ISTRUZIONI PER L'INSTALLAZIONE DELLA RUBINETTERIA
INSTRUCTIONS FOR THE INSTALLATION OF THE FAUCETS
INSTRUCTIONS POUR L'INSTALLATION DE LA ROBINETTERIE
MONTAGEANLEITUNGEN ZUR INSTALLATION DER ARMATUREN
INSTRUCCIONES PARA LA INSTALACION DE LA GRIFERIA
ИНСТРУКЦИИ ПО МОНТАЖУ СМЕСИТЕЛЬНОЙ АРМАТУРЫ
INSTRUKCJE INSTALACJI ARMATURY
Zucchetti Rubinetteria S.p.A.
ZB2481
Advertisement
Related Manuals for ZUCCHETTI Bellagio ZB1481
Summary of Contents for ZUCCHETTI Bellagio ZB1481
- Page 1 INSTRUCCIONES PARA LA INSTALACION DE LA GRIFERIA ИНСТРУКЦИИ ПО МОНТАЖУ СМЕСИТЕЛЬНОЙ АРМАТУРЫ INSTRUKCJE INSTALACJI ARMATURY ZB1481 ZB2481 Zucchetti Rubinetteria S.p.A. Via Molini di Resiga, 29 - 28024 Gozzano (No) - Italy - Tel. +39 0322 954700 - Fax +39 0322 954823 - zucchettidesign.it...
- Page 2 INSTALLAZIONE / INSTALLATION / УСТАНОВКА ZB1481 — ZB2481 Predisporre la piantana 1, inserendo il dado 2, la ranella 3 e la guarnizione 4. GB - Prepare the side valve 1, by inserting the nut 2, the washer 3 and the seal 4. Préparer la pièce de raccordement 1, en insérant l’écrou 2, la rondelle 3 et le joint 4.
- Page 3 INSTALLAZIONE / INSTALLATION / УСТАНОВКА ZB1481 Inserire a pressione la maniglia 9 sull’asta della piantana. Serrare con una chiave da 32 mm il dado 2. GB - Insert with pressure the handle 9 in the side valve rod. Tighten the nut 2 with a 32 mm Key. Introduire à...
- Page 4 INSTALLAZIONE / INSTALLATION / УСТАНОВКА ZB1481 — ZB2481 Diametro min. 45 mm max. 46 mm Handshower Spout...
- Page 5 Recommended temperat.: 60-65°C Zucchetti taps can be used with electric storage water heathers and instant gas types, centralised system, combi wall-mounted gas boilers and district heating systems. Before connecting the taps we recommend draining the system thoroughly; it is also advisable to install under basin stop valves with filter (art. Z9126P). Should the water pressure be higher than 5 bar, a pressure reducer should be fitted upstream of the supply pipes.
