Mubea U-MOBILITY Quick Start Manual

Confirmation vehicle instruction and test drive Mubea U-Mobility XBoard
Herewith I confirm that I am at least 14 years old and that an employee of Mubea (a nominated
employee) has instructed me in the functions of the U-Mobility XBoard.
Notice: Driving the XBoard requires a certain amount of practice. Due to the three wheels and the tilting
mechanism, the vehicle takes some time to get used to, especially when entering curves. Please approach the
driving style slowly and drive with foresight.
Get used to the functions and the position of the operating elements.
❑ Handlebar adjustment: The handlebar height is pre-set.
Notice: Please do not adjust the height of the handlebar during the test ride.
❑ Steering: The entire range of possible steering angle can be used.
Notice: Please keep both hands on the handlebars at all times.
❑ Tilt: The tilt angle of the chassis is mechanically limited. Tilting beyond the limit will cause one of the front
wheels to lift off the road.
Notice: Please avoid lifting one of the front wheels.
❑ Bell: It is located on the left handlebar.
❑ Rear wheel cover: The rear wheel cover (see Fig. 1) has no braking function.
Notice: Please do not step on the wheel cover.
❑ Splash guard: If required, push the splash guard
until it stops.
Notice: Always push the splash guard
Figure 1: Rear wheel cover
❑ Power on / power off: Briefly press the On / Off button
To switch it off, press and hold the On / Off button
Figure 3: Switch On / Off
U-Mobility XBoard vehicle instruction V1 August 23
2 (see Fig. 2) with the slider
2 (see Fig. 2) back to its basic position after driving.
Figure 2: Splash guard
1 (see Fig. 3) to switch the XBoard on.
1 (see Fig. 3) for about 3 seconds.
1 (see Fig. 2) to the rear up
Seite 1 von 3
