Sony SU-PW1 Product View

SU-PW1
NOTE:
WHERE THERE ARE CLOSE TOLERANCES
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION
RECOMMEND THAT THE PRODUCT ITSELF
MEASUREMENTS.
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX (201) 930 7891 • b2b.sel.sony.com
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:

FRONT VIEW

23 5/8"
9 5/8"
1 3/8"
15 deg Tilt
10 deg Tilt
0 deg Tilt
*13 3/8"

TOP VIEW

MOUNTNG
SURFACE
PANEL SIDE
INVOLVED IN CABINET BUILDING
SONY WILL NOT BE RESPONSIBLE FOR
PLASMA MOUNTING
BRACKET FOR
KE-XBR 42& 50
23 5/8 " x 15 3/4" x 2 1/4"
Approx 20 lbs
SIDE VIEW
1 3/8"
5 3/4"
*12 1/4"
PANEL SIDE
*
DIMENSIONS
MATCH MOUNTING
HOOKS ON PANEL
15 deg
PANEL SIDE
BE USED TO MAKE THE ACTUAL
INACCURACIES
POWER
N/A
REQUIREMENTS:
POWER
CONSUMPTION:
N/A
2 1/4"
15 3/4"
6"
WE
