Main menu Right LEFT Confirm button Down Information button Exit the OSD menu button Mute button Volume adjusting button Channel selection button...

  • Page 6: Remote Control Functions

    4.Remote control functions : Power on/standby. S.MODE: Select a sound mode (Off, Concert,Living Room,Hall,Bathroom,Care,Arena,Church). SLEEP: The TV will automatically switch to standby after a preset time I/II: Select audio language (A2 or NICAM). P.MODE: Select picture mode (Standard, User, Cinema, Sport, Vivid, Hi-Bright). ASPECT: Select the picture display ratio: 16:9 / 4:3 / AUTO (Display in 4:3 format is not possible if the resolution is above 720P.).

  • Page 7: Teletext Function Buttons

    5.TELETEXT function buttons Press this button once, turn on the teletext function, Press twice, enter picture and text mix mode. Press once more, turn off the teletext function. After searching for some page, press this key once to go back to the text mode. While the searching result will be displayed at the top of the TV picture, press again to go back to the text mode.

  • Page 8: Led Tv Panel Overview

    6.LED TV panel overview TV Control Panel 1.Volume adjustment and Menu item adjustment. 2.Channel selection and Menu item selection. 3.Main menu display and confirm. 4.Signal Source selection button. 5.On/off button. Instruction of the touch button 1. Press any button with your fingers lightly to activate the touch buttons and all indicators will be lit.
  • Page 9 TV Terminal connections 3. Headphone output. 1. USB input. 2. AV input. 4. CI card input. 1. Antenna input (75 Ohm VHF/UHF). 2. HDMI input. 3. VGA input. 4. Coaxial audio signal out plug. 5. PC audio input. 6. Component and audio input terminal. 7.

  • Page 10: Connecting To External Devices

    7.Connecting to external devices ANTENNA SCART HDMI COAXIAL PC AUDIO S-VIDEO PC AUDIO HDMI Y PB PR VIDEO S-VIDEO HDMI...

  • Page 11: The Osd Menus

    8.The OSD menus Menu Setup TV (When using for the first time only) Initial Setup Initial Setup Complete Welcome Welcome to use the Wizard for Congratulations!! Initial Setup !! Please press [OK] to start the Completed Initial Setup. wizard. Please press [OK] to exit the wizard. Back Language Initial Setup...
  • Page 12 Menu Operation Under TV Input 1. VIDEO MENU Video Picture Mode Standard a. The following picture is the sketch map of Brightness Audio Contrast the video menu. Saturation b. The definition of each option: Sharpness b-1. Picture Mode: Change the picture mode Setup Medium Color Temperature...
  • Page 13 2. AUDIO MENU Video Balance Video Video a. The following picture is the sketch map Bass Audio Treble of the audio menu. Sound Surround b. The definition of each option: Equalizer Auto Volume Control Setup b-1. Balance: Change the value of Balance with the key / in the range of -50 to +50.
  • Page 14 The submenu of Channel Item Channel Scan Video Video Update Scan b-3-1. Channel Scan Auto channel searching. Audio Manual Scan b-3-2. Update Scan Searching added channel. G Gain Channel Skip B Gain Channel Sort b-3-3. Manual Scan: manual channel searching Channel Edit Setup Channel Decode...
  • Page 15 b-3-4. The submenu of Channel Skip Digital arte Video Video The channel skip is used for skipping Digital phoenix Audio the channel. Digital Das Erste Digital WDR Dortmund Digital WDR Dusseldorf Setup Digital WDR Essen Analog Parental Analog Analog BBC1 Analog BBC1 Channels Skip...
  • Page 16 b- 3- 7. T he submenu of Channel Decode Analog Video Video The channel decode is used for decoding Analog Audio Analog BBC1 the channel. Analog BBC1 Analog Setup Analog Analog Parental Analog Analog Analog Select EXIT Exit Channels Decode b-3-8.
  • Page 17 4. Setup MENU Video Video OSD Language English Screen mode a. This menu is used to set the function Auto Audio OSD Timeout Long b. The definition of each option: OSD Transparency Middle b-1. OSD Language: Change the OSD Time Setup Setup language in the sequence as: English Subtitle...
  • Page 18 The Submenu of Time Setup Video Video Time Zone As Broadcaster b-5-1. Time Zone: Change the time zone Time Audio by user. b-5-2. Time: set the time. and set power Setup on/off time. Parental Time Setup Select EXIT Exit The submenu of Subtitle Item. Video Video Analog Subtitle...
  • Page 19 5 . Parental menu Video Video Password a. This menu is used to set the block Audio function. Password set the child lock password, Setup the initial password is 0000. Parental Parental Enter Select EXIT Exit b. The Submenu after You Enter the Video Video Hotel Block...
  • Page 20 b-2. The submenu of channel block. arte Video Video Digital phoenix If you select any of the channel, the Digital Audio Digital Das Erste channel can not receive signal unless WDR Dortmund Digital you unblock it. WDR Dusseldorf Digital Setup Digital WDR Essen Analog...
  • Page 21 b-5. The submenu of change password. Video Video New Password You need to input the new password Confirm Password Audio and confirm it. Setup Parental EXIT Exit Change Password b-6. The submenu of Clean All. Are you sure? Press OK to clean your set or cancel to return the previous menu.
  • Page 22 Main menu under VGA Input a. When system signal source switch to Auto Adjust Video Video Video Video H.Position VGA, there will be a VGA mark in the up- Audio V.Position left corner of the screen, it is in the VGA Phase menu ,and you can setup the item.

  • Page 23: Usb Multimedia Operation

    USB Multimedia operation Import ant: All multimedia operations are available only when an USB storage device is Connected.The USB storage device is not included in this TV packing, please purchase it separately. NOTE: (a)Switch off the TV before connecting any USB devices of the USB port (b)If a hard disk is used ,make sure its AC/DC adapter is connected to the power supply.
  • Page 24 USB Multimedia operation Multimedia Operation:Music Press buttons to select Music button to enter ,Press EXIT button to return to the previous menu. press the buttons to select the Music to view,press the OK button to play the music. press the EXIT button to exit.

  • Page 25: Trouble Shooting

    Trouble shooting Before contrast the service technician, perform the following simple checks. If any program still persists, unplug the LED TV and calling for serving. PROBLEM PROBLEM POSSIBLE SOLUTION POSSIBLE SOLUTION - Check that the main plug has been connected to a wall let. No sound and picture - Check that you have pressed the POWER button on the front of TV set.

  • Page 26: Maintenance

    NOTE: There is a problem in VGA mode.(Only VGA mode applied) NOTE: There is a problem in VGA mode.(Only VGA mode applied) PROBLEM PROBLEM POSSIBLE SOLUTION POSSIBLE SOLUTION - Adjust resolution, horizontal frequency, or vertical frequency. The signal is out of range. - Check it whether the signal cable is connected or loose.
