- Page 1 100W SOLAR PANEL OPERATING INSTRUCTIONS PLEASE READ BEFORE OPERATING THIS EQUIPMENT...
- Page 2 THANK YOU We appreciate your business and would like to thank you for choosing HALO! Your safety is important to us. Please read the instructions carefully and utilize the proper precautions before operating this equipment.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Included Items......................2 Operating Instructions...................3 Connecting a HALO Solar Panel in Parallel............4 Connecting 3 HALO Solar Panels in Serial............5 Charging Electronic Devices................6 Specifications......................7 Safety Precautions....................8 FCC Compliance......................9 Warranty and Contact Information..............10 1 POWER YOUR LIFE... -
Page 4: Included Items
INCLUDED ITEMS • HALO 100W SOLAR PANEL • 10Ft. DC5525 CABLE POWER YOUR LIFE 2... -
Page 5: Operating Instructions
OPERATING INSTRUCTIONS 1. Unfold the solar panels. 2. Adjust the kick stand. For optimal solar radiation, please angle the solar surface and the sunlight at 90°F. MORNING OR WINTER NOON OR SUMMER RIGHT-ANGLE RIGHT-ANGLE 90° 90° 3. Connect the DC5525 to DC5525 cable to the DC Input port on the powerstation. -
Page 6: Connecting A Halo Solar Panel In Parallel
CONNECTING HALO SOLAR PANELS IN PARALLEL Two or more HALO 100W Solar Panels can be connected together for higher output power. Up to six solar panels can be connected in a serial/parallel configuration. 2 Panel Parallel Kit (sold separately). • One MC4 MMF Y-Cable •... -
Page 7: Connecting 3 Halo Solar Panels In Serial
CONNECTING 3 HALO SOLAR PANELS 3 Panel Serial Kit (sold separately). • One MC4 to Anderson Connecting Cable • Three MC4 to DC5525 Connecting Cables MC4 to Anderson MC4 to DC5525 MC4 to DC5525 MC4 to DC5525 5 POWER YOUR LIFE... -
Page 8: Charging Electronic Devices
CHARGING YOUR ELECTRONIC DEVICES DIRECTLY USING YOUR HALO SOLAR PANEL Your electronic devices may be charged directly from the HALO Solar Panel. To charge your electronic devices, locate the output box located on the back of the solar panel. The appropriate USB cable (not included) can be used to charge your electronic devices. -
Page 9: Specifications
SPECIFICATIONS HALO 100W Solar Panel Model........................SE502 Max Power (Pmax)..................100W Open Circuit Voltage...................20.52V Maximum Working Voltage (Voc)..............17.1V Short Circuit Current (Isc)................6.14A Maximum Working Current (Ismp)............5.84A DC Output................12V-20.52 100W Max USB-A Output..........5V/3A, 9V/2A, 12V/1.5A 18W Max USB-C Output..........5V/9V/3A, 12V/2.25A 27W Max Folded Dimensions............23.5 x 23 x 1.4 inches Unfolded Dimensions..........46.1 x 23.5 x 0.19 inches... -
Page 10: Safety Precautions
• Do not disassemble your HALO 100W Solar Panel. • Do not bend, puncture, crush or subject to mechanical shock. • The HALO 100W Solar Panel, along with its accessories, are not toys and should be kept away from children. -
Page 11: Fcc Compliance
COMPLIANCE WITH FCC REGULATION This device complies with part 15 of the FCC Rules and RSS-Gen of IC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 12: Warranty And Contact Information
HALO warrants its products to be free from defects in material and workmanship under normal use. During the first 90 days from date of purchase, HALO will repair or replace the defective product. This warranty does not affect any statutory rights that you may be entitled to. - Page 13 11 POWER YOUR LIFE...
- Page 14 POWER YOUR LIFE 12...
- Page 15 13 POWER YOUR LIFE...
- Page 16 HALO POW E R w w w. .co m...
